Cleveland GFB-10 Specifications

SINCE 1922
GAS FIRED STEAM BOILERS
Cleveland Standard Features
Complete skid-mounted and piped, gas fired Steam Boiler with
Vertical Return System and Blow Down Separator
Available for Pressure Ratings from 15 to 150 psi
Vertical Tubeless design
Fully insulated Boiler with top mounted, down-fired burners
High Temperature Insulation assists thermal efficiency of 80%
Spinning Cyclonic Flame travels down the entire length of the
Combustion Chamber
Top Flame Retainer increases occupancy time of flue gases to
complete combustion process
Operating Pressure Control and High Limit Pressure Control
with Manual Reset
Water Column with Water Gauge Assembly
All necessary valves are included
Automatic Water Feed System with probe type Water Level
Controls and single phase Motor for Pump
Steam Outlet conveniently located at top of Boiler
Control Panel factory mounted and wired, ready for power con-
nection
Built and stamped to A.S.M.E. Code
Registered with the National Board of Boiler & Pressure Vessel
Inspectors
Options & Accessories
Stainless Steel outer Jacket
Automatic Boiler Blow-down Controls
Applicable Controls to meet the various special insurance,
local, state or federal code requirements
Electric heated Steam Boilers
Oil-fired Steam Boilers
Cleveland Range, 1333 East 179th St., Cleveland, Ohio, U.S.A. 44110
LLC
Ph: 1-216-481-4900
INNOVATIVE STEAM COOKING SOLUTIONS
MODELS: GFB-6 GFB-15
GFB-10 GFB-20
ITEM NUMBER __________________________________________
JOB NAME / NUMBER __________________________________
Short Form Specifications
Shall be CLEVELAND Model GFB -____, gas-fired, vertical, tube-
less LARGE STEAM BOILER System, _____H.P. (horse power);
Complete with Power Burners; Skid mounted and piped with
Vertical Condensate Return System and Blow-Down Separator
Package; Factory assembled as a self-contained unit, in accor-
dance to U.L. requirements, and A.S.M.E. Section 1 (one) Code;
Guaranteed production of _______ pounds of Steam per hour at
212˚F.
Fx: 1-216-481-3782 Web Site: www.clevelandrange.com
Cook/Chill Systems
GFB-30
GFB-50
XIV 51
SECT. PAGE
0402
