AS ONE NAK Series Manual

Analog hotplate

Advertisement

1-4600-82 NAK-2K
1-4600-83 NAK-1K
Thank you for your selecting Analog Hotplate NAK Series.
For your safety & life span of the product, please read the manual fully before
using and keep these instructions.
Please read this manual carefully before
using and keep these instructions.
NAK MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NAK Series and is the answer not in the manual?

Questions and answers

Summary of Contents for AS ONE NAK Series

  • Page 1 1-4600-82 NAK-2K 1-4600-83 NAK-1K NAK MANUAL Thank you for your selecting Analog Hotplate NAK Series. For your safety & life span of the product, please read the manual fully before using and keep these instructions.
  • Page 3: Caution For Safety

    Caution for safety Please keep these instructions before using and use the product, properly. By following the suggestions below, you can prevent harm and damage caused by improper use. Please keep these instructions for the safety. Warning mark & meaning Danger of death or serious injury is near at hand with Danger wrong handling.
  • Page 4 Caution of using Caution Please use the product safely and read the following well before using. Please keep the manual near at hand and deliver the product together with this manual always. *This Hot plate is for indoor, please do not use in other places. *This Hotplate is for an experiment.
  • Page 5: Setting The Machine

    Setting the machine * Please avoid the place where * Please avoid the place where * Please place the product to a there is covered by dust or there is a shock and vibration. distance from the machinery corrosive gas is generated. generates noise.
  • Page 6 Dimensions NAK-1K (unit: mm) NAK-2K...
  • Page 7: Specifications

    Specifications Model NAK-1K NAK-2K Dimension 240×280×90mm 320×360×90mm Current consumption Max. 750W Max. 1100W Heater capacity Approx. 675W Approx. 1000W ±2 ℃ Temp. range of the (200 ℃ setting, Room temperature 25 ℃ , No load, Using inner sensor) upper plate Power supply 220VAC(50/60Hz) Indication method...
  • Page 8 Model organization Classification Hot plate(NINOS) NAK-1K S size(Plate 170×170mm) Classification of temperature range NAK-2K M size(Plate 250×250mm) Function Proportion control function It adjusts and controls the output within the fixed period in proportion to the deviation of the PV and SV. LED bar display Green Green...
  • Page 9 There is a bimetal switch operation button under the Push point of ventilation opening on the bottom of the product. If the position is difÏcult to understand, please check the position bimetal switch by illuminating it with a penlight, etc. Image of the switch pushed When the bimetal switch is activated, the metal plate inside...
  • Page 10 • The heater is a consumable item and may need to be replaced. This includes the case that the temperature does not rise due to heater disconnection. To replace the heater, please contact the AS ONE dealer. Warning Do not disassemble, repair or modify the product.
  • Page 14: Product Information

    Contact information Department in charge: AS ONE Corporation Overseas Sales Department Address: 2-1-27, Edobori, Nishi-ku, Osaka, 550-8527, Japan TEL: 81-6-6447-8905 FAX: 81-6-6447-8681 E-mail: asoneint@so.as-1.co.jp <Product Information> Please use the QR code of the following representative model number. NAK-1K (1-4600-83) QR code is a registered trademark of DENSO WAVE INCORPORATED.

This manual is also suitable for:

Nak-2kNak-1k1-4600-821-4600-83
