Sony ICF-M3908 Service Manual

SERVICE MANUAL
ICF-M3908
AEP Model
E Model
TUNES TIME
BAND/StANDBY
SPECIFICATIONS
Frequency range
Antennas
Speaker
Power output
Output
FM |87.5-108 MHz
(0.05 MHz scan step)
MW |531-1,602 kHz (9 kHz scan step)
530-1,610 kHz (10 kHz scan step)
SW |5.80-6.40 MHz (5 kHz scan step)
FM/SW: Telescopic antenna
MW: Built-in ferrite bar antenna
Approx. 7.7 cm (3'/s inches) dia.
280 mW (at 10% harmonic
distortion)
Earphone jack (minijack)
Power requirements 4.5 V DC
Battery life
Dimensions
Weight
Supplied accessory
Three R6 (size AA) batteries
DC IN 4.5 V jack accepts:
Sony AC-E45M AC power adaptor
(optional)
Sony DCC-E145L car battery cord
(optional) for use with 12 V car
battery
Approx. 15 hours of listening for 4
hours a day at a normal volume
using Sony batteries SUM-3 (NS)
Approx. 195 x 95 x 32.5 mm (w/h/d)
(7%x3%x1 ie inches)
not incl. projecting parts and
controls
Approx. 430 g (15.2 02) incl.
batteries
FM antenna coupler (1. Models for
Netherlands and Scandinavia)
Design and specifications subject to change without
notice.
Note
regarding interference suppression.
FEATURES
* The radio can be turned on at the preset time.
Note on MW tuning interval
MW tuning interval
10 kHz
9 kHz
Area
North American countries
Other countries
FM/MW/SW 3 BAND
PLL SYNTHESIZED RECEIVER
