SAFETY INSTRUCTIONS WARNING: • To avoid risk of electrical shock, be sure to shut off power at the main fuse or circuit breaker panel box before installing or servicing this fixture. Turning off the electrical power by using the light switch only is not sufficient to prevent electrical shock hazard. •...
HARDWARE KIT CONTENTS PART DESCRIPTION QUANTITY Wire Connectors Blade Screws and Washers 10 each Machine Screws and Lock Washers 2 each Wood Screws and Washers 2 each Balance Kit Pull Chain Extensions and Fobs 2 each NOTE: For your convenience some extra hardware may be included. The quantity listed above is the number required for installation.
Page 5
ASSEMBLY INSTRUCTIONS A: 16.3 in. B: 9.5 in. C: 7.7 in. D: 5.7 in. (Note: Dimensions with 6” downrod) Choose one of the following mounting options: Downrod Mount is best suited for ceilings 8 ft. or higher. For taller ceilings you may want to use a longer downrod (sold separately).
Page 6
ASSEMBLY INSTRUCTIONS Turn OFF the electrical power at the main fuse or circuit breakers. NOTE: Before continuing installation, confirm that the power is still turned off at the main circuit breaker or by removing the correct fuse. Turning the power off using a wall switch is not sufficient to prevent electrical shock.
Page 7
ASSEMBLY INSTRUCTIONS INSTALLING THE FAN BLADES 4. Put the blade bracket onto the flywheel. Align the blade bracket Flywheel mounting holes with the mounting holes in the flywheel, attach the blade to the flywheel using the (2) blade screws and washers provided, and tighten (2) blade screws to secure.
Page 8
ASSEMBLY INSTRUCTIONS 6. Feed the entire length of the 3 wires coming from the fan through the bottom of the downrod and out the top of the downrod ball. Insert the downrod into the yoke and reinstall the downrod pin and downrod clip. Then re-tighten the two set screws.
Page 9
ASSEMBLY INSTRUCTIONS Use the supplied wire connectors to connect the fan wires to the power supply wires according to the wiring diagram and following instructions: • Connect the WHITE wire from the fan to the WHITE wire coming from the ceiling. •...
Page 10
ASSEMBLY INSTRUCTIONS 9. Locate the (2) screws on underside of hanging bracket and loosen screws. Place rounded part of slotted hole in canopy over the loosened screws in hanging bracket and push up. Make sure all wires are tucked into the canopy and will not be pinched.
Page 11
ASSEMBLY INSTRUCTIONS INSTALLING THE LIGHT KIT SHADE 12. Position the light kit shade to line up with the bottom of the light kit. While holding the glass up to the bottom of the light kit, turn the glass clockwise until the notch in the glass slips into the light kit channel.
Page 12
OPERATING INSTRUCTIONS OPTIMIZING YOUR FAN’S PERFORMANCE USING THE REVERSE SWITCH Use the fan reverse switch, located on the side of the light kit housing, to optimize your fan for seasonal performance. Using a ceiling fan will allow you to raise your thermostat setting in summer and lower your thermostat setting in winter without sacrificing your comfort.
TROUBLESHOOTING FAN DOES NOT START: • Check the circuit breaker and confirm the power is ON. • Make sure the wall switch is ON. • Check that the motor reversing switch is correctly engaged and set to left or right position. Fan will not run if switch is in the middle.
To obtain service please contact Blue Mountain Fans Customer Service online or by phone as noted below. Do not attempt to ship your fan or any parts to Blue Mountain Fans without prior written approval as otherwise your delivery will be refused. Blue Mountain Fans shall not be liable for any incidental, consequential, or special damage arising at or in connection with product use or performance except as may otherwise be accorded by law.
