OWNER'S MANUAL
LG LED Signage
(LED SCREEN)
Please read the safety information carefully before using this product.
After reading this manual, keep it in an easily accessible location for future reference.
LSCB015-CK
LSCB018-CK
LSCB025-CK
Copyright © 2021 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSCB015-CK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG LSCB015-CK

Summary of Contents for LG LSCB015-CK

  • Page 1 LG LED Signage (LED SCREEN) Please read the safety information carefully before using this product. After reading this manual, keep it in an easily accessible location for future reference. LSCB015-CK LSCB018-CK LSCB025-CK www.lg.com Copyright © 2021 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS Precautions for the AC Adapter and Power Precautions for Moving the Product Precautions for Installing the Product Precautions for Cleaning the Product Precautions for Using the Product Precautions for Using the Remote control Precautions for Experiencing Image Retention Product Disposal 1.

  • Page 3: Safety Precautions

    WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. SAFETY PRECAUTIONS The Safety Precautions are intended to prevent unexpected danger or harm by helping the user to use the product safely and for its intended purpose.

  • Page 4: Precautions For The Ac Adapter And Power

    • Use only the power cord or AC adapter provided or approved by LG Electronics, Inc. If you use another power cord, make sure that it is certified by the national standards. If the power cable is faulty in any way, please contact the manufacturer or the nearest authorized service center for a replacement.
  • Page 5 CAUTION • If the outlet, pins of the power plug, or AC adapter is covered with dust, be sure wipe and keep clean. Overheating due to layers of dust may cause a fire or electric shock. • If the outlet, pins of the power plug, or AC adapter is covered with water, be sure wipe and keep clean. Additionally, Do not touch the power plug or AC adapter with wet hands.

  • Page 6: Precautions For Moving The Product

    Precautions for Moving the Product WARNING • Contact the service center before moving the product. - It may cause electric shock and damage the product. • Make sure the product is turned off, unplugged, and all cables have been removed before the product is moved. You may be electrocuted or the product can be damaged.

  • Page 7: Precautions For Installing The Product

    Precautions for Installing the Product WARNING • Contact the service center before installing the product. It can cause electric shock and damage the product. • Do not drop an object on or impact on the product. Keep out of reach of children and do not place toys or objects near the product to prevent throwing things on the product screen.
  • Page 8 CAUTION • Install the product where no Electromagnetic Interference occurs. • If you install the product in a place that does not meet the recommended conditions, this may cause serious damage to the product’s picture quality, life cycle, and appearance. Please check with service engineer before installing. Please do not install the product in places such as where there is an abundance of fine dust or oil mist, chemical substances are used, exposed to direct sunlight, the temperature is very high or low, the humidity is very high.

  • Page 9: Precautions For Cleaning The Product

    Precautions for Cleaning the Product WARNING • Keep the product clean at all times. If you don’t clean the unit for a long time and it becomes covered in dust, it can cause fire or product damage. • When you need to clean the inside of the product, you must contact the service center. Otherwise, cleaning without support may cause a fire, electric shock, or damage to the product.

  • Page 10: Precautions For Using The Product

    Precautions for Using the Product WARNING • Do not use the product in any environment with excessively high temperatures or humidity. • If you use the product for a long period of time, take a rest from time to time to protect your vision. Extended viewing could result in impaired vision.
  • Page 11 CAUTION • This panel is an advanced product that contains millions of pixels. You may occasionally see pixel spots when viewing the screen. Since these deactivated pixels are not a defect, the performance and reliability of the product is not affected. •...

  • Page 12: Precautions For Using The Remote Control

    Precautions for Using the Remote control WARNING • Avoid places with high humidity. - It may cause electrical shock or damage the product. • Do not expose batteries to excessive heat, such as direct sunlight, open fireplace, and electric heaters. It may cause fire and you may be injured.

  • Page 13: Precautions For Experiencing Image Retention

    Precautions for Experiencing Image Retention • Displaying a still image for a prolonged period of time may cause damage to the screen, resulting in image retention. Most third-party products have the same issue. The resulting damage is not covered by the product warranty.

  • Page 14: Product Overview

    1. Product Overview LSCB SERIES is LGE’s flagship fine pixel pitch, ultra-thin, high resolution digital LED display. The all-in-one design is the perfect solution for any installation requiring ultra-high definition. With a panel ratio of 16:9 and pixel pitch ranging from 0.9mm to 3.1mm, configurations of 2K, 4K, 8K resolution displays can be easily achieved. With an ultra-thin edge thickness of only 29.7mm and an intuitive slim line mounting system, LSCB series saves space for demanding environments.

  • Page 15: Dimensions

    1.2 Dimensions Fig.1 LSCB Series (Half size cabinet) AII dimensions are in millimeters...

  • Page 16: External Components

    1.3 External Components Fig.2 Position pin: Easy cabinet alignment Vertical ‘Rolling’-lock: Mechanical connection to upper panel Vertical ‘Rolling’-lock: Mechanical connection to upper panel Hanging pin: Hanging point for fixed installation (4x) （Fixing holes） Horizontal ‘‘Rolling’-lock: Mechanical connection to lateral panel; the curved cabinet without the horizontal locks Through hole: for data input/ output Through hole: for power output Horizontal ‘‘Rolling’-lock: Mechanical connection to lateral panel;...

  • Page 17: Mechanical Installation

    2. Mechanical Installation 2.1 Physical Installation WARNING! The safety and suitability of lifting equipment, installation location, anchoring method, mounting hardware, suspension structures and electrical installation is the responsibility of the installer. All local safety regulations and legal requirements must be observed when installing and connecting the LSCB SERIES panels. WARNING! Installation must be carried out by qualified professionals only.

