Compo Closet CUDDY Quick Start Manual

What to do when you first get your CUDDY
Step 1 take your CUDDY out of the box.
Lift the top seat of CUDDY to see the magic inside.
Remove the carbon filter from its packaging and ensure both end
caps are clear of obstruction.
The solids bin is locked in place for shipping. To remove it, extend
the handle at the front and rotate it 180 degrees so that the legs on
the agitator point down towards the base.
Next, place a carbon-rich cover material such as coco coir,
sustainably sourced peat moss, or sawdust in the base of the solids
bin. There should be enough to cover 1 in of the agitator's legs. This
is approximately 50% of a standard 650g coco coir brick.
The cover material should be crumbly and damp to the touch.
Top Tip: We recommend keeping some hydrated coco coir in a leak-
proof plastic bag so that it's ready for use if you need some.
Connect the 12V power cable to an appropriately fused power
supply. CUDDY draws 0.1A, so a low amperage fuse is
recommended.
Insert the male connector into the power connection at the rear of
CUDDY as shown
Confirm that the fan is operational by feeling the airflow at the back
of the unit.
Insert a battery into the battery box. Confirm that the LED Liquid-full
indicator light works by holding the bottle upside down, touching the
front of the bottle to sensor and observing the LED.
Press the carbon filter onto the circular fitting to secure it.
Orientate the agitator legs downwards and replace the solids bin.
Just in case - give CUDDY a good wipe-down to remove any dirt or
debris left over from the manufacturing and shipping process... It's
your bum, after all!
Coat the surface of the hinges with WD40 or a similar grease for
protection.
Lower the seat, and you're good to, er... go!
Top Tip - Empty the solids bin when it is approximately 60% full to
prevent it from overflowing.
425 E Arrow Hwy, Unit Lytchett
#512, Glendora, CA 91740- Freeland
5607 USA Road, Poole. BH16 6FA. UK
CUDDY™ Composting Toilet
Quick Start Guide to get you Going
For more information including installation & Troubleshooting go to our
CUDDY™
Assembled in the USA with US & imported parts
House, Unit 13
Park, Wareham Further information about the product can be
found on our website, www.compocloset.com
website compocloset.com
Batch: ID: C101-BPUS-62022
