- Page 1 Temperature (TMP) Sensor User Manual...
- Page 2 ATTENTION Please read this datasheet before using your biosignalsplux sensor The information contained in this document has been carefully checked and were made every effort to ensure its quality. PLUX reserves the right to make changes and improvements to this manual and products referenced at any time without notice.
-
Page 3: Table Of Contents
1.5. Applications........................5 1.6. Transfer Function (Conversion Formula) ................5 1.7. Physical Characteristics ...................... 6 2. Using the Temperature (TMP) Sensor with biosignalsplux & OpenSignals ......... 7 2.1. Connecting the sensor to biosignalsplux Systems ..............7 2.1.1. biosignalsplux 4-Channel Hubs ....................7 2.1.2. -
Page 4: General Information
0°C and 50°C temperature range. Figure 1: biosignalsplux TMP sensor 1.2. Typical Unfiltered Sensor Output Figure 2 shows a typical unfiltered TMP sensor output. The raw digital sensor values received from the biosignalsplux device ranged between 0 and 2 -1 (n=sampling resolution) were converted into the original unit of measurement of this sensor (˚C) using the transfer function... -
Page 5: Sensor Specifications
-1 (n=sampling resolution, usually 8-bit or 16-bit) and streamed in the raw digital format. In most applications, the original physical unit of the acquired TMP signal is preferred or required. The raw digital sensor samples can be converted back into Celsius degrees (ºC) using the following formulas: ������... -
Page 6: Physical Characteristics
> A1: 105.0 ± 0.5cm > A2: 90.0 ± 0.5cm > S: 0.3 ± 0.1cm > Available sleeve colors: White, Black, Blue, Green, Red, Yellow, Gray, and Brown Figure 3: Physical characteristics of the standard TMP sensor. 6 of 16... -
Page 7: Using The Temperature (Tmp) Sensor With Biosignalsplux & Opensignals
2.1. Connecting the sensor to biosignalsplux Systems 2.1.1. biosignalsplux 4-Channel Hubs The biosignalsplux TMP sensor is compatible with all 4 analog input channels of the 4-channel biosignalsplux hub, but incompatible with the reference/ground port. Connect the sensor to an analog input to use it with this device. -
Page 8: Biosignalsplux Solo & Single-Channel Openban Devices
The biosignalsplux TMP sensor is compatible with the analog input channel of the biosignalsplux Solo (openBAN) device. Connect the sensor to the analog input channel to use it with this device. Figure 6: Connect the TMP to the analog input channel of the biosignalsplux Solo (openBAN). 2.2. Configuring the Sensor in OpenSignals Download OpenSignals https://support.pluxbiosignals.com/knowledge-base/introducing-opensignals-revolution/... - Page 9 TEMP from the dropdown menu highlighted in the next screenshot. Figure 9: Set the channel type of the channel you have your TMP sensor connected to TEMP. Activate the channel for acquisition by clicking on the circle next to the channel type (must be blue).
- Page 10 Temperature (TMP) User Manual Figure 10: Start the acquisition whenever you’re ready. 10 of 16...
-
Page 11: Scientific Publications Using The Temperature Sensor
User Manual 3. Scientific Publications Using the Temperature Sensor The following scientific is only a small selection extracted from the list of available publications using biosignalsplux. Please visit the following website to access the entire up-to-date list. biosignalsplux Publications https://support.pluxbiosignals.com/1352-2/ Publications J. -
Page 12: Safety & Maintenance
The user must not place the device in the microwave. The user must not insert objects into the holes of the device. The user should not open the biosignalsplux device or its accessories. The repair of the same should be only done by properly authorized PLUX personnel. -
Page 13: Transportation And Storage
Please follow these recommendations to ensure safe transportation and storage of your biosignalsplux equipment and sensors to prevent any damaging of your system. The biosignalsplux equipment and sensors should be stored in the original box in a dry place when those are not being used. - Page 14 Temperature (TMP) User Manual More information on cleaning instructions can be found here: https://support.pluxbiosignals.com/knowledge-base/how-do-i-clean-my-plux-products/ 14 of 16...
-
Page 15: Ordering Guides, Regulatory & Legal Information
5.4. Regulatory Disclaimer biosignalsplux products are intended for use in life science education and research applications; they are not medical devices nor are they intended for medical diagnosis, cure, mitigation, treatment or prevention of disease. We expressly disclaim any liability whatsoever for any direct,... - Page 16 Temperature (TMP) User Manual PLUX Wireless Biosignals S.A. Headquarters Av. 5 de Outubro, n° 70 – 2° 1050-059 Lisboa Portugal tel.: +351 211 956 542 For support visit support.pluxbiosignals.com For sales visit www.pluxbiosignals.com or contact sales@pluxbiosignals.com 16 of 16...
