- Page 1 INSTALLATION & MAINTENANCE GUIDE SECURE Area Light ® ITEM: ASA-4301-90S-UNV-S-SF SAVE THESE INSTRUCTIONS - 1 -...
-
Page 2: Important Safety Instructions
INSTALLATION & MAINTENANCE GUIDE SECURE Area Light - ASA-4301-90S-UNV-S-SF ® IMPORTANT: PLEASE READ BEFORE INSTALLATION READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. Fixtures must be wired in accordance with all local codes and the National Electrical Code. -
Page 3: Package Contents
PACKAGE CONTENTS (1) Luminaire (1) Photocell (5) Wire Connectors PRODUCT DIMENSIONS 10.23” 18.24” 5.19” 6.3” 13.93” 3” 3”... - Page 4 INSTALLATION & MAINTENANCE GUIDE SECURE Area Light - ASA-4301-90S-UNV-S-SF ® INSTALL PHOTOCELL Insert the twist lock Photocell photocell into the receptacle and rotate until Receptacle it stops.. The photocell goes in one way, the large tab into the large slot.
- Page 5 ACCESS TO SELECTION SWITCHES Remove threaded Plug Plug from the side of the luminaire to access the selection switches. COLOR TEMPERATURE (CCT) & POWER SELECT SWITCHES 5K-4K-3K 40/60/80/90W Color Temperature Selection Switch 5K - 4K - 3K 5000K – 4000K – 3000K...
- Page 6 INSTALLATION & MAINTENANCE GUIDE SECURE Area Light - ASA-4301-90S-UNV-S-SF ® ACCESS TO SELECTION SWITCHES Replace the threaded Plug Plug with O-ring on the side of the fixture. ADJUST THE LUMINAIRE ANGLE Socket Cap Screw ROTATE Allen Wrench (not included) Max. 150°...
- Page 8 1-813-978-3700 • Mon-Fri 9am-6pm (ET) Specifications and product details subject to change without notice. © Copyright 2024, AMP® Lighting, Lutz FL USA 33549 • All rights reserved. customersupport@amplighting.com • amplighting.com...
