LED light
& holder
B
A
Attaching the LED Light
Instructions for a Walker
A1. Of the two rubber straps included,
choose the one with a 10-degree ang-
led light attachment section.
A2. Push the light into the slot of the
strap until it snaps in place.
A3. Attach the light to the Walker,
either on the semi-vertical frame
tube just below the height adjust-
ment quick-release lever, or on the
black semi-vertical grip tube.
A4. Pull the strap tight and fix it with
the plastic hook.
Thank you for choosing the 200 Lumen
Trionic LED Front Light.
This manual both shows how you attach the
LED light on a Walker (left column below)
and also how you attach it on a Veloped (right
column below).
In the left-hand photo, A shows the 10-degree
angled strap for attaching the light on a Walk-
er. B shows the 0-degree angled strap for
attaching the light on a Veloped.
Instructions for a Veloped
B1. Of the two rubber straps included,
choose the one with a 0-degree ang-
led light attachment section.
B2. Push the light into the slot of the
strap until it snaps in place.
B3. Attach the light to the Veloped,
preferably the right or left of the
hinge on the U-shaped grip bar. Pull
the strap tight and fix it with the
plastic hook.
B4. Pull the strap tight and fix it with
the plastic hook.
