Page 1: Sri Series 3D Camera
SRI Series 3D Camera ——Hardware User Manual V2.0... -
Page 2: Copyright Statement
The product information and images in this manual are for reference only. As the products are constantly updated, please refer to the actual products, SinceVision reserves the right of final interpretation and revision of this manual. SRI Series Hardware User Manual 2 / 25 ©2024 All rights reserved by SinceVision... - Page 3 The contents of this manual have been prepared with the aim of accuracy and precision. However, if you find any unclear, incorrect or ambiguous content, please contact our sales department. Any manual with missing pages or binding errors will be replaced by us. SRI Series Hardware User Manual 3 / 25 ©2024 All rights reserved by SinceVision...
- Page 4 For software debugging of the SRI-series 3D Camera, please refer to the "Edge-Imaging Software User Manual" and "SRI-series 3D Camera Communication Library Reference Manual" that come with this product. SRI Series Hardware User Manual 4 / 25 ©2024 All rights reserved by SinceVision...
-
Page 5: Document Version
Shenzhen SinceVision Technology Co., Ltd. www.sincevision.com Document Version Version Revision Date Revised Contents Number July 27, 2023 August 20th, 2024 August 26, 2024 October 9th, 2024 SRI Series Hardware User Manual 5 / 25 ©2024 All rights reserved by SinceVision... -
Page 6: Table Of Contents
Shenzhen SinceVision Technology Co., Ltd. www.sincevision.com Table of Contents SRI Series 3D Camera ............................1 ——Hardware Manual............................ 1 V1.0 ................................1 Chapter 1 Overview............................7 Introduction............................7 Features.............................. 7 Model Naming Description........................ 8 Chapter 2 Precautions............................9 Safety Precautions..........................9 2.1.1... -
Page 7: Chapter 1 Overview
10,000 contours per second and 32,000,000 points per second. SRI series 3D cameras have ultra-high dynamic range and can measure accurately from black plane with low reflectivity, to inclined plane or metal plane with high reflectivity at the same time. -
Page 8: Model Naming Description
50 ： Best working distance 50mm 60 ： Best working distance60mm 80 ： Best working distance 80mm 140 ： Best working distance 140mm 240 ： Best working distance 240mm SRI Series Hardware User Manual 8 / 25 ©2024 All rights reserved by SinceVision... -
Page 9: Chapter 2 Precautions
BE CAREFUL When used in combination with other devices, the function and performance of this product may decrease depending on the usage conditions and surrounding environment. SRI Series Hardware User Manual 9 / 25 ©2024 All rights reserved by SinceVision... -
Page 10: Safety Precautions For Laser Products
Ensure that the laser beam path is away from human eye height when installing laser products. This product does not have a mechanism to turn off laser irradiation during disassembly. Do not disassemble it. SRI Series Hardware User Manual 10 / 25 ©2024 All rights reserved by SinceVision... -
Page 11: Precautions For Use
Shenzhen SinceVision Technology Co., Ltd. www.sincevision.com Precautions for Use To ensure proper use and avoid malfunctions in SRI series 3D camera products, please observe the following precautions. 2.2.1 Safe Operation Please use the power supply correctly according to regulations. Otherwise, it may cause fire, electric shock, or malfunction. -
Page 12: Malfunction Handling
BE CAREFUL is severe, please use a cotton cloth dipped in diluted neutral cleaning agent, wring it out, then clean the device with the cotton cloth. SRI Series Hardware User Manual 12 / 25 ©2024 All rights reserved by SinceVision... -
Page 13: Chapter 3 Quick Start Guide
3-merter cable SCB-HCAM-HIO-3m 3-merter cable SCB-HCAM-HNET-3m M4x60 Cap head inner hexagon screw M4 flat gasket Quick Start Guide for SRI series 3D camera Inspection-passed card for SRI Series 3D camera Warranty card for SRI Series 3D camera SRI Series Hardware User Manual 13 / 25 ©2024 All rights reserved by SinceVision... -
Page 14: Installation Environment
Installation hole for metal light Used to install the light shielding metal plate onto the camera. Please shielding plate do not use it to secure the camera. SRI Series Hardware User Manual 14 / 25 ©2024 All rights reserved by SinceVision... -
Page 15: Camera Installation
Figure 3-3 Schematic diagram of the laser path obstructed SRI Series Hardware User Manual 15 / 25 ©2024 All rights reserved by SinceVision... - Page 16 CAUTION To facilitate heat dissipation of the sensor head, please install the sensor head on a metal plate. SRI Series Hardware User Manual 16 / 25 ©2024 All rights reserved by SinceVision...
-
Page 17: Chapter 4 Hardware Connection
Please ensure that the minimum bending radius of the sensor head cable is BE CAREFUL more than 30mm. When using drag chains, if it is not specified, please choose products above R100. SRI Series Hardware User Manual 17 / 25 ©2024 All rights reserved by SinceVision... -
Page 18: Connect The Camera And Power Supply
The power for DC24V is greater than or equal to 30W. Step 1: Connect the red+24V and black 0V leads from the I/O cable (SCB-HCAM-HIO) to the DC24V power supply. SRI Series Hardware User Manual 18 / 25 ©2024 All rights reserved by SinceVision... -
Page 19: I/O Wiring
Automatically stop batch processing after collecting the specified number of rows, or call the API to stop batch processing. The signal timing diagram is shown in Fgure 4-6 Level continuation mode. SRI Series Hardware User Manual 19 / 25 ©2024 All rights reserved by SinceVision... - Page 20 PLC and servo drive are in a power-off state. Hot BE CAREFUL plugging and unplugging I/O cables can cause damage to the camera. SRI Series Hardware User Manual 20 / 25 ©2024 All rights reserved by SinceVision...
-
Page 21: Definition Of I/O Interface Signals
PE is an all-in-one metal shell. Note: When the voltage of "Encoder_A+/Trigger_in+" and "Encoder_B+" is 5V/12V/24V, a resistor (100R/1K/2K) needs to be connected in series. SRI Series Hardware User Manual 21 / 25 ©2024 All rights reserved by SinceVision... -
Page 22: Chapter 5 Definition Of The Led Indicator
Powered on and the power supply is Power indicator, blue normal No power or abnormal power supply Flashing Normal operating Running status indicator, green Abnormal Error occurred Error status indicator, red Normal SRI Series Hardware User Manual 22 / 25 ©2024 All rights reserved by SinceVision... -
Page 23: Chapter 6 Appendix
Input circuit of this device output (PNP) Note 1: The voltage level between 7 and 22V is uncertain status and the logic level cannot be accurately determined. SRI Series Hardware User Manual 23 / 25 ©2024 All rights reserved by SinceVision... - Page 24 Note 2: The voltage level between 3.6 and 22V is uncertain status and cannot be accurately determined. When the input voltage is 5/12/24V, a series resistor (100R/1K/2K) is required. Trigger_in+/Trigger_in- and Encoder_A+/Encoder_A- are multiplexed. SRI Series Hardware User Manual 24 / 25 ©2024 All rights reserved by SinceVision...
-
Page 25: Electrical Parameters Of Digital Output Signals
Internal circuit and wiring diagram Output circuit of this device PLC input circuit (common anode) Output circuit of this device PLC input circuit (common anode) SRI Series Hardware User Manual 25 / 25 ©2024 All rights reserved by SinceVision...
