Access & Power Integration
Altronix/Mercury Wired Kits
Models Include:
T1M1CK1V
4 Door Kit with Fused Outputs
Accommodates one (1) Intelligent Dual Reader Controller and
one (1) Dual Reader Interface Module.
T1M1CK2V
2 Door Kit with Fused Outputs
Accommodates one (1) Intelligent Controller and
one (1) Dual Reader Interface Module.
T1M1CK3V
4 Door Kit with Fused Outputs
Accommodates up to two (2) Dual Reader Interface Modules.
Each fully assembled kit includes:
- Trove1 enclosure with TM1 Altronix/Mercury backplane
- One (1) eFlow4NBV - Power Supply/Charger
- One (1) ACM4 - Fused Access Power Controller
- One (1) PDS8 - Dual Input Fused Power Distribution Module
- One (1) VR6 - Voltage Regulator
- One (1) Rocker Switch Bracket with One (1) Rocker Switch
- Wire harnesses and management
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. 020524
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T1M1CK1DV
4 Door Kit with PTC Outputs
Accommodates one (1) Intelligent Dual Reader Controller and
one (1) Dual Reader Interface Module.
T1M1CK2DV
2 Door Kit with PTC Outputs
Accommodates one (1) Intelligent Controller and
one (1) Dual Reader Interface Module.
T1M1CK3DV
4 Door Kit with PTC Outputs
Accommodates up to two (2) Dual Reader Interface Modules.
Each fully assembled kit includes:
- Trove1 enclosure with TM1 Altronix/Mercury backplane
- One (1) eFlow4NBV - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
- One (1) VR6 - Voltage Regulator
- One (1) Rocker Switch Bracket with One (1) Rocker Switch
- Wire harnesses and management
More than just power.™

Advertisement

loading
Need help?

Need help?

Do you have a question about the TROVE PLUS T1M1CK1V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Altronix TROVE PLUS T1M1CK1V

  • Page 1 Accommodates up to two (2) Dual Reader Interface Modules. Each fully assembled kit includes: Each fully assembled kit includes: - Trove1 enclosure with TM1 Altronix/Mercury backplane - Trove1 enclosure with TM1 Altronix/Mercury backplane - One (1) eFlow4NBV - Power Supply/Charger...
  • Page 2: Configuration Chart

    Place the enclosure’s upper keyholes over the three upper screws. Install the three lower screws and make sure to tighten all screws. 3. Mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) in desired location, opposite hinge. Slide the tamper switch bracket onto the edge of the enclosure approximately 2”...
  • Page 3 LNL-2220 / LP1502 / LP4502 LNL-1320 / MR52 Fig. 2 Fig. 2a Ground Lug VR6 is mounted under PDS8(CB) PWR1 + IN1 Fuse PWR1 + Snap On Altronix PDS8(CB) Spacer OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 COM (--- )
  • Page 4 Mercury Access Controller Pem Mounting LNL-3300 / LP2500 LNL-1320 / MR52 Fig. 3 Fig. 3a Ground Lug VR6 is mounted under PDS8(CB) PWR1 + IN1 Fuse PWR1 + Altronix PDS8(CB) Snap On Spacer OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8...
  • Page 5 Mercury Access Controller Pem Mounting LNL-1320 / MR52 LNL-1320 / MR52 Fig. 4 Fig. 4a Ground Lug VR6 is mounted under PDS8(CB) PWR1 + IN1 Fuse PWR1 + Altronix PDS8(CB) Snap On Spacer OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8...
  • Page 6 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
  • Page 7 Notes: T1M1CKV Series Installation Guide - 7 -...
  • Page 8 1.115” (28.3mm) 1.36” (34.5mm) 1.25” (31.8mm) Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
