- Page 1 USER MANUAL AND PRODUCT SPECIFICATIONS LIGHT VT-194D WINE COOLER WITH 2-REFRIGERATOR DRAWERS...
- Page 2 WARNING SAFETY REQUIREMENTS – REFRIGERATORS ARE TO BE STABLE WHEN DOORS AND/OR DRAWERS ARE OPEN AND FULLY LOADED. THE INCLUDED ANTI-TIP BRACKETS MUST BE INSTALLED TO THE GROUND AS INDICATED BELOW. ANTI-TIP BRACKET INSTALLATION WARNING To avoid the risk of serious personal injury, damage to the appliance as well as to prevent a tipping hazard, it must be secured to the floor with anti-tip brackets and screws (supplied).
-
Page 3: Table Of Contents
CONTENTS WARRANTY, SERVICE AND SUPPORT Warranty Registration Service and Support IMPORTANT SAFETY INFORMATION Before Using Your Appliance Critical Safety Information PRODUCT FEATURES Specifications INSTALLATION INSTRUCTIONS Accessories Included STRUCTURE Shelving Moving of Shelves Installing the Door Handle Reversing the Door CONTROL PANEL OPERATION PROCEDURE CLEANING AND MAINTENANCE TROUBLESHOOTING... -
Page 4: Warranty, Service And Support
WARRANTY ON COMPRESSOR ON THE UNIT THANK YOU FOR PURCHASING THE SNOMASTER VT-194D, UPRIGHT 108 BOTTLE WINE COOLER WITH 2-REFRIGERATOR DRAWERS WARRANTY, SERVICE AND SUPPORT This product is warranted for 5 years on the compressor, 3 years on the unit and 1 year on all parts not listed from the date of purchase. -
Page 5: Important Safety Information
• Please unplug the appliance or disconnect the power before performing any cleaning, maintenance, or servicing. • If the appliance power supply cord is damaged, it must be replaced by SnoMaster, its approved agents, or a similarly qualified person to prevent any hazard. - Page 6 • It is recommended that the circuit breaker size should be no more than 20 amps. • This appliance operates on a single-phase voltage of 220V/50Hz, to avoid electrical surges, it is advised to use a surge protector plug. • Cleaning and maintenance should be supervised by adults, especially if children are involved.
-
Page 7: Product Features
PRODUCT FEATURES TEMPERED GLASS REVERSIBLE DOOR | 2-REFRIGERATOR DRAWERS | 9 + 1 BEECHWOOD SHELVING | FAN ASSISTED COOLING | INTERIOR LED LIGHT | INTERNAL DIGITAL THERMOSTAT SPECIFICATIONS: • Dimensions (mm) Unit: (H) 1950 (L) 598 (W) 690 • Dimensions (mm) Packaged: (H) 1975 (L) 660 (D) 770 •... -
Page 8: Accessories Included
ACCESSORIES INCLUDED 1 x Door Handle 9 + 1 x BEECHWOOD SHELVES STRUCTURE Door Hinge Digital Thermostat LIGHT Tempered Glass Door Door Handle Beechwood Shelves 54L Refrigerator Drawer Handle 54L Refrigerator Drawer 45L Refrigerator Drawer Handle 45L Refrigerator Drawer Kickplate Adjustable Feet... -
Page 9: Shelving
SHELVING Your appliance was designed to store a maximum number of bottles securely. We recommend that you observe the tips below to optimise loading: • Remove all packing materials from shelves once appliance is stable and ready for bottle storage. •... -
Page 10: Installing The Door Handle
INSTALLING THE DOOR HANDLE Pull back the door seal/gasket behind the handle location. 2. Insert screws into the pre-drilled screw holes. 3. Attach handle and tighten screws. 4. Press door seal/gasket back into place. REVERSING THE DOOR Before You Begin: Tape down shelves to avoid movement during the process. - Page 11 Follow the diagram for visual assistance during each step. Figure 1 Figure 2 Figure 3 Installing the Door: Remove the screws and two rubber caps covering the holes on the left side of the lower hinge position. 2. Take the lower hinge from the left side and install it to the left side lower hinge position.
- Page 12 Figure 4 Figure 5 Figure 6 Figure 7 Figure 8...
-
Page 13: Control Panel
CONTROL PANEL The digital thermostat can be found inside the appliance. LED LIGHT BUTTON & UPPER TEMP ZONE LOWER TEMP ZONE TEMP SET °C / °F TOGGLE CONTROLS CONTROLS BUTTON BUTTON LIGHT TEMP TEMP ‘UP’ ‘DOWN’ BUTTON BUTTON TEMP TEMP UPPER LOWER ‘UP’... -
Page 14: Food Storage
INTERNAL CLEANING • Remove accessories and clean separately with soap and water (do not use a dishwasher to clean any accessories). • Avoid abrasive materials or detergents. • Rinse with clean water and dry thoroughly. • Reconnect the plug with dry hands after cleaning. EXTERNAL CLEANING •... -
Page 15: Troubleshooting
Should you experience any issues with your appliance and the below troubleshooting tips do not resolve the fault experienced, kindly contact SnoMaster Service Department or your nearest accredited Service Agent: PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE Appliance is not • Check if the appliance is correctly switched on. - Page 16 PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE Smell/Odour • Check for spillages on each shelf/drawer. You may need to remove the shelves/drawers to check that no spillages have settled underneath them. • Double check if all foods and drinks in the appliance have not expired.
- Page 17 PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE Compressor runs • The appliance has leaked or the system may be but the interior is blocked, please contact a service agent. not getting cold The digital display • Check that the appliance is correctly switched is not turning on •...
- Page 18 CAPE TOWN LIFESTYLE CENTRE CENTRE & SERVICE CENTRE & SERVICE CENTRE 49 Koornhof Road 31 Stella Road Meadowdale Montague Gardens Germiston, 1614 Cape Town, 7441 011 392 5315 / 3147 021 100 5695 info@snomaster.co.za info@snomaster.co.za snomaster.co.za @SnoMasterSA SnoMaster SA snomaster_south_africa @SnoMaster...