  • Page 18: Fixed Installation

    2.2 Fixed Installation The first and most important is the alignment of mounting structure, refer to following procedure to mount the hanging bar on the wall. Building a good fixed screen relies on having an extremely leveled surface. The alignment of the modules in the finished screen will only ever be as good as the bottom row and for that reason, LGE recommend using the adjustable support structure for building a fixed screen Check each vertical structure with gradienter or laser;...
  • Page 19 3. Repeat step 1, Mount the second structure to the wall besides the first one. Ensure the two constructions are aligned correctly Fig.7 4. Detach the mechanical connection between the hanging and mounting bar. Remove the mounting bars carefully from the installation, see Fig.8. Check if the hanging bar is positioned and fastened correctly to the wall. Fig.8 Fig.9 5.
  • Page 20 6. Turn the key clockwise to secure the vertical locks and turn the key counter clockwise to secure the horizontal locks. The key must be rotated till the stopping point is reached. Fig.11 7. The special shape of the fixing point allows you to insert the cabinets pin from the right and left side. Align the panel carefully and ensure, that all four pins are placed into the holes before releasing the panel.

  • Page 21: Dismounting

    9. Put the modules back to the frames and do the alignment. Fig.14 10. The half size cabinet can be mounted with the full size cabinet, but the half size cabinet must be at the left/right side of the full size cabinet. See below for reference 2.3 Dismounting Dismantle all power cables and signal cables before tearing down an installation, remove all modules from the LED wall, then remove single panel starting at the top of the column.

  • Page 22: Power And Data Connection

    3. Power and Data Connection Cabling can be undertaken at the same time as the screen is built or after the screen construction. Whichever method is chosen largely depends on whether the whole screen back is accessible. Two types of cables are used on the back of the screen: ...

  • Page 23: Data Connection

    3.2 Data Connection Data cable should be planned so that it will have clean/tidy cabling. First, connect the main data cable to the panel at one corner of the screen. The main data cable is normally a10m (or longer) Cat5e cable with Neutrik Ether Con connector. Signal input Signal input Signal input...

  • Page 24: System Connection

    3.3 System Connection The fundamental elements of LED display system:  Led module  Driver board  Inner Power supply  Structure  Control system Structure of LED Display System Fig.17...

  • Page 25: Software

    4. Software Software Installation Insert the recorded disk to PC, click setup file to install “LCIN006” to computer hard disk. LED Studio Software Interface After the software is enabled, there comes the software interface as in the following picture. Main Interface The main interface is composed of five areas: 1 Menu, 2.
  • Page 26 Setup the receiver cards Run LCIN006 Login as advanced user, enter the password ‘admin’ or ‘666’...
  • Page 27 Load configuration file Load file: load a receiver card file to software, file format is “.rcfg” Save file: save a receiver card configuration as a file Read from HW: read configuration from receiver card Send to HW: send configuration to receiver card Save config file: save complete configuration including controller, receiver card and screen as a file, file format is “.scfg”...
  • Page 28 Display Connection Setup Press “Screen Config” Icon, select “Config Screen” then press “Next”. Enter “Screen Configuration” page, select “Screen number” as “1” then press “Config”...
  • Page 29 Select “Standard Screen”, set how many Scan Boards (Receiver cards) are used in Column and Row, how many pixels one Scan Board (Receiver cards) manages in Width and Height, and connect Scan Boards (Receiver cards) based on fact (Viewing from the front of LED screen). Correct the Scan Board Size: Select the scan board need to be corrected, change the width or height value then click the scan board area.

  • Page 30: Service And Maintenance

    5. Service and Maintenance 5.1 Storage LGE LSCB SERIES Modules should be stored in a constant temperature, low humidity environment. If the modules or flight cases have been used at an event where they got wet, care should be taken to fully dry all items before they are returned to storage.

  • Page 31: Service And Maintenance

    5.3 Service and Maintenance WARNING! Disconnect the panel from power or isolate the entire distribution circuit from power and ensure that all unused connectors are sealed with the supplied rubber caps before cleaning. WARNING! Refer any service operation not described below to a service technician approved by LGE Professional. Removing any cover may cause a safety risk or unsatisfactory performance and will invalidate the product warranty.

  • Page 32: Troubleshooting

    5.6 Troubleshooting Problem Probable cause(s) Remedy No power to panel. Check power and connections. Disconnect panel from power. Contact LGE Fuse blown. Professional for service. Panel is completely dead Disconnect panel from power. Contact LGE Defective PSU (power supply unit). Professional for service.

  • Page 33: Product Specifications

    6. Product Specifications Model Name LSCB015-CK LSCB018-CK LSCB025-CK Pitch Name P1.5625 P1.875 P2.5 Physical Pixel Configuration 3 in 1 SMD 3 in 1 SMD 3 in 1 SMD Pixel Pitch(mm) 1.563 1.875 2.500 Module Resolution 192x108 160x90 120x135 (WxH) Module 300x168.75...
  • Page 34 Frame Rate (Hz) 50 / 60 50 / 60 50 / 60 Refresh Rate (Hz) 3,840 3,840 3,840 Lifetime (Half 100,000 100,000 100,000 brightness) Operation Operating Specificatio -10∘to +45∘ -10∘to +45∘ -10∘to +45∘ Temperature(℃) Operating Humidity 0~80%RH 0~80%RH 0~80%RH IP rating Front IP30 IP30 IP30...
  • Page 35 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. MODEL device. SERIAL NO.
