- Page 1 EGE-WHD5-EXT Wireless HD Video Transmission Solition...
- Page 2 EGE-WHD5-EXT Wireless HD Video Transmission Solition...
- Page 3 EGE-WHD5-EXT Wireless HD Video Transmission Solition Important Information Please read this user manual before you use this product, it contains all the notes and impor¬tant things regarding operating this product. In accordance with the safety precautions and operating instructions listed on this user manual, ourapplies provided the product is handled properly for its intended use, but may not apply to below cases: Repairs or product modification and alterations have been executed by unauthorized personnel.
- Page 4 EGE-WHD5-EXT Wireless HD Video Transmission Solition Warning This product should not be exposed to dripping or splashing. Do not place any object filled with liquid on the product(eg. vases). To avoid electric shock, please do not block or stick anything on the air vent of product; do not remove the cover or put the object just like pins, steel wire into the gap of the air vent.
-
Page 5: Table Of Contents
EGE-WHD5-EXT Wireless HD Video Transmission Solition CONTENTS Foreword ................Brief Introduction ..............Features ................. Structure & Interface ............. The Transmitter EGE-WHD5-EXT ........The Receiver EGE-WHD5-EXT .......... Packing List ................Product Installation Instruction ........... Specification ................................. Indication Troubleshooting ..............FCC Statement ............... -
Page 6: Foreword
EGE-WHD5-EXT Wireless HD Video Transmission Solition Foreword Please read this manual carefully before you use this p roduct and reta in it properly for future reference. If there is any doubt or difficulty in the process of product usage, please feel free to contact us or the dealer. -
Page 7: Structure & Interface
CONNECTING AND OPERATING Structure & Interface The Transmitter EGE-WHD5-EXT 1) Connect the HDMI input source (such as HD-DVD/ PS3 /STB etc.) into transmitter over HDMI cable. 2) Connect the output of transmitter and input of receiver over CAT5E or CAT6 cable. -
Page 8: The Receiver Ege-Whd5-Ext
EGE-WHD5-EXT Wireless HD Video Transmission Solition The Receiver EGE-WHD5-EXT DC Power: Power socket for DC adapter. HD MI Output: connect to HD display device such as HDTV, Projector, LED Screen, etc. USB: USB socket for upgrading. Pairing: For devices paring, use pin to push for about 5 seconds then release, the devices will be paring. -
Page 9: Packing List
EGE-WHD5-EXT Wireless HD Video Transmission Solition Packing List Pleace check the packing list carrefuly, if any part missed, pleace contact your dealer. Components of all models are subject to the following packing list. TX:EGE-WHD5-EXT RX:EGE-WHD5-EXT Wireless HD Transmitter x1 Wireless HD Receiver x1... - Page 10 EGE-WHD5-EXT Wireless HD Video Transmission Solition 3) After communicating the power transmitter and receiver system startup, the system start after the completion of the following OSD displayed on the device screen: ¨Connecting to transmitter¨...
- Page 11 EGE-WHD5-EXT Wireless HD Video Transmission Solition 4) Wait for the system start, and the screen will display text "Connecting to transmitter" then the images shows up, which means the product is working. 5) Whenthe system working properly, user can uset he remote controller of HD player at the HDTV side.
-
Page 12: Specification
EGE-WHD5-EXT Wireless HD Video Transmission Solition Specifacation Transmitter Receiver ITEM EGE-WHD5-EXT EGE-WHD5-EXT Free Band (USA):5151 ~ 5250MHz, 5725 ~ 5825 MHz Rrequency Free Band (JAN & EU) :5151 ~ 5250 MHz RF Communication 2x2 MI MO Modulation Mode OFDM Power Consumption... -
Page 13: Indication
EGE-WHD5-EXT Wireless HD Video Transmission Solition Indicators LED Indicator Display Status Network Indicator Indicator ON Device Power ON (RED) Twinkle Slowly Connecting... Video Indicator Indicator ON Video Transmission ON (BLUE) Twinkle Slowly NO Video Signal Input Both Network & Video Twinkle Quickly Pairing... -
Page 14: Troubleshooting
EGE-WHD5-EXT Wireless HD Video Transmission Solition Trouble Shooting Posible Reasons Solutions No signals are input toTV Receiver is notturned on. Power on receiver. Transmitteris on sleeping. Remove the hDMI cable then connect it to awake the device. Receiver and TV are not connected. -
Page 15: Fcc Statement
EGE-WHD5-EXT Wireless HD Video Transmission Solition FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can... - Page 16 www.egerate-store.com...
