USER GUIDELINE
Thank you for choosing MOON headlight!
*For using this product safely and conveniently and keeping it
well-preserved, please read this manual carefully before using.
Please save this manual for future reference.
*Due to the improvement of the product, the product you bought may
not be exactly in accordance with the introduction of this manual. We
apologize for that.
SPECIFICATION
*1 pc CREE XP-G2 (R5) high brightness LED
*Rechargeable lithium polymer battery (3.7V 1200mAh)
*USB rechargeable
*Water resistant (IPX 4)
*Headlight with durable aluminum alloy light cap
*6 modes: Over drive / High / Standard / Flashing / Strobe / SOS
*Quick release handlebar mount (fits 22-31.8mm)
*Quick release helmet mount
*Low battery, charging and fully charged indicator
*Mode status indicator
*Automatic fully charged cut-off system
*High precision optical lens
CONTENTS INCLUDED
Contents:
Meteor 250
* USB-01 (USB cable)
* RB-07 (Handlebar bracket)
Optional accessories:
* XP-USC (Wall charger)
* RB-06 (Helmet mount bracket)
HEADLIGHT OPERATION
1. Please make sure that there are no obstacles around the headlight
to keep the air flow smoothly, as the light will get hot during use.
Please don't touch the light immediately after a long time use.
2. Press the power button to choose the modes:
In this method three modes are cycled.
Over drive
Blue color
High beam
Green color
Standard
Orange color
3. Fast press two times the power button to change into the strobe
and flashing modes. Fast press two times back to the first cycle.
Power button
PRESS
Fast press
2 times
4. Press the power button to choose the modes again :
®
In this method three modes are cycled also.
Flashing
Strobe
SOS
!
Never use the SOS sign unless there is a real emergency or danger
occurring. The SOS signal is visible for several miles, thanks to the
high light output of the lamp. And the battery can support for long
runtime up to several hours.
5. Press and hold the on / off button around 0.5 seconds to turn off.
6. Battery power indicator: 100% -60% blue color, 60 % - 20% yellow
color 20 % - 0 % red color. During charging it turns flashing blue and
when fully charged it turns steady blue.
7. When the battery indicator turns flashing red, it means the battery is
low. You'd better charge the light right now.
Battery indicator
* 100% -60% Blue
Power button
* 60%-20% Green
* 20% -0 % Flashing Red
PRESS
Charging indicator
* Flashing blue - charging
* Soild blue - charged
Power button
Flashing Blue color
Flashing Green color
Flashing Orange color
PRESS
Power button
PRESS
Hold 0.5 sec
Low battery &
charging indicator
6 Modes indicator
Power button
HOW TO MOUNT THE HEADLIGHT
1.Install the bracket onto handlebar by wrapping rubber strap around
post/bar and stretching strap around hook to secure.
2.Slide headlight forward onto bracket until it clicks into place.
3.Press down release lever to remove.
INSTALL
click
RELEASE
PRESS
RELEASE
LEVER
RUBBER
STRAP
HOW TO MOUNT THE HEADLIGHT TO HELMET
1.Wrap belt around helmet and return the belt onto slotted space.
2.Twist screw knob clockwise until tight.
3.Slide headlight forward onto bracket until it clicks into place.
4.Press down release lever to remove.
click
INSTALL
PRESS
RELEASE
SCREW
KNOB
RELEASE
LEVER
BELT
To adjust the vertical beam angle when mounted on the helmet,
loosen the screw knob and rotate the light up or down to your
preferred angle, then tighten the screw knob to secure the light in
place.
