SLENERGY iShare-Home Series Manual

Residential smart solar system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Residential Smart Solar System
2023.07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iShare-Home Series and is the answer not in the manual?

Questions and answers

Related Manuals for SLENERGY iShare-Home Series

Summary of Contents for SLENERGY iShare-Home Series

  • Page 1 Residential Smart Solar System 2023.07...

  • Page 2: About This Manual

    Slenergy is not liable for any patent infringement or third-party rights arising from the use of the system. Slenergy reserves the right to change the Product specification and this manual without prior notice.
  • Page 3 Residential Solar Energy Solution Company Profile Slenergy is a renewable energy company that develops, produces, and delivers • the world’s most complete and cost-effective photovoltaic solar energy solutions. Slenergy has created multiple PV systems designed for specific solar energy installations and applications, including residential , industrial, Micro/off-grid, ground PV kits.
  • Page 4 CONTENT Installation Concept Product Introduction...
  • Page 5 iShare-Home Residential Solar Energy Solution PART Concept Introduction of marketing shortages and design concept...
  • Page 6 iShare-Home Residential Solar Energy Solution • High labor cost Distributors • Difficulties in dealing with different manufacturers • Long design cycle and Installers • Incompatibility between equipment • Difficulties in fault identification and responsibility attribution • Lack of system products •...

  • Page 7: Warranty

    Certificates Our PV Solutions and complete range of products, On-grid, Off- Slenergy offers a complete line of warranties on all major products grid, Hybrid, and Residential PV Kits include a wide variety of and components within our PV kits and solar energy solutions internal components and hardware that comply with global with optional extended warranties upon request.
  • Page 8 iShare-Home Residential Solar Energy Solution Smart Standard Modular Simple System Design Energy storage Wireless quick installation Real-time monitoring, intelligent Standard BOM Adopts the smallest modular unit Storage battery installed in stack control of 2.56kWh, which can be flexibly 24-hour monitoring of the power Interface design The connection between modules configured according to customer...

  • Page 9: Product Introduction

    iShare-Home Residential Solar Energy Solution PART Product Introduction System introduction and equipment key features...
  • Page 10 iShare-Home Residential Solar Energy Solution 1. PV Modules 2. Inverters 3. Battery 4. Mounting Structure 5. Wiring Connection Kit...
  • Page 11 Residential Solar Energy Solution Slenergy offers a range of variable power We offer both Monocrystalline cell SL-BH series is a high voltage iShare-Home mounting systems One of the best parts of inverters in three phase AC. Code technology in all black glass back-...
  • Page 12 iShare-Home Residential Solar Energy Solution PV Module 20.7 % Max. Efficiency • 405 W Module Power • All Black PV modules / low-profile and minimalist aesthetic • IEC 61215, IEC 61730, IEC 62716, IEC 61701, IEC TS 62804-1, IEC 60068-2-68 •...
  • Page 13 iShare-Home Residential Solar Energy Solution PV Module N Type TOPCON 21.8 % Max. Efficiency • 425 W Module Power • All Black PV modules / low-profile and minimalist aesthetic • IEC 61215, IEC 61730, IEC 62716, IEC 61701, IEC TS 62804-1, IEC 60068-2-68 •...
  • Page 14 iShare-Home Residential Solar Energy Solution Electrical Parameters (STC * ) Mechanical Parameters Nominal Max. Power(Pmax/W) Cell Type P Type Open Circuit Voltage(Voc/V) 37.38 Module Size 1722×1134×30mm Short Circuit Current(Isc/A) 13.76 Glass Thickness 3.2mm Operating Voltage(Vmp/V) 31.35 Module Weight 21.2kg Operating Current(Imp/A) 12.92 Output Cable 4mm²,cable length 1200mm...
  • Page 15 iShare-Home Residential Solar Energy Solution Electrical Parameters (STC * ) Mechanical Parameters Nominal Max. Power(Pmax/W) Cell Type N Type Open Circuit Voltage(Voc/V) 38.54 Module Size 1722×1134×30mm Short Circuit Current(Isc/A) 13.79 Glass Thickness 1.6mm Operating Voltage(Vmp/V) 32.35 Module Weight 20.5kg Operating Current(Imp/A) 13.14 Output Cable 4mm²,cable length 1200mm...
  • Page 16 iShare-Home Residential Solar Energy Solution Inverter 98.2 % Max. Efficiency • Dual MPPT technology provides numerous • layout and design options. Large MPPT voltage range • Within 10ms UPS-level switching • Up to 110% unbalanced load • Up to 125% AC output overloading •...
  • Page 17 iShare-Home Residential Solar Energy Solution Technical Specificationt SL-D4KTR-H25 SL-D5KTR-H25 SL-D6KTR-H25 SL-D8KTR-H25 SL-D10KTR-H25 SL-D12KTR-H25 Efficiency Max. efficiency 98.10% 98.10% 98.10% 98.20% 98.20% 98.20% European Efficiency 97.30% 97.30% 97.30% 97.40% 97.40% 97.40% Input Max. Input power [kWp] Max. DC input Voltage*[V] 1,000 MPPT voltage range**[V] 120~950 200~950...
  • Page 18 iShare-Home Residential Solar Energy Solution Energy Storage Battery Safer LiFePO batteries • Flexible Application Modular design with • extensible capacity from7.68-20.48kWh Reliable Performance Long working life with 6000 • cycles @80% DOD Stacked structure with optimized installation • mode Better temperature sensitivity increases cycle •...
  • Page 19 iShare-Home Residential Solar Energy Solution Battery LX-BH-3-7 LX-BH-4-10 LX-BH-5-12 LX-BH-6-15 LX-BH-7-17 LX-BH-8-20 NO. of series battery Rated power (kWh) 7.68 10.24 12.8 15.36 17.92 20.48 Usable energy (kWh) 11.52 13.8 16.13 18.4 Rated voltage (V) 153.6 204.8 307.2 358.4 409.6 Voltage range (V) 134.4~172.8 179.2~230.4...

