- Page 1 Demark (Wuhan) Technology Co., Ltd 150w spot welding machine manual Demark (Wuhan) Technology Co., Ltd...
- Page 2 Demark (Wuhan) Technology Co., Ltd Thank you for choosing to use our "150w Spot Welding Machine", this manual describes the size and detailed technical parameters of the whole machine,the equipment start-up workflow,troubleshooting and daily maintenance of equipment. Please read this manual in detail before using the product for the first time.
- Page 3 Demark (Wuhan) Technology Co., Ltd II. Technical parameters of the complete machine laser wave length 1064nm Maximum laser power 150W Maximum laser pulse energy pulse length 0.1-15.0ms pulse frequency 1.0-15.0Hz The grade is adjustable Aiming at positioning Microscope + CCD camera system Adapt to welding All kinds of metal jewelry welding, repair Power consumption of the host...
- Page 4 Demark (Wuhan) Technology Co., Ltd 2. Structure The power supply consists of the following parts: Main circuit: including charging circuit, energy storage circuit, discharge circuit. Control circuit: including electrical control circuit, single-chip microcomputer control circuit, detection circuit and protection circuit. Rectifier circuit: AC220V through the rectifier bridge to pulsating DC, to provide energy for energy storage capacitor reactor.
- Page 5 Demark (Wuhan) Technology Co., Ltd Detection circuit: including water flow signal, heat dissipation disk temperature signal, actual pulse detection signal, etc. guard circuit a) Pre-combustion protection When the precombustion is unsuccessful or abnormal, the signal will feed back to the control system, and the system starts the protection command and makes a fault alarm prompt.
- Page 6 Demark (Wuhan) Technology Co., Ltd Figure 3-1 (graph) 2. Connect the foot switch to the foot switch socket correctly (see Figure 3-1 for illustration). Internal schematic diagram of the control signal (Figure 3-2) Foot switch is a passive input, do not connect to the external power supply. Figure3-2 (internal diagram of laser control signal) 3.
- Page 7 Demark (Wuhan) Technology Co., Ltd 4.The microscope is correctly installed on the machine, please refer to the position and direction (Figure 2-1). The microscope eyepiece is fixed with the meter screw, which is fixed on the side of the base to ensure that the base is installed horizontally, and locked with a random inner hexagon wrench.
- Page 8 Demark (Wuhan) Technology Co., Ltd graph 3-4 IV.Software operation 1.Entering the standby interface, you can see the simple and easy to understand human-computer interaction interface, and the common operation buttons are displayed in the boot waiting interface.(See Figure Figure 4-1) graph 4-1...
- Page 9 Demark (Wuhan) Technology Co., Ltd 2.Touch the red power supply, the button (see Figure 4-1) enters the power waiting interface, and the power button turns green successfully. 3.The power system will enter the standby state interface (see Figure 4-2). At this time, the power supply has been charged and the xenon lamp has been prefired.
- Page 10 Demark (Wuhan) Technology Co., Ltd graph 4-3 4.Home page interface introduction Order: The parameters set in the current interface are saved as a program as a whole, and a number number is set to facilitate the user to store, classify, and call at any time.
- Page 11 Demark (Wuhan) Technology Co., Ltd automatic welding of plane and workbench can be higher. Power: It represents the size of the discharge current of the lamp tube (the xenon lamp that provides light energy for laser excitation). The higher the working current, the greater the laser output energy.
- Page 12 Demark (Wuhan) Technology Co., Ltd graph 4-4 Reduce / increase: Modify the size of the parameter values. Direct click button, the value will change at 0.1 / time or 1.0 / time. Preserve: Save the above modified parameters in the current number number program (figure 4-3, namely program 1).
- Page 13 Demark (Wuhan) Technology Co., Ltd parts: microscope and built-in HD CCD camera. Users can choose one or both of the observation methods according to the needs, which can clearly observe the welding position of the workpiece, which is easy for welding. 2.
- Page 14 Demark (Wuhan) Technology Co., Ltd unconventional faults, please timely contact our technical service personnel to solve, can rise technology for your equipment escort, after-sales worry. Abnormal Possible cause Processing method phenomena The power switch is not closed Close the power main switch and The display The word plug is not touched plug to contact well...
- Page 15 Demark (Wuhan) Technology Co., Ltd 2. Laser system maintenance and maintenance The storage site of the equipment should avoid strong mechanical vibration, strong mechanical vibration will affect the light path structure inside the laser, thus affecting the light effect. In the process of use, the lens paper should be used to protect the laser objective lens and microscope eyepiece, so as not to avoid dust affecting the laser Demark (Wuhan) Technology Co., Ltd...
