Visit www.clevelandrange.com to locate a

service or sales representative in your area.

SteamCraft Power 10

Gas Steam Boiler & Convection Steamer with

Easy Timer

Operation, Installation & Maintenance Manual

This manual is updated as new information and models are released. Visit our website for the latest manual.

MODEL:

24CGP10

Read the manual thoroughly.

Improper installation, operation or

maintenance can cause property

damage, injury, or death.

For your future reference.

Model #

Serial #

Cleveland

Part # KE004039-2 Rev D

February 2024

Table of Contents

Need help?

Do you have a question about the SteamCraft Power 10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cleveland SteamCraft Power 10

Page 1 Cleveland Visit www.clevelandrange.com to locate a service or sales representative in your area. SteamCraft Power 10 Gas Steam Boiler & Convection Steamer with Easy Timer Operation, Installation & Maintenance Manual This manual is updated as new information and models are released. Visit our website for the latest manual.
Page 2 Cleveland Range, LLC has aux biens résultant de l'utilisation, de la fallecimiento, lesiones, daños al equipo o made every effort to provide accurate mauvaise utilisation ou du manquement daños a la propiedad resultantes de la...
Page 3 FOR YOUR SAFETY / POUR VOTRE SÉCURITÉ / PARA SU SEGURIDAD FOR YOUR SAFETY POUR VOTRE SÉCURITÉ PARA SU SEGURIDAD Do not store or use gasoline or any Ne pas entreposer ou utiliser No guarde ni use gasolina o other flammable liquids and vapours d'essence ou d'autres liquides ou cualesquiera otros líquidos o in the vicinity of this or any other...
Page 4 WARNING / AVERTISSEMENT / ADVERTENCIA Inspect unit daily for proper Heavy. / Lourd. / Pesado. operation. / Inspecter le bloc quotidiennement pour garantir le fonctionnement normal. / Team or mechanical lift. / Levage en équipe ou Inspeccione diariamente el mécanique. / Levantamiento en equipo o funcionamiento correcto de la mecánico.
Page 5: Table Of Contents
OPERATION, INSTALLATION & MAINTENANCE MANUAL MODEL 24CGP10 TABLE OF CONTENTS CHAPTER 1 GENERAL INFORMATION ..........................5 Laws, Codes, and Regulations ............................ 5 Gas Leak Instructions ..............................5 Operational Safety............................... 5 Inspection for Shipping Damage ..........................6 CHAPTER 2 PRODUCT INFORMATION ..........................7 Product Information ..............................
Page 6: Chapter 1 General Information
Improper installation, adjustment, alteration, service, or maintenance of this appliance, or installation of a damaged appliance can result in DEATH, INJURY, EQUIPMENT DAMAGE, and void the warranty. NEVER install damaged appliances, equipment, or accessories. ALWAYS have installation and service performed by qualified Cleveland Range authorized personnel. B. Gas Leak Instructions ⚠ DANGER Gas leaks are fire and explosion hazards.
Page 7: Inspection For Shipping Damage
This appliance must be level both front-to-back and side-to-side in all installations. NEVER operate this appliance out of level. If this appliance is suspected to be out of level, shut it down at once and call your qualified Cleveland Range authorized service agency immediately.
Page 8: Chapter 2 Product Information
For further information, contact your Cleveland Range sales representative or Cleveland Range. B. Model Numbers and Serial Numbers 1. Cleveland Range, LLC assigns two product identification numbers to each appliance: a model number and a serial number. 2. Please provide the model number and serial number when you contact Cleveland Range or a qualified Cleveland Range authorized service representative.
Page 9: Product Views
D. Product Views Figure 2-1 24CGP10 PRODUCT VIEWS Plan, Front, and Side Views Dimensions in Inches...
Page 10 Figure 2-2 24CGP10 Utility Locations...
Page 11: Chapter 3 Installation Procedure
NEVER operate this appliance out of level. If this appliance is suspected to be out of level, shut it down at once and call your qualified Cleveland Range authorized service agency immediately.
Page 12: Positioning And Leveling The Steamer
appliances in the area under the hood, including this appliance. • The BTU/HR for a 24CGP10 is 240,000. c) If an existing hood does not meet all specifications, a new one must be constructed. d) When determining hood size, include operating clearances. See Figure 2-1. C.
Page 13: Install Gas Supply Lines
