Related Manuals for Nebula Capsule 3 Laser
Summary of Contents for Nebula Capsule 3 Laser
- Page 1 What’s Included Nebula Capsule 3 Laser GTV Adapter Charging Cable Remote Control AAA Battery × 2 Quick Start Guide...
-
Page 2: Front View
At a Glance 1. Projector Front View Lens Camera (for autofocus and auto keystone correction) -
Page 3: Rear View
Rear View Speaker AUX-OUT Socket • Connect to an external sound output device. Infrared Receiver Mode Button • Press to switch between Bluetooth speaker mode and projector mode. Power Button • Press and hold for 1.5 seconds to power on / off. •... -
Page 4: Top View
Top View Volume Up / Down Buttons Confirmation Button Return Button Navigation Buttons Bottom View 1/4" Tripod Socket... - Page 5 Dimensions 167.5 (H) x 83.0 (D) mm / 6.6 (H) × 3.3 (D) in 83.0mm...
-
Page 6: Remote Control
2. Remote Control Remote Control: Google TV RCU Model: D0442X Auto image adjustment Activate the Google Assistant Power on / off / switch Confirm a selection / to standby mode pause / resume Navigation Access the home menu Return button Access more options Volume down Volume up... - Page 7 3. LED Light Guide Button LED Status Description Steady blue Powered on Light off Powered off Steady orange Standby mode Steady green Fully charged Flashing red Low battery Ready to pair / Bluetooth pairing / Flashing blue Bluetooth disconnected (Bluetooth speaker mode) Bluetooth connected (Bluetooth Steady blue...
-
Page 8: Getting Started
Getting Started 1. Prepare the Remote ① Slide to open the battery compartment. ② Insert new batteries matching the polarity (+/-) and close the battery compartment. ③ For first-time use, follow the on-screen instructions to pair the remote with your projector. The distance between the remote and the projector should not exceed 20 m / 65 ft . - Page 9 • It is unnecessary to tilt the projector towards the projection surface. You can correct the projection image with the built-in autofocus and auto-keystone correction. • You may also install the projector onto a tripod (sold separately). • The distance between the projector and the projection surface determines the projection image size.
-
Page 10: Power On/Off
3. Charge Your Projector For first-time use, fully charge your projector using the provided adapter and charging cable. 4. Power On / Off Press and hold the projector power button for 1.5 seconds to power on / off. 1.5” • You can also press and hold the power button on the remote for 1.5 seconds to power off. - Page 11 5. Autofocus and Auto Keystone Correction To enable autofocus and auto keystone correction, slightly move the projector or press the on the remote. 6. Setup When using the projector for the first time, follow the on-screen display (OSD) instructions to complete the basic setup. •...
- Page 12 ① Download the Nebula Connect app from the App Store (iOS devices) or Google Play (Android devices). ② Enable Bluetooth on your smartphone. ③ Open the Nebula Connect app and select [Capsule 3 Laser] as the device to be connected. ④ Follow the on-screen instructions to complete connection setup.
- Page 13 2. Projector On the home page, select > [Projector] and press Auto Keystone Correction Settings [Auto Keystone Correction By Remote]: Enable or disable auto keystone correction by remote. [Auto Keystone Correction At Startup]: Automatically perform keystone correction when the projector powers on. [Auto Keystone Correction After Movement]: Automatically perform keystone correction when you move the projector.
- Page 14 [Smart Solutions]: Receive alerts when issues are detected. • [Projection Angle Alert]: Receive alerts when issues are detected. • [Fine Tuning Popup]: Receive a popup after Auto Gridless Keystone Correction. • [Nebula Smart Popup]: Receive prompts when the projector status changes.
- Page 15 Picture [Brightness]: Adjust brightness based on your environment. [Standard]: Keeps natural looking colors with a balance of warm and cool tones. [Eco]: Reduce brightness to save power. [Auto]: Maximum brightness when connected to power; switch to Eco Mode when power is disconnected.
- Page 16 [Advanced Settings]: Customize advanced settings to enhance image quality. [Color Temperature]: Switch between • different color temperatures. • [Red Gain]: Manually set the value of red gain. • [Green Gain]: Manually set the value of green gain. [Blue Gain]: Manually set the value of blue •...
- Page 17 Sound [Movie]: Creates a surround-sound listening experience for watching movies. [Music]: Enhances the treble for listening to music. [Outdoors]: Increases volume for playing audio / video outdoors. [Custom]: Manually set audio settings such as balance, bass, and treble. [Turn on the Bluetooth Speaker Mode]: Enable to use the projector as a Bluetooth speaker.
- Page 18 3. Apps ① On the home page, select > [Apps], and press ② Select an app to check its current version, open or force stop it, review the storage it uses, clear its data or cache, uninstall it, or enable/disable its notifications and permissions. 4.
- Page 19 Restart the system. [Restart] 5. Others On the home page, select to find more setting options. [Accounts & Sign-in] Sign in to make the most of Google TV. [Privacy] Customize your privacy preferences. [Remotes & Accessories] Search for accessories for pairing. Leave your feedback on the projector or [Help &...
-
Page 20: Using Your Projector
① Connect your device and projector to the same wireless network. ② Open the streaming app on your device. ③ Play a video clip and tap the cast icon on the video screen. ④ Select Capsule 3 Laser to connect. The projector will mirror the video screen on your device. - Page 21 3.2 Cast Device Screen You can cast the entire screen from your device to the projector. Before that, please ensure Nebula Capsule 3 Laser and your device are connected to the same wireless network. •...
- Page 22 Install the Nebula Cast app on your projector. Open Nebula Cast app and follow the on-screen instructions to complete the process. 4. Play from HDMI Playback Devices The projector can be connected to various HDMI playback devices such as a TV box, TV stick, DVD player, set-top box (STB), gaming console, or other devices.
- Page 23 ③ Select music, videos, or photos from the USB drive that you want to play and press ④ Press to stop playback. USB-C 6. Play Through External Sound Devices This projector can also be connected to external sound output devices, including headphones and speakers;...
- Page 24 B: On the home page, select >Settings > Display & Sound > Sound > Turn on the Bluetooth Speaker Mode. ② Enable Bluetooth on your smartphone and select Nebula Capsule 3 Laser to connect. < Settings Bluetooth...
-
Page 25: System Update
System Update To fully enhance your experience with this product with the latest features, you are recommended to update the system from time to time. To update the system, go to [Settings] > [System] > [About] > [System update]. Specifications Specifications are subject to change without notice. - Page 26 Throw Distance 1.06~3.18 m / 3.48~10.43 ft Light Source Laser Focus Auto Keystone Correction Auto Speaker Output Power Noise <28dB WiFi5 802.11a/b/g/n/ac ,Dual Frequency Wi-Fi 2.4/5GHz Bluetooth Version Bluetooth Range 25 m / 82 ft USB Format FAT, FAT32 For Europe and UK, 0°C to 25°C Operating Temperature For other countries and regions, 0°C to 35°C / 32°F to 95°F...
-
Page 27: Troubleshooting
Troubleshooting ① Fails to Power On • The projector may be out of power. Charge the projector for 15-30 minutes and see if the power button light turns on. ② Cannot Charge • Use the included adapter and charging cable to charge the projector. - Page 28 • Connect the HDMI playback device to your TV via HDMI cable to check if the device or cable malfunctions. • Adjust the HDMI playback device's output resolution / frequency to be the same as the projector's. ⑦ How to Play Videos without Wi-Fi •...
