Summary of Contents for Speedata J-COM HT35
- Page 1 HT35 Quick Start Guide...
-
Page 2: Appearance And Keypad
HT35 Quick start guide V1.0 Appearance and Keypad... -
Page 3: Virtual Keyboard
HT35 Quick start guide V1.0 SIM Card 1 Both SIM cards use standard Nano-SIM cards. Please use professional equipment to open the SIM card warehouse, so as not to damage the equipment and affect the protection performance. 2 When the SIM1 card is placed, the SIM1 card is placed horizontally in the upper right corner of the second layer of the slot, which is flat with the slot, and the SIM1 card is successfully placed. - Page 4 HT35 Quick start guide V1.0 Quick setup You can click the iron in the lower right corner to enter the “Change keyboard” interface to enable “Show virtual keyboard”. Click “Setting”->”system”->”Languages&Input”-”Virtual Keyboard”,then click “manage keyboard”,you can manage the virtual keyboard.
-
Page 5: Physical Keyboard
HT35 Quick start guide V1.0 Physical Keyboard When the device is turned on for the first time,the default input of the physical keyboard is numbers.You can switch between numbers and uppercase and lowercase by pressing the “aA”key. -
Page 6: Wifi & Network
HT35 Quick start guide V1.0 WIFI & Network Connect to a Wi-Fi network 1 Swipe down from the status bar to open the notification panel. 2 Press to enter the WLAN settings interface. 3 Turn on the WLAN switch. The system will list the detected WLAN networks in tabular form. -
Page 7: Barcode Scanning
HT35 Quick start guide V1.0 Barcode Scanning Basic Settings Click "Settings"-"Scan" to enter the scan settings. Turn on / off the barcode scanning function. Scan engine on/off: Results of scanned barcode displayed at focus. Out to Cursor: After the barcode scanning is finished, the tone will sound. Scan Sound: Vibration alert after barcode scanning. - Page 8 HT35 Quick start guide V1.0 With table key With enter key No addition Add custom prefix: add custom characters, numbers, letters, etc. before the barcode output (add "#" for demonstration) Add a custom suffix: add custom characters, numbers, letters, etc. after the barcode output (add "#"...
- Page 9 HT35 Quick start guide V1.0 Choose code-1d-EAN-13-Enable such as the scan result after scanning "EAN- 13" barcode, one less. You can select "EAN-13" type, enable "Check transmit Digit", and scan later the results show normal. Example1:EAN-13 barcode:6456813472345;When "Check transmit Digit"not enabled,the result show 645681347234 ;and when the "Check transmit Digit"...
- Page 10 HT35 Quick start guide V1.0 enabled,the result show 12345678901,and when the "Check transmit Digit" is enable,the result show 123456789012. Choose code-1d-Code39-Enable such as the scan result after scanning "Code39" barcode, one less. You can select "Code39" type, enable "Transmit Start/Stop Characters ", and scan later the results show normal.
- Page 11 HT35 Quick start guide V1.0 Click "Settings"-"Scan" to slide to the bottom, and click "More". Check update: Show scan hand type.And can check update after connecting to the internet. Note: "Check update"requires the scanning service version 5. 1 or higher. This is used to set a custom broadcast.
-
Page 12: Product Parameters
HT35 Quick start guide V1.0 USB charging cable may result in long charging time and repeated restarts, and affect the battery life. 2 It is recommended not to operate the devices while charging, and not to cover objects on the device and charger. 3 When the device is in low power, there will be an indicator light and a desktop pop-up reminder. -
Page 13: Data Connect
HT35 Quick start guide V1.0 Type: IPS Touch screen: 5-point touch screen Processor CPU: Octa-core, 8*2.0 GHz Android 8.1 Memory RAM: 2 GB ROM: 16 GB Micro SD：Extension max128GB Battery 7.4V 19.24Wh Charging: 2.0 fast charging, full no more than 4 hours Camera Rear camera : 1300MP，AF... - Page 14 HT35 Quick start guide V1.0 WI-FI: 802. 11a/b/g/n，2.4G & 5G WI-FI hotspot: support Support card reader mode, peer-to-peer mode, card emulation NFC: mode（14443A/B, ISO 15693, NFC） Bluetooth: BT 4. 1 （BLE） fast charging USB: Type-C, OTG, USB tethering, USB Location GPS/GLONASS /Beidou Barcode Barcode engine model: CM60...
-
Page 15: Packing List
HT35 Quick start guide V1.0 Gravity sensor Light sensor Gyroscope sensor Geomagnetic sensor Packing list Standard: HT35 (with battery) X 1 Power Adapter X 1 USB Type-C cable X 1 Instruction manual X 1 CONTACT US Phone: 86-0755-8279 7385 E-mail: info@speedatagroup.com Website：...
