Quictent Greenhouse Please read, understand, and practice the guidelines in this user manual before use, and keep it for future reference. 20’ x 10’ x 6.6’ (Model: SZ1323G & SZ1323W) 25’ x 10’ x 6.6’ (Model: SZ1324G & SZ1324W)
About Quictent ............Soil Foundation Preparation ..... 20’ x 10’ x 6.6’ Greenhouse (Model #SZ1323G/#SZ1323W) ..... 25’ x 10’ x 6.6’ Greenhouse (Model #SZ1324G/#SZ1324W) ................Maintenance .................. Warranty IMPORTANT We’d love to hear from our customers. If you have any questions about the manual or would like us to help in any way, please feel free to contact the support team.
This user manual applies to Quictent large greenhouses. It will help you to get to know your Quictent large greenhouses. Please read the guidelines in this manual and keep the manual for future reference. We may update the manual without notice in advance. You can always search “Quictent Instructions”...
So far preparing a foundation for greenhouses is the most practical way to extend the green- house lifespan. Consequently, we at Quictent highly recommend you do this right from the beginning. In this chapter, we will introduce the details to prepare a soil foundation.
Page 5
Before you move on with the installation, we have some tips which ONLY apply to the installation with a prepared soil foundation. Tip 1: allowed. Tip 2: After laying the frame poles into the foundation, please make sure the soil around is Tip 3: You can bury the extended edge at both sides of the cover into the soil.
20’ x 10’ x 6.6’ Greenhouse (Model #SZ1323G /#SZ1323W) Parts List You’ll receive two (2) boxes for this model. Please pay particular attention to making sure all parts are numbered and graphically indexed as shown on the Parts List, and so does the quantity for each part.
Page 7
Quantity Part Diagram Description (PCS) 44.5” Top Curved Pole 59.6” Horizontal Pole With 2 Female Ends 59.6” Horizontal #2-1 Pole With Hole 59.6” Horizontal Pole With 1 Male End 59.6” Horizontal Pole #3-1 With 1 Male End and Hole 59.1” Floor Pole With 1 Male End 59.1”...
Page 8
Quantity Part Diagram Description (PCS) 44.5” Auxiliary Supporting Pole With 1 Female Ends and 1 Male End 16.7” Vertical Pole With 1 Hinge 59.1” Vertical Pole With 1 Hinge and 1 Male End 59.1” Horizontal Pole With 2 Holes and 1 Male End 16.7”...
Assembly Steps Before the assembly, please check to make sure that you have all parts listed on the Parts List. The steps below are for a regular assembly, that is, without a prepared foundation. For more details about the foundation preparation, please refer to the previous chapter Soil Foundation Preparation carefully.
Page 11
Step 3 Form the tunnel. The poles you’ll use are: 20 x Part #1 2 x Part #2 6 x Part #3 Reminders: tunnel connecting the poles (2 x #2, 2 x #3) at both sides, then add the 8 x poles (#1), see Fig. a;...
Page 12
Step 4 Reinforce the tunnel with poles (3 x #2-1 and 9 x #3-1). Step 5 Reinforce the tunnel with poles (4 x #9 and 4 x #10). Step 6 Form the door casing with metal clamps (#N) and poles (1 x #11, #12, #13 and #14). (Same with the other door) in the vertical direction.
Page 13
Link poles (#11 & #12) and (#13 )Please note that the pole (#14) and the Note 1 pole (#11) are on the top. The Pole (#12) and the pole (#13) are on the bottom. Please make that the door frame is exactly in the same order shown in thee figure. Both the door frames of 2 sides are the same.
Page 14
Note 1 Refer to the picture; connect poles (#17 & #18) and poles (#15 & #16). Note 2 Align the hinges on the door frame with the hinges on poles (#11 & #12). Install after making sure the hinges of the two sides are aligned. 14 14 17 14 14 Hinges...
Step 8 Step 8 Put on and secure the Cover (#A). And Put on the Door Cover(#B). a)Equip the joint of frames with the 79 x Screw Caps (#D) and the 22 x Pole Plugs (#E). b)Unzip the cover, raise it over the frame top (either from the left side or the right side), careful- the door cover on the frame from top to the bottom c)Secure the structure to the ground by using the 20 x Ground Stakes (#H) and the 4 x Tie Ropes (#I).
