- Page 1 EGE-UHD-HDB-507-TX/RX HDMI over CAT5e/6/7 Transmitter / Receiver with LAN Output/PoC...
-
Page 2: Copyright Notice
DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document. -
Page 3: Safety Precautions
EGE-UHD-HDB-507TX/RX HDMI over CAT5e/6/7 Transmitter Receiver with LAN Output/PoC SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •... -
Page 4: Table Of Contents
EGE-UHD-HDB-507TX/RX HDMI over CAT5e/6/7 Transmitter Receiver with LAN Output/PoC CONTENTS 1. Introduction ................1 2. Applications ................1 3. Package Contents ..............1 4. System Requirements ............1 5. Features...................2 6. Operation Controls and Functions ........3 6.1 Transmitter Front and Rear Panels............3 6.2 Receiver Front and Rear Panels..............4 6.3 IR Cable Pin Assignment.................5 6.4 RS-232 Cable Pin Definitions..............5 7. -
Page 5: Introduction
EGE-UHD-HDB-507TX/RX HDMI over CAT5e/6/7 Transmitter Receiver with LAN Output/PoC 1. INTRODUCTION The HDMI over CAT5e/6/7 Transmitter and Receiver set can send uncompressed video/ audio and IP data over an single run of CAT5e/6/7 cable up to 100 meters. It has the added benefit of control through the built-in RS-232 pass-through and 2-way IR control and a LAN serving connection. -
Page 6: Features
EGE-UHD-HDB-507TX/RX HDMI over CAT5e/6/7 Transmitter Receiver with LAN Output/PoC 5. FEATURES • HDMI (with 3D format and 4K2K resolution support), HDCP and DVI compliant • Supports CEC bypass function • Simultaneous transmission of uncompressed video/audio and data over a single CAT5e/6 cable up to 100 m/328 ft •... -
Page 7: Operation Controls And Functions
EGE-UHD-HDB-507TX/RX HDMI over CAT5e/6/7 Transmitter Receiver with LAN Output/PoC 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter Front and Rear Panels HDMI In: Connect to HDMI source equipment such as a DVD or Blu-ray player. LAN: Connect to an internet or network connection. RS-232 In: Connect to a PC or laptop with D-sub 9-pin male cable for the transmission of RS-232 commands. -
Page 8: Receiver Front And Rear Panels
EGE-UHD-HDB-507TX/RX HDMI over CAT5e/6/7 Transmitter Receiver with LAN Output/PoC 6.2 Receiver Front and Rear Panels HDMI Out: Connect to a HDMI equipped TV/monitor for display of the HDMI input source signal. LAN: Connect to a PC or Laptop to the Internet or network connection. RS-232 Out: Connect to the device that is to be controlled (via D-sub 9-pin female cable) by RS-232 commands. -
Page 9: Ir Cable Pin Assignment
EGE-UHD-HDB-507TX/RX HDMI over CAT5e/6/7 Transmitter Receiver with LAN Output/PoC 6.3 IR Cable Pin Assignment 6.4 RS-232 Cable Pin Definitions ASSIGNMENT (TX/RX) TxD / RxD RxD / TxD... -
Page 10: Connection Diagram
EGE-UHD-HDB-507TX/RX HDMI over CAT5e/6/7 Transmitter Receiver with LAN Output/PoC 7. CONNECTION DIAGRAM... -
Page 11: Specifications
EGE-UHD-HDB-507TX/RX HDMI over CAT5e/6/7 Transmitter Receiver with LAN Output/PoC 8. SPECIFICATIONS VideoBandwidth 340 MHz/10.2 Gbps Ethernet Speed 100 Mbps Transmitter Input Ports 1×HDMI, 1×LAN, 1×IR Extender,1×RS-232 Output Ports 1×CAT5e/6/7, 1×IR Blaster Receiver Input Ports 1×CAT5e/6/7, 1×IR Extender Output Ports 1×HDMI, 1×LAN, 1× IR Blaster, 1×RS-232 HDMI Cable Distances Up to 10 meters CAT6 Cable Distances... - Page 13 www.geratech.eu...
