- Page 1 Humidifier with Fan KC-MH-8060A User's Guide Thanks for your purchase. We provide a one-year warranty. If any quality issues, replacement or refund is available. Please feel free to contact us via E-mail: service@keecoon.com...
- Page 3 Precautions Thank you for purchasing our humidifier with fan KC-MH-8060A. Please read this manual carefully before using and keep it for future reference. All pictures shown are for illustration purposes only. Actual products may vary due to product enhancement.
-
Page 4: Table Of Contents
Safety Guide Components Placement Installation Water filling Control Panel& Remote Control Maintenance 9-11 12-13 Product Specification Warranty... -
Page 5: Safety Guide
Safety Guide Do not disassemble or modify the machine. Do not subject the machine to strong impacts. Keep a safe distance when the humidifier is working, especially if you have a sensitive respiratory tract. Turn off the machine before moving it. Do not connect the machine to a socket that exceeds the rated voltage or use an extension cable, as this may cause fire or electric shock. -
Page 6: Components
Components Air circulator fan Air Outlet Panel & Humidity Sensor Display Screen ❶ Air Quality Sensor( ) Filter Air Inlet Water Inlet Back Cover Water tank Water Window Air Quality Sensor ❶... -
Page 7: Placement
Placement Place the machine in a horizontal position that is more than 20 cm away from walls, furniture, household appliances, and other objects. Do not use the machine in the following situations to avoid water leakage, signal jamming, damage or injury: In direct sunlight. -
Page 8: Installation
Installation ❷ ❶ Remove ❶ with a screwdrive Press ❷ to unlock the cover 1.Take the back cover off and pull out the 2.Remove the plastic bag from the filter. water tank slowly. 3.Install the filter to the water tank and push 4.Install the cover back to the machine the water tank back to machine and add water before use... -
Page 9: Water Filling
Water Filling ❶ Pull ❶ to open the water inlet. Add water from the water inlet. Add water below 40°C to the water tank. Do not add mineral water, plasma water, or tap water that has been left for a long time. If mold or impurities breed, it may cause health problems. -
Page 10: Control Panel
Control Panel The control panel and remote control allow you to operate the machine with ease. Here is a breakdown of the various functions: Humidify Button & Indicator Mode Change Button & Indicator White: On White: Purifier function Red:Off Green: Fan + Purifier function Blue: Fan function only Smart Mode &... -
Page 11: Control Panel& Remote Control
Control Panel& Remote Control Mode ① Mode ② Mode ③ Touch this button to turn on/off the machine. Everytime it start in mode ① Power Touch this button to enter smart mode, the humidity function will be turned on automatically when your environmental humidity is below 45%. - Page 12 Control Panel& Remote Control Mode ① Mode ② Mode ③ Touch this button to turn on/off humidifier function. When the button is flashing, it means you need to add water. Humidify (Only on panel) Touch this button to turn on/off left-right automatic oscillation function. Oscillation Long touch this button can adjust the up-down angle（0°/30°/60°/90°）...
-
Page 13: Maintenance
Maintenance External Clean the external surface 1-2 times a week using a clean cloth to remove dust and dirt. If the dirt is stubborn, soak the cloth in a neutral detergent before wiping. Water tank Clean the water sink and tank 1-2 times a week as water can cause minerals and organic matter to accumulate, affecting the function of the humidifier. - Page 14 Maintenance Filter When the smart mode button is flashing, it means you need to replace the filter. Follow the installation page to take the back cover off to replace the filter. After you install the back cover back to the machine, please long press the smart mode button and timer button on the panel at the same time until you hear a "ding"...
- Page 15 Maintenance How to pour out the water in the tank: 1. Take the cover off. 2. Pull out the tank, and you can remove the filter as your convenience. Note: The water tank is connected with power cables, please don't force it too hard. 3.
-
Page 16: Faq
Q： Why is the humidity button flashing? A：Open the back cover to check whether the water is empty. If yes, please add water. If not, please contact customer service to help. Q： Why is the smart mode button flashing? A：The filter need to be replaced. Follow the maintenance page to replace the filter. - Page 17 Q： Why is there scale in the water tank? A：Tap water contains minerals that can adhere to objects. Clean the water tank regularly. Q： Why is there interference with the TV remote control signal? A：Keep the machine 1m away from the TV or other objects that emit radio waves. Q：Why is the fire on the stove turning red? A：The composition of tap water can react with the flame, so keep the machine away from the stove.
-
Page 18: Product Specification
Product Specifications Product Name Humidifier with Fan Model Number KC-MH-8060A Fan Speed Medium High Max Mist Output 300ml/h Rated Power Power Supply AC 100V-120V~ Rated Frequency 50/60Hz Water Tank Capacity Coverage Area 300-600ft²/27-55m Size 9.84*9.84*23.6in/250*250*600mm N.W. 11 lb / 5 kg... -
Page 19: Warranty
Provide the warranty card and the order number. Describe the problems you are experiencing in detail and provide pictures or videos if possible. service@keecoon.com Send an email to Please note that we cannot provide warranty service if you are unable to provide the above information.
