The information provided in this manual is for general guidance on the use and maintenance of the Firefly system� While every effort has been made to ensure the accuracy and completeness of the information contained in this document, Firefly Integrations, LLC assumes no responsibility for errors or omissions, or for damages resulting from the use of the information contained herein�...
Navigation Tap this icon to access the main control screen, which divides the screen into five quadrants for quick and easy control of lights, tanks, electricity, HVAC, Awnings, and Sofa Bed Tap this icon to access the screen that controls all interior and exterior lights;...
Home Screen Light Master Control Turning On All Lights Instructions To turn on all interior lights, The Light Master function press and hold Light Master allows you to control all On for at least 1 second. interior lights at once. Turning Off All Lights Individual Lights Press Light Master Off to...
Home Screen The Black Tank epresents the level of waste The black tank r water from the toilet. Here, the black bar indicates the tank is 67% full. LPG (Liquid Propane Gas) Tank The LPG tank shows how much propane is available for appliances like heating or cooking.
Lights • This screen will control the lighting for the entire coach. Tap any button to turn the desired light On/Off. • Lights with up/down arrows are dimmable. Press and hold these buttons to ramp the brightness up or down. Tap the buttons to toggle On/Off.
Climate Control • This screen works the same as the climate portion on your home screen with just a couple additional options. • The Auto button is for the climate fan alone.
Settings Tap to navigate to the Mira connection screen. Tap to navigate to the When Auto Dimming is enabled, Network Diagnostics page. the screen will enter sleep mode after 60 seconds of inactivity. Tap anywhere on the screen to wake it up. Tap to disable the touchscreen for 15 seconds for the purpose of cleaning.
Page 10
Settings Drag the slider to adjust screen brightness. Tap the buttons to set the time or select 24-hour time mode. Floorplan display.
Mobile App • Navigate to this page by tapping on the settings icon and then tapping on Mobile App. • For the purpose of this part of the user guide, we will refer to your static 7” Lyra Screen as “the screen”. •...
Mobile App (Setup) Tap Scan Locate the Mira ID that matches the one dis- played on your Lyra screen. Input the PIN lo- cated beneath the Mira ID on your Lyra screen and tap “Authenticate” on your phone. If this is the first time setting up your mobile app, you will need to enter the pin ID that is displayed on the screen.
Mobile App Pairing Apple location services permissions. You will need to turn on you location services to get the most out of the Mira App pairing to your Lyra screen. Android location services permissions.
Page 14
Mobile Settings Navigate to the settings by tapping the triangle at the bottom of the screen. Then tap the gear icon. Tap the Temperature Units selection to choose between Fahrenheit and Celsius. This is your system information and Mira information. Tap “Unpair”...
Mobile Settings Tap “Diagnostics” to see circuit status and device list� Tap “Custom Settings” to change your color theme, customize your home screen, the default landing page, and then reset your settings back to default� Tap “Advanced Settings” to set your Mira Pin, Reset the Module, or Unpair from Mira�...
Wireless Switch Pairing Red switch indicator with a zero reading – The switch is currently disconnected from the screen. The wireless switch panel in your coach will illuminate a green LED whenever a button is pressed. If the LED on your switch panel does not illuminate when you press a button on your switch, you will need to replace the 2032 coin cell battery.
The system also controls hot water. You can choose between ECO, HOT, or OFF modes depending on your needs. This Water Heater Modes: can be done through the Firefly system Mode: Energy-efficient hot water heating, or directly on the Truma CP Plus control panel.
Page 19
Just like in the other models, the Westfalia integrates and Truma Combi systems are ideal for efficient these systems into the Firefly touchscreen, allowing space heating and cooling. They are specifically you to control both the air conditioning and heating chosen to maximize comfort while minimizing energy from one central location.
Page 20
Please be prepared with the Year, Make, and Model of your unit as well as the GUI version and the Control Logic Version of the software on your Firefly system� This information can be found on the Settings page of the main touchscreen� We look forward to serving you!
