WAC InvisiLED Duet T24-DU Installation Instruction

INSTALLATION INSTRUCTION
InvisiLED ® Duet
T24-DU
SAFETY INSTRUCTION
IMPORTANT: NEVER attempt any work without shutting off the electricity.
•
Always turn off power at fuse box prior to installation to prevent electrical
shock.
•
Intended for indoor use. Dry and damp locations.
•
For installation and serviced by a qualified, licensed electrician.
•
Install in accordance with national electric code, and local regulations.
CAUTION – TO REDUCE RISK OF FIRE AND ELECTRICAL SHOCK
•
Read all instructions before installing.
•
Handle product with care.
•
Do not conceal or extend exposed conductors through a building wall
•
To reduce the risk of fire and burns, do not install this lighting system
where the exposed bare conductors can be shorted or contact any
conductive materials
•
To reduce the risk of overheating and potential fire risk, make sure all
connections are tight.
•
Do not install any fixture assembly closer than 6 in. from any curtain, or
similar combustible material.
•
Do not modify or disassemble product beyond instructions or warranty
will be void.
•
Failure to follow safety warnings, and installation instruction will void the
warranty
WIRING AND INSTALLATION:
1. Please refer to installation diagrams shown on next page.
Determine the number of separately powered runs needed. Calculate the number of power supplies.
Maxmimum run length:
Power consumption:
2. Measure the length of each run and round it off to the nearest 4-inch interval. Determine the necessary quantities of 1-ft, 5-ft, 10-ft and nearly longest
available length in sections.
3. Count the number turns in the runs in order to determine the number of L, X, and Y connectors.
4. If making lateral turns at angles other than 90°, determine the number of joiner cables necessary to make the lateral adjustment.
5. Connect to Hard-wire power supply
•
Power supply must be installed away from heat sources and accessible for service
•
Power supply is UL listed. The power supply box has a separate line volt, and low volt wiring compartments. Trade size knock out are provided on both
compartments. Connect building wires to like color transformer wires with wire nuts.
•
Building ground wire my be green or un-insulated, and attaches to green wire from power supply box.
6. Connect the output lead-wire with screw-in type connector of the power supply with the InvisiLED® tape or lead wires, to form straight lines or turns
around the installation surface.
7. LED sections may be cut every 4" and reconnect using screw-in type connector
8. On smooth surfaces, the included adhesive is sufficient in most applications.
However if mounting surface is a porous or textured surface, then use a Mounting Clip every 6 inches to reinforce the installation.
Waclighting.com
Scan the QR code on the right to access detailed information and technical assistance for WAC Home
Phone (800) 526.2588
product features and functionality.
Fax (800) 526.2585
WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement
DU1: 60' per run with 96W power supply, 50' per run with 60W power supply
DU2: 40' per run with 96W power supply, 27' per run with 60W power supply
DU3: 30' per run with 96W power supply, 17' per run with 60W power supply
DU4: 20' per run with 96W power supply, 13' per run with 60W power supply
DU6: 15' per run with 96W power supply, 11' per run with 60W power supply
DU10: 10' per run with 96W power supply, 7' per run with 60W power supply
DU1: 1.2 Watts/ft
DU2: 2.3 Watts/ft
DU3: 3.5 Watts/ft
DU4: 4.7 Watts/ft
DU6: 5.4 Watts/ft
DU10: 8.3 Watts/ft
•
Consult with local inspector to assure compliance.
•
Do not submerge, or install within 5 feet of a swimming pool.
•
Do not connect the tape directly to high voltage power
•
Do not exceed maximum run recommended for each tape series
ATTENTION - AFIN DE RÉDUIRE LES RISQUES D'INCENDIE ET DE CHOC
ÉLECTRIQUE
•
Lire toutes les instructions avant d'installer.
•
Manipuler le produit avec soin.
•
Ne pas dissimuler et faire passer les conducteurs exposés à travers un mur
de bâtiment.
•
Afin de réduire les risques d'incendie et de brûlures, ne pas installer ce
système d'éclairage là où les conducteurs dénudés peuvent être court-
circuités, ou entrer en contact avec des matériaux conducteurs.
•
Afin de réduire le risque de surchauffe et d'incendie potentiel, s'assurer
que toutes les connexions sont bien serrées.
•
Ne pas installer aucun luminaire à moins de 6 pouces d'un rideau ou d'un
matériau combustible similaire.
•
Ne pas modifier ou démonter le produit au-delà des instructions sous
peine d'annuler la guarantie.
•
Ne pas respecter les avertissements de sécurité et des instructions
d'installation annulera la garantie.
program. DEC 2024 1.
