Equator BIC 365 CC ED Owner's Manual

Hide thumbs

Advertisement

Table of Contents

INDUCTION COOKTOP
Built-in
Model: BIC 365 CC ED
DO NOT RETURN TO STORE!
Read the instructions carefully and keep for
STOP
future reference. Information maybe updated
HAVE QUESTIONS OR NEED SERVICE?
from time to time so please refer to the
Service@ApplianceDesk.com
website for the latest version of the manual.
1-800-776-3538

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIC 365 CC ED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Equator BIC 365 CC ED

Summary of Contents for Equator BIC 365 CC ED

  • Page 1 INDUCTION COOKTOP Built-in Model: BIC 365 CC ED DO NOT RETURN TO STORE! Read the instructions carefully and keep for STOP future reference. Information maybe updated HAVE QUESTIONS OR NEED SERVICE? from time to time so please refer to the Service@ApplianceDesk.com...
  • Page 2 Insufficient spacing around appliance Website: EquatorAppliances.com Chat-AI 1. Scan QR Code Open Smart Phone Open Camera Click the Link 2. Register online at ApplianceDesk.com/Warranty 3. QR Code is also used to obtain Product Information, Manuals and Updates...
  • Page 3 Keep Warm function Pause function for interrupted cooking Lock function for safety Easy to clean glass surface Specifications Table Model BIC 365 CC ED Electrical 240V / 60Hz Number of Burners Type of Burners 5 Induction Total Power / Levels...
  • Page 4 Safety This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. SAVE THESE INSTRUCTIONS...

  • Page 5: Installation

    Installation Follow cutout dimensions of the countertop as indicated on the diagram. Before cutting out the countertop, check that the dimensions in the diagram correspond to the dimensions of the product. Ensure the work surface is heat-resistant and is at least 1.2 inch (3 cm) thick. Ensure the safety distance between the sides of the cooktop and the inner surfaces of the countertop is at least 0.12 inch (0.3 cm).
  • Page 6 Ensure that the following conditions are met for adequate ventilation of the cooktop and that the supply and exhaust air is not blocked: The safety distance between the cooktop and the cabinet or the vent hood should be at least 30 inch. If the cooktop is installed above an oven, the oven must have its own fan.

  • Page 7: Electrical Connections

    Electrical Connections The cooktop must connect to a separate, grounded wire, single phase, AC only electrical supply with its own circuit breaker. These appliances must be installed in accordance with National Electrical Codes, as well as all state, municipal and local codes.

  • Page 8: Cooktop Features

    Cooktop Features 5. Right Rear Burner 1. Glass Surface 6. Right Front Burner 2. Left Rear Burner 3. Center Burner 7. Control Panel 4. Left Front Burner 8. Chat AI Code Main Control Panel 4. Pause 1. Power 2. Child Lock 5.

  • Page 9: Operating The Cooktop

    Operating the Cooktop Ensure the cooktop is plugged into an electrical outlet. Place suitable cookware onto the cooktop. Main Power Press the Power icon . This powers on the whole cooktop. You will hear a beep and see flashing lines - on the display next to both the burners. Burners To select the burner to use and the power level, press the burner icon for the desired burner.

  • Page 10: Maintenance

    Power Boost To heat a burner to a high temperature quickly, use the Power Boost feature. Press the PB icon and the display panel will show “P” while the Power Boost is on. The Power Boost is 1800 W and it will remain on for 5 minutes. Then the heat level will reduce to 9 (1400 W).

  • Page 11: Troubleshooting

    Troubleshooting In most cases, when your Cooktop fails to work, the problems arising can be easily solved without having to call for a technician. Before calling for assistance, always check these points. Repairs should only be done by an authorized service agent. Problem Possible Cause Solution...
  • Page 12 Equator Advanced Appliances USA, founded in 1991, offers Efcient, High-Quality, and Innovative household appliances. Our Mission is to simplify domestic chores and save Time, Space, and Energy. Our Vision is to enhance our Customer’s Quality of Life!
