Summary of Contents for biosignalsplux ECG
- Page 1 Electrocardiography (ECG) Sensor User Manual...
- Page 2 ATTENTION Please read this datasheet before using your biosignalsplux sensor The information contained in this document has been carefully checked and were made every effort to ensure its quality. PLUX reserves the right to make changes and improvements to this manual and products referenced at any time without notice.
- Page 3 1.7. Electrode Connections & Sleeve Color Meanings ..............6 1.8. Physical Characteristics ...................... 6 2. Sensor Application Notes ........................7 3. Using the Electrocardiography (ECG) Sensor with biosignalsplux & OpenSignals ...... 8 3.1. Connecting the sensor to biosignalsplux Systems ..............8 3.1.1. biosignalsplux 4-Channel Hubs ....................8 3.1.2.
- Page 4 This sensor can be used to extract heart rate data and other ECG features, enabling its application in research fields such as biomedical, biofeedback, psychophysiology, and sports, among many others.
- Page 5 - 1 (n=sampling resolution, usually 8-bit or 16-bit) and streamed in the raw digital format. In most applications, the original physical unit of the acquired ECG signal is preferred or required. The raw digital sensor samples can be converted back into millivolt (mV) using the following formulas: ������...
- Page 6 Sensor also available with A2 and A3 with 30cm cable lengths. Custom cable lengths for A1, A2, and A3 are possible. For custom lengths, please contact our operations team via sales@pluxbiosignals.com. Figure 3: Physical characteristics of the standard Electrocardiography (ECG) sensor. 6 of 18...
- Page 7 1.5cm (+ & -) reference). and 3 cm (reference). After placing the ECG electrodes correctly on the body, connect the electrode cables of the ECG sensor according to one of the following configurations: Table 1: ECG sensor electrode and electrode placement connection.
- Page 8 Such sensors can lead to an increase in baseline noise due to the lack of a reference electrode but can be an alternative to the 3-electrode sensor for applications in which a simplified ECG sensor can be useful (e.g. for the extraction of heart rate data only).
- Page 9 Electrocardiography (ECG) User Manual Figure 7: ECG compatible biosignalsplux channels (green checkmarks). 9 of 18...
- Page 10 The biosignalsplux ECG sensor is compatible with the analog input channel of the biosignalsplux Solo (openBAN) device. Connect the sensor to the analog input channel to use it with this device. Figure 8: Connect the ECG to the analog input channel of the biosignalsplux Solo (openBAN). 3.2. Configuring the Sensor in OpenSignals (r)evolution Download OpenSignals https://support.pluxbiosignals.com/knowledge-base/introducing-opensignals-revolution/...
- Page 11 ECG from the dropdown menu highlighted in the next screenshot. Figure 11: Set the channel type of the channel you have your ECG sensor connected to, to ECG. Activate the channel for acquisition by clicking on the circle next to the channel type (must be blue).
- Page 12 Electrocardiography (ECG) User Manual Figure 12: Start the acquisition whenever you’re ready. 12 of 18...
- Page 13 Electrocardiography (ECG) User Manual 4. Scientific Publications The following scientific resource elements is only a small selection extracted from the list of available publications using biosignalsplux. Please visit the following website to access the entire up-to-date list. biosignalsplux Publications https://support.pluxbiosignals.com/1352-2/ Publications Short List C.
- Page 14 The user must not place the device in the microwave. The user must not insert objects into the holes of the device. The user should not open the biosignalsplux device or its accessories. The repair of the same should be only done by properly authorized PLUX personnel.
- Page 15 Please follow these recommendations to ensure safe transportation and storage of your biosignalsplux equipment and sensors to prevent any damaging of your system. The biosignalsplux equipment and sensors should be stored in the original box in a dry place when those are not being used.
- Page 16 Electrocardiography (ECG) User Manual More information on cleaning instructions can be found here: https://support.pluxbiosignals.com/knowledge-base/how-do-i-clean-my-plux-products/ 16 of 18...
- Page 17 6.4. Regulatory Disclaimer biosignalsplux products are intended for use in life science education and research applications; they are not medical devices nor are they intended for medical diagnosis, cure, mitigation, treatment or prevention of disease. We expressly disclaim any liability whatsoever for any direct,...
- Page 18 Electrocardiography (ECG) User Manual PLUX Wireless Biosignals S.A. Headquarters Av. 5 de Outubro, n° 70 – 2° 1050-059 Lisboa Portugal tel.: +351 211 956 542 For support visit support.pluxbiosignals.com For sales visit www.pluxbiosignals.com or contact sales@pluxbiosignals.com 18 of 18...