Page 16
Link the door cover(#B) to the main cover(#A) via Velcro. The edge of the cover needs to be wrapped on the steel pipe, and then locked with buckles(#K).
Page 17
Additional instructions Put the handles outside the plastic cover and put the bolts through the cover. Make sure the Velcro sticks tightly to keep airtight.
Page 18
e)Attach the cover buckles(#K) to the frame to make the cover more secured. Assem- ble the door handles(#J) to the door frames with M6x35mm screws. After that you can use the door chains(#L) or other locks to keep the doors closed.
4 corners at the bottom, and the other (M6x55mm) ones apply to all the other joints. You can tell the model #SZ1324G from the model #SZ1324W by the Cover (#9). Model #1324G has a green cover while the cover for Model #1324W is white.
Page 20
Quantity Part Diagram Description (PCS) 44.5” Top Curved Pole 59.6” Horizontal Pole With 2 Female Ends 59.6” Horizontal Pole #2-1 With Hole 59.6” Horizontal Pole With 1 Male End 59.6” Horizontal Pole #3-1 With 1 Male End and Hole 59.1” Floor Pole With 1 Male End 59.1”...
Page 21
1 Male End 16.7” Vertical Pole 59.1” Vertical Pole With 2 Hinges 44.5” Bottom Curved Pole 59.1” Horizontal Pole With 2 Holes and 1 Male End 46.1” Top Curved Pole Cover (A Green Cover for #SZ1324G; A White Cover for #SZ1324W...
Page 23
Assembly Steps Before the assembly, please check to make sure that you have all parts listed on the Parts List. The steps below are for a regular assembly, that is, without a prepared foundation. For more details about the foundation preparation, please refer to the previous chapter Soil Foundation Preparation carefully.
Page 24
Step 3 Form the tunnel. The poles you’ll use are: 24 x Part #1 2 x Part #2 8 x Part #3 Reminders: tunnel connecting the poles (2 x #2, 2 x #3) at both sides, then add the 8 x poles (#1), see Fig. a;...
Page 25
Step 4 Reinforce the tunnel with poles (3 x #2-1 and 12 x #3-1). Step 5 Reinforce the tunnel with poles (5 x #9 and 5 x #10). Step 6 Form the door casing with metal clamps (#N) and poles (1 x #11, #12, #13 and #14). (Same with the other door) in the vertical direction.
Page 26
Link poles (#11 & #12) and (#13 )Please note that the pole (#14) and the Note 1 pole (#11) are on the top. The Pole (#12) and the pole (#13) are on the bottom. Please make that the door frame is exactly in the same order shown in thee figure. Both the door frames of 2 sides are the same.
Page 27
Note 1 Refer to the picture; connect poles (#17 & #18) and poles (#15 & #16). Note 2 Align the hinges on the door frame with the hinges on poles (#11 & #12). Install after making sure the hinges of the two sides are aligned. Hinges Door Handle Holes...
Page 28
Step 8 Step 8 Put on and secure the Cover (#A). And Put on the Door Cover(#B) a)Equip the joint of frames with the 91 x Screw Caps (#D) and the 24 x Pole Plugs (#E). b)Unzip the cover, raise it over the frame top (either from the left side or the right side), carefully on the frame.
Page 29
Link the door cover(#B) to the main cover(#A) via Velcro. The edge of the cover needs to be wrapped on the steel pipe, and then locked with buckles(#K).
Page 30
Additional instructions Put the handles outside the plastic cover and put the bolts through the cover. Make sure the Velcro sticks tightly to keep airtight.
Page 31
e)Attach the cover buckles(#K) to the frame to make the cover more secured. Assem- ble the door handles(#J) to the door frames with M6x55mm screws. After that you can use the door chains(#L) or other locks to keep the doors closed.
Maintenance To help you maintain your greenhouse cover in optimal condition and for longer service life, please refer to our suggestions below: Please clean up snow or accumulated water in time, or the greenhouse may break due to overloading. extended part of the cover with extra weights (soil, bricks, stones, sandbags, etc.) When high winds blow, please open all the doors and windows to let the winds pass through.
Required parts (name, quantity, and part number) Pictures (or video clips, if applicable) Warning Restructuring the product without written permission from Quictent in advance would VOID the warranty. Damages due to improper use in severe weather conditions, including but not limited to...