  • Page 20: Mounting Structure

    iShare-Home Residential Solar Energy Solution Easy to fix rail and adjust leveling • Easy to adjust hook height • Hook height adjusting range 40-55mm • High strength aluminum alloy • Minimum modular design with two PV panels • Better compatibility with roof •...

  • Page 21: Cable Set

    iShare-Home Residential Solar Energy Solution Cable Set • Wide application flexibility • Superior durability and longevity • Cost and time savings with connectors prefabricated Name specification From Remark Length(m) Accessory bag Inverter PV PV DC Cable H1Z2Z2-K 1×6mm PV Modules Cable terminals are made and installed on site 80 ~ 160 MC4 Connector...

  • Page 22: Installation Instruction

    iShare-Home Residential Solar Energy Solution PART Installation Instruction Quick Installation introduction...
  • Page 23 iShare-Home Residential Solar Energy Solution Indicates a hazard with a high level of risk which, if not avoided, will result in death or serious injury. Indicates a hazard with a medium level of risk which, if not avoided, could result in death or serious injury. Symbols Indicates a hazard with a low level of risk which, if not avoided, could result in minor or moderate injury.

  • Page 24: What's In The Box

    iShare-Home Residential Solar Energy Solution What’s in the Box...
  • Page 25 iShare-Home Residential Solar Energy Solution iShare integrated System – 405W System Configuration 10kW 12kW 15kW PV Module 4kW~5kW 6kW~7kW 8kW~9kW 10kW~11kW 12kW~14kW 15kW~17kW 18kW~20kW No. PV modules (pcs) 10/12/14 16/18 20/22 24/26/28 30 /32/34/36 38/40/42/44 46/48/50 Inverter 4kW*1set 5kW*1set 6kW*1set 8kW*1set 10kW*1set 12kW*1set...
  • Page 26 iShare-Home Residential Solar Energy Solution iShare integrated System – 425W System Configuration 10kW 12kW 15kW PV Module 4kW~5kW 6kW~7kW 8kW~9kW 10kW~11kW 12kW~14kW 15kW~17kW 18kW~20kW No. PV modules (pcs) 10/12/14 18/20 22/24/26/28 30 /32/34 36/38/40/42 44/46/48/50 Inverter 4kW*1set 5kW*1set 6kW*1set 8kW*1set 10kW*1set 12kW*1set 15kW*1set...
  • Page 27 iShare-Home Residential Solar Energy Solution Mounting Structure Technical Parameter Product Name Solar Mounting System EN1990 Basis of Structure Design Building Type Pitched Roof Design Standard EN1991-1-3 Actions on Structure-Snow loads Tile Type Concrete Tile, Clay Tile, Slate Tile EN1991-1-4 Actions on Structure-Wind loads Tilt Angle 15-60°...

