Contents Page Parts, Fittings Supplied & Important Note Preparing for Surround Installation Surround Installation Fire Installation Maintenance / Important Note R1- JAN 25 200896...
Page 3
Assembly & Installation Instructions Parts & Fittings Supplied. PARTS DIAGRAM PARTS DIAGRAM Surround 4mm x 16mm Dome head POZI Screws BOX-1 Supplied with BOX-1 surround Wall Bracket Fire Supplied with Supplied surround. Separately. BOX-2 BOX-1 Before you start DO NOT dispose of the packaging until you have checked and made sure you have all the parts and fittings listed above.
Page 4
Assembly & Installation Instructions Preparing for Surround Installation Unpack the Surround and prepare the area for the installation Note: Dependent on the surround size purchased and whether the surround will be floor or wall mounted; the wall mount bracket position will be different. Measure from the base of the surround up to the bottom edge of the pre-installed Mount Bracket to get dimension A-A.
Assembly & Installation Instructions Holding the wall hook brackets in place mark the position of the fixing holes on the wall. The wall hook brackets must be level and horizontal with each other. Drill and plug the 8 fixing points in the wall with the appropriate fixing for the wall medium.
Page 6
Assembly & Installation Instructions When installed, the surround mount brackets should be securely positioned over the wall hook brackets. The surround installation on the wall is complete. Fire Installation Unpack the fire and remove fire front trim if fitted. Again, with a second person lift the fire carefully in to place.
Page 7
Assembly & Installation Instructions Shown here in the surround base are the power cable routing holes. Centre the fire in the opening. For best results pilot hole the position of the fixing points in the fire onto the panel behind. Securely screw the fire in place in all four corners with the supplied 4-off 4mm x 16mm Dome head screws (Ref-C).
Page 8
Assembly & Installation Instructions Shown here are the magnets in place on the magnet blocks. Note, the side magnet is positioned below the central hole. Place the trim over the front of the fire, with the magnets holding the trim securely in place. The Suite installation is now complete.
CAUTION: Abrasive cleaners should not be used on the glass panel. Liquids should not be sprayed directly onto any surface of the unit. Troubleshooting Should you have any queries regarding this product please contact Customer Services on 0191 4300901 (option 4) or email us at customerservices@bemodern.co.uk Recycling All cardboard packing is recyclable IMPORTANT NOTE: Wall fixings (i.e.
