- Page 1 USER MANUAL Electric Bike Please read this manual carefully before using the E-Bike. Keep this manual for later reference.
-
Page 2: Assembling The Front Wheel
1. Assembling the Front Wheel 3.Tighten the screws on both sides 1.Install the front wheel as 2.Install the front wheel into the picture shows fork slot as picture shows The anti-decoupling direction should be consistent with the card slot Axle sleeve 10mm Be careful not to bump the Axle sleeve 5mm disc brake pads during... - Page 3 • Do not ride a the original supplier electric bicycle that is not assembled properly. • Do not disassemble or modify the X3 electric bicycle without permission; other wise, irreparable damage to the X3 electric bicycle and even personal injuries...
-
Page 4: Manual Overview
For your safety, please carefully read this manual before riding the X3 electric bicycle, and follow the instructions while riding the X3 electric bicycle. ● Be familiar with all safety warnings and precautions listed in this manual, which is helpful to ride the X3 electric bicycle. ● This manual applies to X3 electric bicycles produced by your dealer ●... - Page 5 The product S/N, which is the unique identifier, is used for quality tracking and after-sales services of the product. Please keep the product S/N properly. You can obtain it on the packing box, warranty card and bicycle body (on the side face of the controller box). 4.2 X3 Product Dimensions 520 mm 1330mm...
- Page 6 4.3 X3 Product Parameters Item SPEC Remarks Model Body size L52.36*H45.08*W20.47 inch Folding size L30.7*H27.56*W17.72 inch 46 LBS Net weight Tire type 16-inch Maximum load 265 LBS Brake type Front and rear disc brakes 1. The endurance mileage is associated...
- Page 7 4.4 X3 Product Structure Brake handle Throttle lever Warning bell Display screen Battery Bright LED headlight Leather cushion Front suspension Front wheel Inside controller Front disc brake Rear suspension Battery case anti-theft lock (underface) Rear fender Pedal Rear motor Rear disc brake...
- Page 8 4.5.2 X3 LCD Details Introduction...
- Page 9 4.5.2 Presentation of contents on the screen Item Picture Remark Real time speed Indicates real time speed info, in km/h or mph Indicates battery level: 4 segments in total， last segment will Battery level flash if battery level is under low voltage value Real time Battery In multi-purpose area, which indicates the battery voltage in voltage...
- Page 10 4.5.3 Manipulation By default, which means after power on, this device displays the real time speed, ODO, battery level and speed level. This device has 3 buttons for manipulation: “M”: Hold this button for more than 3 seconds will power on/off the device Shortly press(<1 second) will switch different content in multi-function area(ODO->TRIP->battery voltage->speed ratio->Error code(if exist)）...
- Page 11 4.6 X3 Fold and Take Battery Demo Folding steps: 1. Press and hold the safety pin with your thumb and then pull down the fixing handle of the folding machine to fold the riser; 2. First push hard in and then fold the pedal downward;...
- Page 12 4.7 X3 Unpacking Assembly Demo ① 0.59 inch open spanner #3 Inner Hexagon #5 Inner Hexagon Unpacking assembling steps: 1. Stand pipe is folded up. 2. Use 0.59 in open spanner to install the foot pedal on the left and right side.
- Page 13 5. Safe Operation Instructions 5.1 Charging Step 1: Find the charging port on the side face of the battery, as shown below. Step 2: Insert the charging terminal of the charger into the charging port (make sure that the charging port is dry). Step 3: The battery is being charged when the charger indicator turns red and fully charged when the indicator turns green.
- Page 14 • Do not use the X3 electric bicycle or lend it to anyone that does not know how to use it, before reading this manual to get familiar with the performance of the X3 electric bicycle.
-
Page 15: Safe Riding Precautions
• Be fully familiar with the riding environment and prevent disturbances caused by cars, pedestrians, pets, bicycles and other obstacles. • Ask a skilled person for help. He (She) needs to be skilled in riding the X3 electric bicycle and familiar with all precautions and riding instructions in this manual. -
Page 16: Maintenance
• Due to special properties of the lithium battery, the micro electric bicycle needs to be charged at least once a month. The battery damage arising from lack of regular maintenance is excluded from the warranty. • The X3 electric bicycle is for daily use only. Do not use it in extreme sports or under similar dangerous riding conditions. 6. Maintenance 6.1 Storage... -
Page 17: Tire Inflation And Replacement
5. Do not ride the electric bicycle if you are sick or take drug or drink alcohol or in poor physical or mental conditions. 6. The X3 electric bicycle must be used by a single person. It is also forbidden to carry a child or load while riding the electric bicycle. - Page 18 17. It is forbidden to ride the X3 electric bicycle on rainy days and wet roads. As the tire grip is reduced on a wet road, the braking distance will increase, and slipping may occur easily, making the electric bicycle out of control or resulting in other accidents.
-
Page 19: Personal Information Statement
26. Do not call someone or have any action that may distract you while riding the X3 electric bicycle, so that you are concentrated to always observe the external environment. 27. Ride the electric bicycle on the bicycle lane or in the roadside direction permitted or designated by the local government and the laws and regulations. -
Page 20: Intellectual Property Statement
5. You are deemed to waive all claims, liabilities and losses arising out of or in connection with the disclosure and use of your personal information by the original supplier or its affiliates or the parties receiving or using your personal information in line with the legal statement, except those caused by direct deliberation or gross negligence of the party receiving and/or using your personal information. - Page 21 Got a question? Need Help? Visit our web site for replacement parts, product support, a list of authorized service centers in the US and customer service contact information at www.rideglarewheel.com. Additional Customer Service contact information is listed at the back of this manual. UNITED STATES Glare Technology USA INC Monday –...
