Summary of Contents for DMK DHH-1500
-
Page 2: Table Of Contents
Table of contents 1. Product introduction····························································3 Product characteristics·························································4 3. Parameter valve··································································5 Appearance function····························································6 usage method·····································································7 Software summary and operation guide····································9 Maintenance and troubleshooting··········································13 8. Precautions and Safety Protection··········································18 9. Attachment······································································20... -
Page 3: Product Introduction
Thank you for choosing our handheld welding equipment, and this user manual provides you with important information on safety, operation, maintenance and other aspects. Therefore, please read this user manual carefully before using this product. To ensure safe operation and optimal product performance, follow the following precautions and warnings and other information in the manual. -
Page 4: Product Characteristics
2. Product characteristics ① Welding speed is fast, 2-10 times faster than traditional welding, a machine can save at least two welders a year. ② Less laser welding consumables, long life. ③ Simple operation, no work certificate can be employed, no teachers can also weld beautiful products. -
Page 5: Parameter Valve
⑫ Exclusive laser safety operation protection function to ensure the safety of operators during work. 3. Parameter valve 型号 DHH-1500 Model 激光功率 1500 Laser power 工作模式 连续或调制 Working mode Continuous or modulate 激光波长 1080NM Laser wavelength 光束质量 M2<1.2 Beam quality 输出功率稳定度... -
Page 6: Appearance Function
4. Appearance function touch screen emergency stop indicator light 65-35-60CM (including cable support) shake hands fiber cable welding head argon port wire feeder port cable support switch power wire port... -
Page 7: Usage Method
protective lens copper nozzle focusing lens reflection lens scale tube motor wire feed bracket collimating lens switch button QBH protective cover Schematic diagram of welding head Laser equipment wire feeder 5. Usage method Equipment installation and debugging ① The equipment power cord is connected to the power supply empty opening, and pay attention to the power and voltage matching. - Page 8 of the equipment must be connected to the standard ground wire terminal. ② Prepare the argon bottle, the pressure gauge, and insert the trachea into the argon interface. ③ Prepare a dedicated welding workbench, and the workbench cannot share the ground wire with argon arc welding, gas shielded welding, etc. Boot process ①...
-
Page 9: Software Summary And Operation Guide
③ Turn off the key switch and organize the fiber optic cable; ④ Turn off the empty opening outside of the device. 6. Software summary and operation guide The operation panel is mainly composed of the touch screen and the control box. - Page 10 welding, it can be used intermittently for spot welding operation, which is convenient to control the spot welding time due to human difficulties. This function should be set as required Control panel technology page ① The process interface contains the process parameters of debugging, click the box to modify, click OK, and then save in the quick process, click import (modify-save-import).
- Page 11 1000). ④ Duty cycle range 0 to 100 (default 100, usually not changed). ⑤ The pulse frequency range is recommended from 5-5000Hz (default 2000, usually no modification). ⑥ Click the HELP button on the top right to get more relevant parameter explanations.
- Page 12 ① The laser power is the maximum power of the laser used. ② The default open gas delay and off gas delay are 200ms, range 200ms-3000ms. ③ From N1% of process power to 100%; from 100% of process power to N2;...
-
Page 13: Maintenance And Troubleshooting
The duration of spot welding is the light output time after the trigger is pulled, that is, even if the button is released, the laser will still be released according to the output time. The spot welding interval time is the stop time between two spot welding times after pulling the trigger button. - Page 14 dirty, and the protective lens should be replaced in time. ②The lens cleaning technology is extremely important. If the cleaning is not good, the performance of the lens will be reduced, and the lens will be damaged if it is serious. So when cleaning the lens, we must be very careful. ③...
- Page 15 Laser center adjustment method (tilt angle) When the red light cannot come out of the copper nozzle completely, it needs to be adjusted manually at this time to prevent the copper nozzle from being burned. Please note: When using for the first time, when the red light cannot come out from the copper nozzle, be sure not to emit light.
