- Page 1 ACT AON1210C Optical Receiver Quick Reference Guide Revision E...
- Page 2 Quick Reference Guide Revision E Copyright © 2024 Ascent Communication Technology Limited. All rights reserved. Reproduction in any manner whatsoever without the express written permission of Ascent Communication Technology is strictly forbidden. This document is produced to assist professional and properly trained personnel with installation and maintenance issues for the product.
- Page 3 AON1210C Smart Optical Receiver Table of Contents 1 Product Summary ........................4 2 Performance Characteristics ....................4 3 Technical Specifications ......................4 4 Block Diagram ........................5 5 Structure Description ......................6 6 Relation Table of Input Optical Power and CNR ..............7 7 Function Display and Operating Instruction ................
- Page 4 AON1210C Smart Optical Receiver AON1200C Series 1 or 2-port Optical Node is part of ACT Deep Fiber solution, which has been designed to deliver high quality CATV and other advanced services. The cost-effective node platform helps operators expand bandwidth of their existing HFC network while minimizing capital investment.
- Page 5 AON1210C Smart Optical Receiver RF Parameters Frequency Range 45 MHz to 862/1003 MHz Flatness in Band ±0.75 dB Rated Output Level ≥108 dBµV Max Output Level ≥112 dBµV (-9 dBm to +2 dBm optical power receiving) ≥116 dBµV (-7 dBm to +2 dBm optical power receiving) Output Return Loss ≥16 dB Output Impedance...
- Page 6 AON1210C Smart Optical Receiver 1. Working indicator 2. Transponder connecting wire 3. Power interface 4. LED digital display tube 5. Enter key 6. Down key 7. Up key 8. AC220V input port 9. Switching power supply 10. AC60V jump 11. OUT 1 12.
- Page 7 AON1210C Smart Optical Receiver Mode: Mode selection button, total twelve modes, press the mode selection button to enter the corresponding status display, twelve modes to cycle. The following is the detailed instructions: Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 7 of 14...
- Page 8 Opening the IE browser and entering the equipment IP address leads to the following interface. Default IP is 192.168.1.168. Enter the user name admin and password ascent (factory default), to show the following interface: Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com...
- Page 9 AON1210C Smart Optical Receiver There are 5 sub-interfaces: 1. Device parameter interface: Describes the device parameter display and configuration menu. 2. Common Parameter interface: Describes the common parameters such as S/N, device model, MAC address, temperature and so on. 3. Trap address interface: Describes the current alarming parameter. 4.
- Page 10 AON1210C Smart Optical Receiver Click Network parameter to open the following interface: Click Modify password to open the following interface: Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 10 of 14...
- Page 11 AON1210C Smart Optical Receiver If users configured the network management transponder, need to do the following settings: Transponder IP setup instruction: Network management directly modify: 1. Default IP is 192.168.1.168, default gateway is 192.168.1.1, default subnet mask is 255.255.255.0 2. Connect the computer and transponder (can be direct connected), and change the computer IP to 192.168.1.XXX (XXX is any number from 0 to 255 except 168);...
- Page 12 AON1210C Smart Optical Receiver Failure phenomenon Failure cause Solution After connecting the network, 1. The optical input power of the 1. Check the optical input power and make the image of the optical contact optical receiver is too high, make appropriate adjustments to make it in the specified point has obvious netlike curve or the output level of the optical...
- Page 13 AON1210C Smart Optical Receiver 3. Tightly closed the equipment enclosure to ensure the shielding effect; if possible add shielding cover to the optical contact point and reliable grounding. After connecting the network, Power supply AC ripple Check grounding situation of the equipment, make the images of several optical interference because of the bad sure that every equipment in the line has been...
- Page 14 Phone: +84 243 795 5917 WEB: www.ascentcomtec.com EMAIL: sales@ascentcomtec.com Specifications and product availability are subject to change without notice. Copyright © 2024 Ascent Communication Technology Limited. All rights reserved. Ver. ACT_AON1210C_Optical_Node_QRG_V1e_Oct_2021 Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 14 of 14...
