bemodern DIAMOND 4250 Instructions For Assembly And Installation

Floor standing marble suites

Advertisement

Quick Links

Floor Standing Marble Suites
Instructions For Assembly & Installation
(Surround, Back Panel & IQFX Fire Supplied Separately)
Models Covered:
4250
Marble Floor Standing Suites
Including
IQFX 750L /1000L
R1- OCT 24
200883

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIAMOND 4250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for bemodern DIAMOND 4250

  • Page 1 Floor Standing Marble Suites Instructions For Assembly & Installation (Surround, Back Panel & IQFX Fire Supplied Separately) Models Covered: 4250 Marble Floor Standing Suites Including IQFX 750L /1000L R1- OCT 24 200883...
  • Page 2: Table Of Contents

    Contents Page Parts & Fittings Supplied Important Information Power Supply and Optional Mood Lighting Introduction Surround Hearth Installation Hearth & Plinth Installation Mount Board Installation Main Body Wall Bracket Installation Preparing the Fire for Installation Installing the Fire- IQFX 750L- 1000L Optional Mood Lighting Installation Installing the Back Panel Trim Surround Main Body Installation...
  • Page 3: Assembly & Installation Instructions

    Assembly & Installation Instructions Parts & Fittings Supplied. PARTS DIAGRAM PARTS DIAGRAM Surround Adhesive Pad Main Body Supplied with surround. (No back Panel Fitted) Surround Back Panel Hearth & Trim Plinth Supplied Separately. Note: Fire Support Stands are not required for this Wall Bracket installation.
  • Page 4: Important Information

    Assembly & Installation Instructions Important Information - These instructions are for your safety. Please read them thoroughly before use and retain for future reference. Failure to follow them may result in serious or fatal injury and/or property damage. Before you begin the installation, please ensure that a full and detailed inspection of all component parts is undertaken jointly by the installer and purchaser to ensure there is no damage or manufacturing defects with the product.
  • Page 5: Power Supply And Optional Mood Lighting Introduction

    Assembly & Installation Instructions Before you start DO NOT dispose of the packaging until you have checked and made sure you have all the parts and fittings listed above. If not, contact: BE MODERN - HELPLINE 0191 430 0901 who will be able to assist you with this and any other problems you may encounter. When you are ready to start, make sure that you have the right tools to hand, plenty of space and a clean dry working area.
  • Page 6: Hearth & Plinth Installation

    Assembly & Installation Instructions Hearth & Plinth Installation Fig.2 FLOOR 1. Unpack the Surround Main Body (A) and Hearth- Fig.3 Plinth (B). Packed with the Main Body (A) is the supplied fitting kit. Unpack and confirm all components have been supplied as detailed in page 2. 2.
  • Page 7: Mount Board Installation

    Assembly & Installation Instructions Hearth & Plinth Installation Continued.. Fig.5 5. Once the Wall Brackets (C) have been securely screwed to the wall. Carefully lower the Hearth-Plinth (B) in to position, hooking the L-brackets over the Wall Brackets. See Fig.5. The brackets must be positioned as illustrated in Fig.6.
  • Page 8 Assembly & Installation Instructions Main Body Wall Bracket Installation Fig.9. Continued.. 8. Lift the Main Body (A) in to position centrally on the pre-installed Hearth-Plinth (B). See Fig.9. Fig.10. 9. Mark a line under both pre-installed L-brackets 10mm in from the MDF side blocks. See Fig.10. Fig.11.
  • Page 9: Preparing The Fire For Installation

    Assembly & Installation Instructions Fig.13 Preparing the Fire for Installation 12. Unpack the Fire (G) 13. Lay the Fire (G) on its back and unscrew the 2x Fig.14 wall mount bracket securing screws on the rear base of the Fire (G). Fig.13,14. 14.
  • Page 10: Installing The Fire- Iqfx 750L- 1000L

    Assembly & Installation Instructions Installing the Fire Fig.17 16. Screw the previously removed Fire wall mount bracket to the previously installed plywood Mount Board (H). The Mount Board (H) is pre-drilled at the factory with two bracket mount positions. For this installation the lower row of fixing holes should be used.
  • Page 11: Optional Mood Lighting Installation

    Assembly & Installation Instructions Installing the Mood Lighting Fig.21 Note: If optional mood lighting has been purchased, this will need installing before proceeding any further. 20. Connect the mood lighting to the corresponding port on the fire and route the cable down the side of the fire to the underside of the Hearth-Plinth (B).
  • Page 12: Installing The Back Panel Trim

    Assembly & Installation Instructions Installing the Back Panel Trim Fig.23 22. Unpack the Back Panel Trim (F) and if applicable remove the protective film. See Fig.23. Note: The Back Panel Trim (F) is supplied with 3 x Fire Support Stands, these are not required for this installation.
  • Page 13: Surround Main Body Installation

    Assembly & Installation Instructions Fig.25 Installing Surround Main Body 24. To fit the Main Body (A) in place. Lift and position the Main Body (A) over the pre-installed Wall Brackets (C) and into the pre-machined notch in the rear of Mount Board (H). See Fig.25-27.
  • Page 14: Maintenance/ Important Note

    CAUTION: Abrasive cleaners should not be used on the glass panel. Liquids should not be sprayed directly onto any surface of the unit. Troubleshooting Should you have any queries regarding this product please contact Customer Services on 0191 4300901 (option 4) or email us at customerservices@bemodern.co.uk Recycling All cardboard packing is recyclable IMPORTANT NOTE: Wall fixings (i.e.