7. Do NOT connect the drain outlet extension line directly into a floor drain or a sewer line. 8. Do NOT connect this appliance’s drain directly to drains or to the plumbing of any other equipment. 9. Do NOT install a trap or shutoff in the drain line. 10.
Page 14: Install Electric Power Lines
This unit is not suitable for connection to a GFCI (Ground fault Circuit Interrupter). • Cleveland Range recommends that the unit be connected to the electrical system, using a flexible conduit system compliant with the applicable codes. 3. A main disconnect switch and a separate fuse or breaker should be installed near the unit as shown in Figure 3-4.
Page 15: Water Supply Requirements And Installation
H. Water Supply Requirements and Installation 1. Water Supply Requirements ⚠ CAUTION Using water not within the limits specified in this manual could void or reduce Cleveland Range’s warranty coverage of the steamer. a) Water Quality As with any steam generating equipment, poor water quality degrades the performance of the steamer.
Page 16 • Two 40 mesh water strainers (dirt filters), Cleveland Range Part Number 19870, are factory installed. • Flush the water supply lines before connecting the lines to the appliance.
Page 17: Installation Checklist
Installation Checklist Installation Checklist TASK REFERENCE COMPLETED Chapter Number (initial and Date) Preparation Check Operating Location Clearances Chapter 2 Section D Test Supply Water Quality Chapter 3 Section H Water Supply Requirements Met Chapter 3 Section H Electric Power Requirements Met Chapter 3 Section G Installation Check Level Front-to-Back and Side-to-Side...
Page 18: Chapter 4 Cooking With The 24Cgp10
If the steamer door is stuck shut: • Turn OFF the steamer. • Call a qualified Cleveland Range authorized service technician. • Wait for the steamer to cool before servicing. ⚠ CAUTION Some food drip juices. Use a solid catch pan under perforated pans when cooking food that drips juices. Dripping juices can cause burns and clog the drain.
Page 19 • The steamer compartment of the steamer is equipped with an automatic door interlock switch that turns off the heating elements and condenser when the door to the compartment is opened. ⚠ WARNING BURN and SCALD HAZARD Even though the heat shuts off as soon as the door is opened, it may take up to a minute for production of steam to end and residual steam in the system to clear from the cooking compartment.
Page 20: Chapter 5 Easy Timer Operating Instructions
CHAPTER 5 EASY TIMER OPERATING INSTRUCTIONS DIGITAL DISPLAY CONTROL KNOB Enabled with TIMED mode TIMER START/STOP BUTTON in TIMED mode TIMED/MANUAL SWITCH BUTTON (Press for 5 sec) ON-OFF SWITCH ⚠ CAUTION Press switch and button with fingertips only. INJURY and EQUIPMENT DAMAGE can result from pressing switches and buttons with anything else.
Page 21: Main External Power Switch
A. Main External Power Switch Usually, the steamers main external power switch is left ON. If the main external power switch was left in the OFF position, turn it ON as follows. 1. Check that the water supply valves are open. 2.
Page 22 1. Turn the ON/OFF switch to the ON position to energize the steamer control panel. The digital display on the control panel lights, the combustion blower turns ON to purge the generator and water fills the steam generator. 2. When the generator is full, the steamer automatically stops water flow. 3.
Page 23: Lighting And Shutdown Instructions
Do not alter any adjustments on this electronic control or gas valve. If adjustment is required, contact an authorized service center. Cleveland Range is in no way responsible for the operation or safety of this equipment if the controller, valve, or igniter probe are adjusted by anyone other than a Cleveland Range authorized service representative.
Page 24: Chapter 6 Shutdown And Cleaning Procedures
Based on the water quality analysis done before installation, and the amount of use, make, and post a blowdown schedule. • Contact your qualified Cleveland Range authorized service agency or Cleveland Range for more information about maintenance scheduling, products, and services. b) Blowdown Schedule Guidelines:...
Page 25 increase the door gasket life. 6. Replace the cleaned slide racks. 7. Wipe the exterior with a damp cloth only. NEVER HOSE DOWN THE STEAMER. Electrical components inside the unit will not function correctly if wet or damp. 8. After cleaning, leave the steamer door open until the next steamer operation. This prevents compartment odor buildup and increases gasket life.
Page 26: Chapter 7 Operating Tests And Final Checkout Procedures
