- Page 1 Lithium Battery HU6514 LIthium COBALT HEAVY DUTY JUMP STARTER PORTABLE EMERGENCY POWER SUPPLY U S E R M A N U A L hulk4x4.com.au hulk4x4.co.nz...
- Page 2 A BO U T JUMP PA C K The HULK Professional Jump Pack with high discharging rate of Lithium-ion Cobalt batteries has powerful performance for Heavy duty Semi-trucks, buses, airplanes, mine machines, farm & construction equipment. Works with most 12V and 24V gasoline or diesel power vehicles.
-
Page 3: Function Introduction
Lithium Battery F U NC T ION IN TR ODUC T I ON Performance 1. LED display screen 8. Cigarette output port 2. Master ON/OFF switch 9. DC output port x 2 3. ON/Off for USB output 10. Type-C port 4. -
Page 4: Technical Specifications
T EC HNIC AL SPEC IF IC AT IO NS Battery Type Lithium-ion Cobalt Capacity 80,000mAh/296Wh Starting Current 12V - 3,000A 24V - 2,000A Peak Current 12V - 15,000A 24V - 6,000A Unit Dimensions 356 x 128 x 418mm Unit Weight 8.35kg DC Input 18V 2A... - Page 5 Lithium Battery J U M P PAC K C ON TR OL PANE L Master ON/OFF Switch The LED display illuminates when the unit is on. Turn the Master ON/OFF switch to the 12V position to start the 12V system, turn the Master ON/OFF switch to 24V position to start the 24V system.
- Page 6 J U M P PAC K STA R TING G U I DE 1. Personal Safety & Battery Preparation A) Please use safety glasses when jump starting any vehicle. Remove personal metal items such as watches, rings and bracelets when working with a lead-acid battery. It may cause personal injury.
- Page 7 Lithium Battery J U M P PAC K C ON TR OL PANE L Step One Place unit on a flat surface before use. Next, connect the clamps: Red clamp (+) to Red terminal (+) and Black clamp (-)to Black terminal (-).
- Page 8 J U M P PAC K LED DISP LAY 1) Normal System 4) 24V System Activated 7) USB Output Turn the Master ON/OFF The “USB” indicator flashes Turn the Master ON/OFF switch to the 24V position whenever a USB port is switch to the ON position to start the 24V vehicle.
- Page 9 Lithium Battery E RRO R CODE IN DI C ATO R S Low Voltage The voltage of single-cell battery is between 2.4V~1.1V, please connect the charger, press and hold the USB ON/OFF switch until the E0 is not displayed. Reverse Polarity Reverse polarity protection activated.Turn off the Jump Pack.
-
Page 10: Led Indicators
L ED I NDI CATOR S Normal Screen Normal ON/OFF screen. Hold output ON/OFF for 16V. Jump Pack Activated and Connected Indicates the vehicle is ready to be jump started. Search Mode The unit is searching for a battery and current in order to activate the jump starting. - Page 11 Lithium Battery 6. Key Position Ensure that the ignition key/button is turned to first position to detect connection. This will help activate the unit. 7. Can’t Get The Jump Pack to Connect? If the Jump Pack does not show a green “8” when connected to a dead vehicle: (1) Make sure to turn on the Jump Pack before connecting to the dead vehicle.
- Page 12 6) Do not burn or incinerate this product. 7) Use only recommended attachments. Use of attachments NOT sold by HULK Professional or included with the Jump Pack may result in a risk of fire, electric shock or injury to peersons or damage property.
