- Page 1 SD50RT Quick Start Guide...
-
Page 2: Appearance And Keypad
SD50 Quick start guide V1.0 Appearance and Keypad Power Scanning Handle Standby Battery Scanning Volume Flash&Camera Handle Standby battery cap SIM Card 1 Both SIM cards use standard Nano-SIM cards. Please use professional equipment to open the SIM card warehouse, so as not to damage the equipment and affect the protection performance. -
Page 3: Wifi & Network
SD50 Quick start guide V1.0 3 When the SIM2 card is placed, the SIM2 card is placed horizontally in the upper left corner of the first layer of the slot, which is flat with the slot, and the SIM2 card is successfully placed. 4 Memory card slot, maximum expandable 128G memory card. - Page 4 SD50 Quick start guide V1.0 Scan Sound:After the barcode scanning is finished, the tone will sound. Scan Vibrate:Vibration alert after barcode scanning. Save Image:Save the barcode picture to album. Scan mode:The device has a built-in three-minute scan mode. Select the fast scan mode you are used to.
- Page 5 SD50 Quick start guide V1.0 Continuous Scan Internal:Setting the continuous Scan Internal(ms). Attached key value: Special keys are added after the barcode output, such as "Enter" and "Line Feed". With table With enter Add custom prefix: add custom characters, numbers, letters, etc. before the barcode output (add "#"...
- Page 6 SD50 Quick start guide V1.0 Choose code-1d-EAN-13-Enable such as the scan result after scanning "EAN-13" barcode, one less. You can select "EAN-13" type, enable "Check transmit Digit", and scan later the results show normal. Example1:EAN-13 barcode:6456813472345;When the "Check transmit Digit"not enabled,the result show 645681347234 ;and when the "Check transmit Digit"...
- Page 7 SD50 Quick start guide V1.0 Example1:UPC-A barcode:123456789012;When the "Check transmit Digit"not enabled,the result show 12345678901,and when the "Check transmit Digit" is enable,the result show 123456789012. Choose code-1d-Code39-Enable such as the scan result after scanning "Code39" barcode, one less. You can select "Code39" type, enable "Transmit Start/Stop Characters ", and scan later the results show normal.
- Page 8 SD50 Quick start guide V1.0 More settings Click "Settings"-"Scan" to slide to the bottom, and click "More". Show scan hand type.And can check update after connecting to Check update: the internet. Note: "Check update"requires the scanning service version 5. 1 or higher. This is used to set a custom broadcast.
- Page 9 SD50 Quick start guide V1.0 Charging & attention Please use the supplied charger and USB (Type-C) cable. Otherwise, the fast charging mode cannot be enabled. Using a non-original charger and a USB charging cable may result in long charging time and repeated restarts, and affect the battery life.
- Page 10 SD50 Quick start guide V1.0 When the device is charging,the host will be charged first.And it will start to charge the standby battery after the host is fully charged.During the charging process,standby battery will not charge the host when the UHF is used Page 10...
-
Page 11: Product Parameters
SD60 Quick start guide V1.0 Product parameters Size 207*84*20mm Weight About 715g(with battery) (Note: Differences in different functional modules will cause actual weight differences, please refer to the actual product.) IP Code IP65 Color Black Screen Size: 5 inches, 18：9 Resolution * 1280 : 720... - Page 12 SD60 Quick start guide V1.0 Camera Rear camera : 1300MP，AF Front camera : 500MP，FF WWAN Dual SIM dual standby single pass, support for Nano SIM card FDD-LTE： B1/B3/B5/B7 TDD-LTE：B38/B39/B40/B41 TDSCDMA： B34/B39 WCDMA： B1/B2/B5/B8 GSM： B2/B3/B5/B8 CDMA：1x/CDMA2000 BC0 Data connect WI-FI: 802. 11a/b/g/n，2.4G & 5G WI-FI hotspot: support Support card reader mode, peer-to-peer mode, card emulation NFC:...
- Page 13 SD60 Quick start guide V1.0 Standard Range (SR) Optics Typical Range* Symbology/X-Dim mm – 419 mm (1.8” – 16.5”) 64 100% U.P.C mm - 163 mm (2.5" - 6.4") mil Code 39 mil Code 39 mm – 338 mm (1.1” – 13.3”) mill PDF 417 mm - 185 mm (1.8"...
- Page 14 SD60 Quick start guide V1.0 Shenzhen Office 2nd Floor, Building 4, Jinyuan Technological Zone, Banli Avenue, Longgang District, Shenzhen, China, 518129 Page 14...
