KEECOON KC-MH-K20 User Manual

Cool mist ultrasonic humidifier

Advertisement

Quick Links

Cool Mist
Ultrasonic Humidifier
KC-MH-K20
User's Guide
Thanks for your purchase.
We provide a one-year warranty.
If any quality issues,
replacement or refund is available.
Please feel free to contact us via E-mail:
service@keecoon.com
This model is available in two colors.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KC-MH-K20 and is the answer not in the manual?

Questions and answers

Summary of Contents for KEECOON KC-MH-K20

  • Page 1 Cool Mist Ultrasonic Humidifier KC-MH-K20 User's Guide Thanks for your purchase. We provide a one-year warranty. If any quality issues, replacement or refund is available. Please feel free to contact us via E-mail: service@keecoon.com This model is available in two colors.
  • Page 3 Precautions Thank you for purchasing our humidifier KC-MH-K20 Please read this manual carefully before using and keep it for future reference. All pictures shown are for illustration purposes only. Actual products may vary due to product enhancement. For more installation information, please visit the official website link or scan the QR code: https://keecoon.com/pages/customer-instruction-manual...
  • Page 4: Table Of Contents

    Safety Guide Components Placement Installation Water filling &Use of Essential Oil Control Panel& Remote Control 10-11 Maintenance After Using the Humidifier 13-14 Product Specifications Warranty 16-17...
  • Page 5: Safety Guide

    Safety Guide Do not disassemble or modify the machine. Do not subject the machine to strong impacts. Keep a safe distance when the humidifier is spraying mist, especially if you have a sensitive respiratory tract. Turn off the machine before moving it. Do not connect the machine to a socket that exceeds the rated voltage or use an extension cable, as this may cause fire or electric shock.
  • Page 6 Safety Guide Use the machine at normal room temperature, which ranges from 5°C to 40°C. When the room temperature drops below 0°C, please pour out the water in the water tank and sink to avoid freezing and damaging the machine. Note: The above safety guide is for your reference only.
  • Page 7: Components

    Components Mist Outlet Main Body Cover Pump Connector Aroma Box Water Pipe Display Tank Handle ater Pump Water Tank Power Cord Main Body Remote Control Tube Fan Outlet Float Water Inlet Atomizers Water Outlet...
  • Page 8: Placement

    Placement Place the humidifier in a horizontal position that is more than 20 cm away from walls, furniture, household appliances, and other objects. Do not use the humidifier in the following situations to avoid water leakage, signal jamming, damage or injury: In direct sunlight.
  • Page 9: Installation

    Installation 1. Take out all parts of the humidifier, 2. Install the base. remove the protective bag from the water pump. 3. Please install the battery before use 4. Place the main body on the water tank properly (note that the battery needs to be prepared by yourself).
  • Page 10 Installation 5.Install the misting nozzle and extended tube as you like. Note: If the water pump fails to pump water, please try disassembling it along with the water pipe and then reinstalling them. To remove the pump, turn the connector counterclockwise, and to reinstall it, turn the connector clockwise.
  • Page 11: Water Filling &Use Of Essential Oil

    Water Filling & Use of Essential Oil Add water below 40°C to the water tank. Do not exceed the max water line. Do not let the water into the mist outlet to avoid machine failure. Do not add mineral water, plasma water, or tap water that has been left for a long time.
  • Page 12: Control Panel& Remote Control

    Control Panel & Remote Control The control panel and remote control allow you to operate the humidifier with ease. Here is a breakdown of the various functions: Digital Screen: The screen display will switch between Mist Level Indicator mist level and relative humidity(RH) percentage Humidity Function Light Function...
  • Page 13 Control Panel & Remote Control This button turns on the humidifier when pressed. The display will light up, and the humidifier will start working. Power This button allows you to set the humidity level between 40-90% in increments of 5%. The humidifier will automatically stop spraying mist Humidity when the surrounding humidity reaches the set value.
  • Page 14: Maintenance

    Maintenance External Clean the external surface of the humidifier 1-2 times a week using a clean cloth to remove dust and dirt. If the dirt is stubborn, soak the cloth in a neutral detergent before wiping. Make sure the main body is completely dry before use. Water Sink&...
  • Page 15 Maintenance Water Pipe If you notice sediment in the water pipe, you can clean it using a slim brush or contact our customer service to request a replacement. Follow these steps to clean or replace the water pipe: 1. Unplug the water pipe from the humidifier. 2.
  • Page 16: After Using The Humidifier

    After Using the Humidifier 1.Always unplug the device when not in use. 2. The humidifier requires regular cleaning. Please refer to and follow the instructions to clean the machine. 3.When the humidifier is not in use for 4. Do not attempt to repair or a long time or no one is at home, do adjust any electrical or not leave water in the water tank.
  • Page 17: Faq

    Q: Why doesn't the display light up after turning on the power? A:It's possible that water has entered the circuit board. Air-dry the main body for one day. If it still can't be turned on, please contact customer service via email. Q:Why is the mist output low? A:When the ambient humidity exceeds the set value, the machine will automatically stop spraying mist.
  • Page 18 Q:Why is there white powder around the humidifier? A:Tap water contains minerals that can adhere to objects. Clean the water tank regularly and keep precision instruments away from the humidifier to avoid damage. Q: Why is there scale in the water sink or tank? A:Tap water contains minerals that can adhere to objects.
  • Page 19: Product Specifications

    Product Specifications Product Name Ultrasonic Humidifier Model Number KC-MH-K20 Operation Mode Medium High Max Mist Output 300ml/h Rated Power Noise Coverage Area 1000 sq.ft 8.4*7.2*25.8 inches Size (not including extended tube) G.W. 5.07lb 1-12 hours Timer Safety Functions Waterless auto shut-off...
  • Page 20: Warranty Card

    Warranty Warranty Card Model Number KC-HM-K20 Warranty Period Within 1 year from the date of purchase Purchase date Year Month Date Name Address Customer Phone Number Store...
  • Page 21 Provide the warranty card and the order number. Describe the problems you are experiencing in detail and provide pictures or videos if possible. service@keecoon.com Send an email to Please note that we cannot provide warranty service if you are unable to provide the above information.
