- Page 1 User Manual Adjustable Solar Panel Tilt Mount MODEL: RS-TM4 / RS-TM6...
-
Page 2: Components List
COMPONENTS LIST adjustable front leg adjustable rear leg screw rubber washer -01-... -
Page 3: Installation Steps
INSTALLATION STEPS Step 1 Follow image: use the pre-assembled bolt to install both adjustable front legs to the frame of panel; -02-... - Page 4 Step 2 Follow image: aligning rubber washers then underlay the adjustable front leg, use 2pcs ST6.3*80mm screw to lock adjustable front leg on the surface of ground; -03-...
- Page 5 Step 3 Follow image: use pre-assembled M8 bolt to lock top of adjustable rear leg (the side includes aluminum angular) and panel; -04-...
- Page 6 Step 4 Settle the distance between front and rear leg according to the actual angle, follow image: use ST6.3*80mm screw to lock both base of rear leg and rubber washer to surface of ground; -05-...
- Page 7 Step 5 Follow image a, loosen both bolts can adjust the length of rear leg, to adjust angle; after that, follow image b, tighten up both bolts to fix the length of rear leg. -06-...
- Page 8 Step 6 Installation of the brackets is completed. -07-...
- Page 9 NOTICE This installation is only applicable on our this product. Unless there is no other way, please install strictly according to our providing install steps. Contact us if there is any changes of installation steps. 1. For your safety please strictly comply with the operating procedures of the use of tools.
- Page 10 1-800-831-9889 support@richsolar.com www.richsolar.com 5550 Jurupa St, Ontario, CA 91761...