  • Page 28: Note Before Installation

    iShare-Home Residential Solar Energy Solution Note Before Installation The Inverter series three-phase high voltage hybrid inverter applies to the three-phase power grid with a voltage of 230/400V and a frequency of 50/60Hz. • PV modules number in one string for •...
  • Page 29 iShare-Home Residential Solar Energy Solution An independent AC breaker is required in both on-grid and back-up output side, and any loads cannot be connected with inverter directly. User-side distribution box. Install the inverter in the same room of the Install the inverter vertically. Never original distribution box of the user, and the install the inverter horizontally, or at distance should be less than 10m between the...
  • Page 30 Slenergy the protrusion of key A and locked. The calculation tool, otherwise the mounting length of rail shall be selected according structure might have risk of failure when it to the corresponding drawings.
  • Page 31 iShare-Home Residential Solar Energy Solution PV & Mounting structure installation Place the PV module on the rail and adjust the position according to the drawing. Then fix the end clamp into the rail channel, and tighten the bolts. Installation of PV Modules Installation of Grounding Lug Installation of Rail Cap...
  • Page 32 iShare-Home Residential Solar Energy Solution Electrical connections Horizontal Installation of PV modules It is not recommended to install PV modules horizontally. If it is necessary to install PV modules horizontally, an extension line should be added. Vertical Installation Standard Cable length Note: An extension cord is required at the rotor head of the double rowassembly and at the end of the single row.

  • Page 33: Inverter Installation

    iShare-Home Residential Solar Energy Solution Inverter Installation Installation space Installation Angle Mark the Position and Drill Fix Wall Bracket Holes Mounting Inverter Grounding PV String Connection* Power Cable of the Terminal Battery Connection** Connection * Cable terminals are made and installed on site **Inverter &...
  • Page 34 iShare-Home Residential Solar Energy Solution Ground terminal connection steps ① The external grounding terminal is located in on the lower right side of the inverter. ② Fix the grounding terminal to the PE H07V-K 6m㎡ wire with a proper tool and lock the grounding terminal to the grounding hole in the lower right side of the inverter.
  • Page 35 iShare-Home Residential Solar Energy Solution Monitoring Device Meter and CT Connection Installation...
  • Page 36 Communicate with Meter L1-S1 RJ45-2 Communicate with BMS L1-S2 Multifunction Relay NO (Normally Open) L2-S1 To detect the CT current and Reserved Slenergy CT cable direction L2-S2 Reserved DRM4/8 L3-S1 DRM3/7 L3-S2 DRM2/6 DRED For Australia and New Zealand DRM1/5...
  • Page 37 iShare-Home Residential Solar Energy Solution Connect the Meter and BMS Communication Inverter Cables Connect Other Cables Electrical Please be awarded that Meter side terminal is prefabricated and installed at the factory Installing the COM Connector Connection...

  • Page 38: Battery Installation

    iShare-Home Residential Solar Energy Solution Battery installation Installation of the Base Install the Battery ControlBox Installation of Fix the Product Slave Battery...

  • Page 39: Battery Electrical Connection

    iShare-Home Residential Solar Energy Solution Battery electrical connection RJ45 terminal connection sequence and definition Color Meter Side Battery Side Power Cable of Battery Connection Orange & White RS485_A3 *Inverter & Battery side terminals are prefabricated Orange RS485_B3 and installed at the factory Green &...

  • Page 40: Inspection Before Commissioning

    iShare-Home Residential Solar Energy Solution Commissioning Abbreviation Complete Name V-Ipv1/2 PV input voltage and current of each MPPT Ppv1/2 PV input power of each MPPT BAT Parameter Battery Parameter APP preparation Charg. Charge ① Install the Setup App and Monitoring App with latest version. Please Dischg.
  • Page 41 iShare-Home Residential Solar Energy Solution WiFi Module Configuration Guide ① ② ③ ④ → → → Prepare a laptop or Searching for the Open the browser and Tap“Scan”，A list Smartphone and turn corresponding WLAN enter 10.10.100.254. of WiFi network on the WLAN in the WLAN connec- names pop up.
  • Page 42 iShare-Home Residential Solar Energy Solution LAN Module Configuration Guide If DHCP is enabled on the router, the LAN module does not need to be configured. Otherwise, the LAN module will need to be configured on inverter screen. ① Find the “General Settings” by short pressing the button on the inverter screen.
  • Page 43 iShare-Home Residential Solar Energy Solution Local configuration App Local configuration App is designed for quick configuration of hybrid inverters, offering features such as safety code, battery brand and type, work modes, and off-grid application settings through WiFi direct connection, etc.There are two connection modes, WiFi direct connection and router connection.
  • Page 44 iShare-Home Residential Solar Energy Solution Indicator Monitoring Device...
  • Page 45 iShare-Home Residential Solar Energy Solution Easy Energy Easy Life iShare-Home Residential Solar Energy Solution...
