Scorpion Sports APEX EXO-RACE AIR Tech Manual

FEATURE SUMMARY
1 Lite Force Carbon™ Matrix Shell
Developed from premium 12K chopped carbon strands, expertly fused into our proprietary Carbon
Mat. This intricate configuration ensures optimal energy dissipation on impact from any angle of
impact, laying the foundation for unparalleled protection.
Optical Class 1 Face Shield Technology/ Pinlock Ready Face Shield
2 ®
APEX Series Optical Class 1 shield features varied thicknesses throughout the lens which
enhances visual accuracy, reduces glare, and prevents distortion. Additionally, its specially
designed shape was developed to improve aerodynamics and reduce wind noise during rides.
3
Cool Tech™ Liner
Engineered to redefine comfort thanks to a unique adjustable crown pad design and an
advanced material composition that offers exceptional comfort and moisture wicking
properties.
4 Pinlock Ready FaceShield
®
The shield is with Anti-Scratch hardened coating, and is ready for Pinlock max
vision system, the world's best fog free resistant system.
5 Variable rear spoiler
Variable rear spoiler is helping for reducing drag of vortex and improving downforce while
high speed riding. In racing position, this variable rear spoiler would help to fill up the gap
between helmet and hump so that the racer would have better air channel.
6
Dual Shield Locker (Step 1)
Step 1 lock automatically engages when the shield is firmly closed.
Dual Shield Locker (Step 2)
Step 2 lock provides FRHPhe-02 (FIM 2) compliant dual shield lock
closure. Note: Step 2 lock must be manually engaged by the user.
8 Speaker Pockets
Speaker ducts designed into the EPS allow compatibility with
communication unit speakers.
9 AirFit ® Liner Inflation System
Inflatable cheek pad bladders for a personalized fit.
1
12
1
11
2
4
3
6
LINE ARTS SHOWN IN THIS MANUAL
9
ARE FOR REFERENCE ONLY AND MAY
VARY FROM ACTUAL PRODUCT.
Emergency Release System
Tabs located under the neck roll allow easy removal of the cheek pads by emergency
medical personnel thus allowing easier removal of the helmet.
Vortex generator
11
Specifically engineered vortex pattern manges surface airflow reducing both lift and drag
resulting in enhanced aerodynamics.
FlexGel
12
Newly developed gel type material is engineered to absorb the impact forces from
oblique impacts mitigating the risk of concussions.
ENGLISH
DUAL SHIELD LOCKER (STEP 1)
5
11
8
1
2
Push-in the shield lock button and keep it
pushed-in while lifting the shield upward.
DUAL SHIELD LOCKER (STEP 2)
LOCKED
RELEASED
2