- Page 16 ② We need to remove the back cover, and you can see the four adjustment screws, and adjust the center according to the video ③ Finally, this effect can be achieved ④ Minor left and right deviations can be set by setting the panel laser center offset Common abnormal treatment Laser / water cooler / air pressure alarm is indicated...
- Page 17 turning), check whether the controller and the four-core wire of the screen are connected correctly, and whether the voltage of the 1st foot and the 4th foot 24V is normal. ② If it is not clicked in normal use, check whether the temperature of the whole machine is too high.
-
Page 18: Precautions And Safety Protection
The monitoring interface checks whether the safety lock and other alarms are normal, and also checks whether the temperature exceeds the temperature alarm threshold. Red light partial See the laser center adjustment method for details 8. Precautions and Safety Protection Matters need attention ①... - Page 19 people. When you stop using or temporarily suspend use, please click the interface to close the button; 3. When welding some high reverse materials, please pay attention to the high temperature reflection area.(Aluminum plate galvanized plate). Demark (Wuhan) Technology Co., Ltd Website: https://www.demarkchina.cn/...
-
Page 20: Attachment
Electrical Schematic Diagram Attachment 1 Laser control diagram Attachment 2... -
Page 21: Operating Environment And Parameters
Attachment 3 Wire Feeder Instructions 1. Size 560×250×350mm 2. Peculiarity Touch screen display, four wheel double drive wire feeding mechanism, wire feeding speed 25-600cm /min (adjustable), support continuous wire feeding mode and pulse wire feeding mode 3. Support welding wire diameter 0.8/1.0/1.2/1.6mm, 2.0/2.5mm can be customized Operating environment and parameters Supply voltage (V) - Page 22 2.5 When installing, be sure to clamp the welding wire in the slot and then clamp it Installation of wire feeding tube 1.Wire feeder position 1.1 Loosen the locking screw of the wire feeding tube, insert it into a suitable position and lock 2.
-
Page 23: Software Operation
software operation Continuous mode - homepage introduction： 激光焊接送丝系统 Laser welding wire feeding system 连续模式 Continuous mode 首页 home page 送丝速度 wire Feed speed (cm / min) 设置 setting 手动送丝 Manual wire feed 手动回抽 Manual retraction 运行 run 停止 stop 1. "Continuous mode" means that the wire feeding is currently in "continuous mode", click the button Switchable to "pulse mode". - Page 24 "Manual Wire Feeding" from blue to green, the motor will continue to feed the wire at the "Manual Wire Feeding Speed", and release the button to stop the wire feeding. 4. "Manual retraction" controls the speed of the motor during manual retraction, which is usually used for daily debugging of equipment.
- Page 25 中文 the Chinese language 激光焊接送丝系统 Laser welding wire feeding system 帮助 help 手动送丝速度 Manual wire feeding speed 手动回抽速度 Manual retraction speed 系统版本 system version 保存 save 返回 back Continuous mode - setting page introduction: 1. "Continuous mode setting" means that the current screen display is the setting page of the continuous mode of the wire feeder system, and clicking it is invalid.
- Page 26 page, which is used for daily equipment debugging. The range is 15~600cm/min. Usually set 300cm/min. 10. "System version" displays the version number of the control system of the wire feeder. 11. "save" controls the storage action of the wire feeder system parameters, including all parameters on the "Home Page"...
- Page 27 (3) smoothness: indicates the smoothness of fish scale grain in fish scale welding, the larger the value, the less obvious the effect of fish scale. Its range is: 10~80. 9. System version: The three version numbers are successively "hardware version", "master control board software version", and "screen version".
- Page 28 you can quickly adjust it through the "Arrow". Note: This "average speed" is not equal to "manual wire feeding speed". 4. Other keys and parameters are the same as "continuous mode". 脉冲模式设置 Pulse mode setting 通用参数 General parameters 启动延迟 start delay 回抽长度 ...
- Page 29 the individual fish scale pattern. The range is 50~1000ms, usually set to 500ms. 3. "Smoothness" controls the fluctuation of the interval between the two fish scales, the smaller the value, the more obvious the overall effect. The range is 10~80, usually set to 30. 4.