This should be done at a union or connection as close as possible to the inlet of the automatic gas valve. g) If the burner does not light after the third attempt, call a Cleveland Range authorized service representative to adjust the burner controls.
Page 27: Startup Procedure With The Appliance De-Energized
2. Shutdown Instructions a) Turn off electrical power to the steamer, at both the ON/OFF switches and the main power switch. b) Turn off gas supply at the main manual gas valve. B. Startup Procedure with the Appliance De-Energized 1. Start with or the Main External Power Switch OFF. 2.
Page 28: Operating Test Procedures
• Start this test over. 4. The automatic blowdown cycle opens the fill and rinse valves. 5. The drain valve remains open. 6. The drain valve and water column float assembly are flushed with fresh water. 7. Stop the blowdown cycle before it is complete by turning the ON/OFF switch ON. a) The operating controls energize.
Page 29: Optional Compartment Door Steam Shut Off Switch (Scs)
3. Stand to the hinge side and back from the upper door and carefully open the upper door. 4. Steaming stops within a minute. 5. If steaming does not stop within a minute: Shut down the appliance and call your qualified Cleveland Range authorized service representative.
Page 30: Chapter 8 Preventative Maintenance
• Increase the frequency of maintenance as needed depending on use and water quality. • Contact your qualified Cleveland Range authorized service agency or Cleveland Range for more information about maintenance scheduling, products, and services. B. Maintenance and Service Records 1.
Page 31 ⚠ DANGER The liquid solution in Cleveland Range Descaler Solution Part No. 106174 or 1061741 can be harmful if not handled properly. Follow these basic safety rules for handling and using this product. Instructions and warnings on container labels supersede all other warnings and instructions.
Page 32 NOTICES regarding the Manual Descaling Procedure • Cleveland Range recommends DISSOLVE® Descaler Solution, Part No. 106174. • Use no other system of steamer descaling. • Appropriate warnings and safe handling procedures must be provided to handlers and users. • Instructions and warnings on Dissolve® containers and Material Safety Data Sheets supersede and replace instructions and warnings in this manual.
Page 33: Yearly Maintenance
16) After the timer counts down, turn ON/OFF switch to OFF to start Automatic Blowdown. 17) Descaling is complete, resume normal startup, cooking, and shutdown procedure. F. Yearly Maintenance 1. Clean the Water Line Strainer • See Figure 8-2. • Clean the water line strainers at least once a year.
Page 34: Chapter 9 Troubleshooting Guide
CHAPTER 9 TROUBLESHOOTING GUIDE The Troubleshooting guide includes a list of symptoms that may be encountered during routine operation and maintenance. The first column on the left (PROBLEM) describes these symptoms. The second column lists the possible causes for the problem in column one. The third column lists possible remedies for the problems and causes in columns one and two.
Page 35 Reduced steam flow into Steam generator scale buildup. Descale steam generator with cooking compartment. Cleveland Range approved descaler. Gas inlet pressure is low. The unit requires a minimum inlet pressure of 4.5 in. W.C. for NATURAL GAS, or 11 in. W.C. for LIQUID PROPANE, to operate.
Page 36 Water Supply. See note # 3. proper operation see note condenser line. Steam generator scale buildup. Descale steam generator with Cleveland Range approved descaler. Compartment overloaded with too much Put less food into pan. Use fewer pans. food. Condenser water is turned OFF.
Page 37 TROUBLESHOOTING NOTES 1. If problem is inside the steamer, call an authorized service representative. Cleveland Range will not pay for warranty repairs by unauthorized repair centers. 2. Proper installation of the steamer is the responsibility of the owner or installer. A qualified installer or technician should be contacted to correct the installation.
Page 38 Water leaking from the door gasket can be a sign of a blocked drain. If the drain is blocked, hot water can accumulate inside the compartment and spill out when the door is opened. 8. Replacement descale caps and gaskets can be ordered from a Cleveland Range authorized maintenance and repair center.
Page 39 Cleveland Cleveland Range, LLC 760 Beta Drive, Unit D Mayfield Village, Ohio 44143 216.481.4900 800.338.2204 Every new piece of Welbilt Foodservice equipment comes with KitchenCare® and you choose the level of service that meets your operational needs from one restaurant to multiple locations StarCare –...
