- Page 1 User Guide Pump-A-Wear Pump-A-Wear 2x24mm Hands-Free, Wearable Breast Pumps with Silicone Flanges *17, 19, 21 and 27mm Attachments Sold Separately...
-
Page 2: Table Of Contents
Table of Contents Important Safety Information What’s in the Box Cleaning How to Assemble Pump Motor Instructions How to Pump Ending Your Session Charging Your Breast Pump Finding the Correct Flange Fit Troubleshooting Technical Information Warranty Electromagnetic Compatibility Compliance Statement Information Replacing Your Pump-A-Collect Parts... -
Page 3: Indications For Use
Idaho Jones® Pump-A-Wear INDICATIONS FOR USE The Idaho Jones Pump-A-Wear Wearable Breast Pump with Silicone Flange is suction device intended to express and collect milk from a lactating person’s breasts. This pump is intended for a single user. -
Page 4: Important Safety Information
Important Safety Information Read this user guide carefully before using your breast pump. Save the user guide for future reference. Failure to follow the instructions and safety information included in this guide can lead to danger from the device. • When using any electrical products, basic safety precautions should always be followed. - Page 5 Important Safety Information Important Safety Information Important Safety Information (cont’d) • Make sure all parts are assembled correctly before pumping. • This product should never be left unattended when plugged in. • Keep the cord away from heated surfaces. • Always unplug electrical product immediately after use. •...
-
Page 6: What's In The Box
What’s in the Box: 2x Pump motors 2x Membranes 2x Valve bases 2 Collection cups (6Oz/180ml) 2x Silicone breast shields / flanges (2x 24mm) 2x Valves 2x USB cables 2x Bra adjustment straps... -
Page 7: Cleaning
Cleaning BEFORE FIRST USE • Disassemble all parts and put the pump motors aside. • Wash all silicone and plastic parts in warm soapy water. • Rinse well with clean water. • Submerge all parts in a pot of water and boil for no longer than 3 minutes. -
Page 8: After Each Use
Cleaning (cont’d) AFTER EACH USE • Put the pump motors aside. • Disassemble all other parts (collection cup, silicone breast shield, insert, valve, valve base and membrane). • Rinse with cold clean water soon after use. • Wash in warm soapy water. ◦Valves can be cleaned by gently rubbing between fingers (do not use brush). -
Page 9: How To Assemble
How to Assemble... - Page 10 How to Assemble (cont’d) IMPORTANT NOTE: The pump motor will not work while still charging.
-
Page 11: Pump Motor Instructions
Pump Motor Instructions Power button Level display Timing display Battery level indicator Expression mode display Mode selection button Massage mode display Level down button Auto mode display Level up button... -
Page 12: How To Pump
How To Pump Correct Placement PLACEMENT IN BRA IDEAL BRA FIT Correct nipple alignment and a supportive bra that keeps the cups securely in place will ensure your pumping sessions are comfortable and effective. Double check that you have a good seal between the flange and your skin. - Page 13 How To Pump (cont’d) Position for Expressing IDEAL GOOD UPRIGHT SLIGHTLY FORWARD MAY LEAK MAY LEAK RECLINING BENDING FORWARD WON’T WORK LAYING BACK (OR SIDE)
- Page 14 How To Pump (cont’d) Turning on the pump and choosing the right program Press the power button to start the breast pump. Massage Expression Auto This pump offers three modes. Use the “M” button to toggle between different modes. 1. Press “M” once for “ ”...
- Page 15 How To Pump (cont’d) Turning on the pump and choosing the right program 2. When you are in Massage mode, press “M” again to switch to “ ” (Expression) mode. Expression mode comes with 12 levels. You can increase or decrease the suction strength by using the “+”...
-
Page 16: Ending Your Session
Ending Your Session The pump shuts off automatically after 30 mins. If you would like to end your pumping session before 30 minutes, please press the power button to switch off your pump. After the pump is turned off, break the seal between the pump and your breast and carefully remove the pump from your breast. - Page 17 Ending Your Session (cont’d) Place the full cups on a flat surface until you are ready to transfer your milk. Pour the milk out of the dedicated hole at the top of the collection cups. Warning! There might be some milk remaining in the nipple hole in the middle.
-
Page 18: Charging Your Breast Pump
Charging Your Breast Pump Check your battery status indication on your pump after each pumping session. If your pump is turned off, please turn it on by pressing the power button and you will be able to see the battery status indicator. Battery Status Indicator BATTERY STATUS... - Page 19 Charging Your Breast Pump (cont’d) 1. Plug the charging tip of your charging cable into the pump’s charging port. 2. Plug the USB tip of your charging cable into a USB wall charger. not provided 3. Plug your USB charger into your power outlet. NOTE: We recommend using a certified DC 5V/1A wall charging adapter that meets IEC 60950 standard requirements.
-
Page 20: Finding The Correct Flange Fit
Finding the Correct Flange Fit The Pump-A-Wear pumps come with a 24mm flange. Based on your nipple measurement, if you need to size up or down your flange, you can get: • 2x 17mm, 2x 19mm or 2x 21mm inserts (that work with 24mm flanges) •... -
Page 21: Troubleshooting
Troubleshooting We summarize here the most common issues you can encounter while using your Pump-A-Wear pump. If you are not able to solve the issue with the information below, please email us on hello@idaho-jones.com and we will do everything we can to help you. -
Page 22: Technical Information
Technical Information Input 100-240V~ 50/60Hz Power Output DC 5V/1A Li-ion Polymer Battery Battery 3.7V, 1000mAh, 3.7Wh Massage mode cycle speed 70-114 cycles per minute Massage mode vacuum 35-110 mmHg Expression mode cycle speed 23-90 cycles per minute Expression mode vacuum 35-245 mmHg Auto shut off 30 minutes... -
Page 23: Warranty
Warranty There is a one-year warranty for the unit from the date of purchase. Proof of purchase in the form order number evidencing that the product is within the warranty period must be presented to obtain warranty. For warranty service, contact hello@idaho-jones.com This is a single user product. -
Page 24: Electromagnetic Compatibility Compliance Statement Information
Electromagnetic Compatibility Compliance Statement Information The Pump-A-Wear Breast Pump may be used at home, office, or other general areas. Special consideration should be given to use: 1. During Medical Procedures: Do not use the Pump during any medical procedure or during imaging. For example, do not use pump during RF ablation of a skin anomaly, x-ray, MRI, or ultrasound. -
Page 25: Replacing Your Pump-A-Collect Parts
Replacing Your Pump-A-Collect Parts VALVES MEMBRANES Replace every 1-3 months depending on frequency of use. To get the most out of your parts: • Do not steam sterilize or boil after first use. • Do not wash them in the dishwasher. •... - Page 26 COMPLETE FREEDOM TO PUMP ANYWHERE ANYTIME!
