- Page 1 HEATMISER PLUS INSTRUCTION & SETUP MANAUL Features in this manual are only available on the Heatmiser Plus with the software version 5.4 Revision 2 18/08/2002 Revision 2 18th August 2002 Page 1...
-
Page 2: Table Of Contents
Heatmiser Plus User Manual SUBJECT PAGE NUMBER Contents Page 2 & 3 KeyPad Layout Standard Terms Specification Installation Notes Control Specification Normal RUN Mode Scroll Screens Increase/Decrease temperature temporarily View Technical Screen (Log) Service Mode Override Function Holiday Function Program Mode... - Page 3 Heatmiser Plus User Manual SUBJECT PAGE NUMBER Configuring the Heatmiser Plus Configuring the system Resetting the System back to the factory defaults Engineers setup - Setting up the individual zones Calibrating the sensors Setting the maximum override time UP Arrow key “Offset Limit”...
-
Page 4: Keypad Layout
Prog/ Override Copy Back Lit LCD - The Heatmiser Plus has a 40*2 character back lit LCD. The back light is activated when any key is pressed and remains active for 5 minutes after the last key press. HOLS Button - The Heatmiser Plus features a HOLS button which allows the user to put the control in to a holiday condition. -
Page 5: Standard Terms
Pump Overrun To help dissipate the heat from the boiler, a pump overrun time can be set in the Heatmiser Plus. When enabled, the pump will run on for a number of minutes (programmable) after the zone has switched off. -
Page 6: Specification
F i t t i n g t h e H e a t m i s e r The Heatmiser is fitted to the wall using the four mounting holes, one in each corner of the enclosure. Sensor Inputs 12v Output... -
Page 7: Normal Run Mode
User Manual Normal RUN Mode The Heatmiser Plus has two different types of RUN mode screens. The first is the Time/Date screen and the other is the Zone information screen. The Zone information screen layout will change depending on how the zone is setup. -
Page 8: Service Mode
To cancel an override. Repeat the steps outlined above, reducing the number of hours to 00. Holiday Function (On the keypad) The Heatmiser Plus has a holiday button on the keypad which can be used to shut the entire system off. - Page 9 This setting is normally used to give frost protection. Note ! - At any time when programming the Heatmiser, you are able to use the ENTER key to accept the programmed setting and continue or the RUN Key to accept the programmed setting and return to the DATA menu.
- Page 10 DATA - Programming the DAY temperatures and Switching times. (Continued) The Heatmiser Plus has 4 switching periods available per day per zone. It is important to use 24 hour clock notation when programming the Heatmiser Plus. You do not need to program all of the 4 switching periods simply leave the unused periods at 00.00.
- Page 11 • Press RUN to return to the Normal RUN mode. Programming the Holiday periods. The Heatmiser has 5 holiday periods available which can be used to program the holiday periods for the year. • To program a holiday period press PROG and enter the USER code.
-
Page 12: Configuring The System
Heatmiser Plus User Manual Configuring the system The Heatmiser Plus is our multipurpose control and has a wide number of configurations available. This section aims to guide you through the configuration process. To configure the Heatmiser Plus follow the steps below;... - Page 13 Note: If compensation or boiler sequencing is required on the system these must be setup before any optimised zones. The Heatmiser Plus has 9 relays which can be used for various applications depending on the configuration selected. To calculate the number of relays required for your system observe the following table.
- Page 14 Configuring the system (Continued) Sensor Averaging… The Heatmiser Plus has the facility to average two temperature readings. For example you may have a large heating zone which would be controlled better if two temperature sensors were Installed in the zone and the average reading taken. To set this up follow the steps below;...
-
Page 15: Engineer Setup
Heatmiser Plus User Manual Engineer Setup What you need prior to starting the setup procedure • The configuration and Engineers code (These will be found stuck to the reverse side of the keypad) • The type of zone and total number of zones on the system. - Page 16 User Manual Engineer Setup Setup > Calibration The Heatmiser Plus has eight sensor inputs and these should be calibrated after installation of the system. To calibrate the Heatmiser sensors you firstly need a temperature reading from a digital thermometer, for each zone or pipe being monitored.
- Page 17 00 = Optimiser mode only Automatically adjusts the start up time so that the building is warm for the start of the programmed switching period. The Heatmiser will adjust the rate of change and preheat as the Heatmiser learns the system.
- Page 18 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup (BOILER SEQUENCER FIXED)…. Continued 04 = VENT. Not used on this type of system. Fixed flow... • We must now program the fixed Enter the FIXED FLOW temperature for flow temperature for the boiler the boiler sequencer.
- Page 19 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup (BOILER SEQUENCER FIXED)…. Continued Boiler On Delay... • This is the time delay between ENTER THE BOILER ON TIME DELAY REQUIRED boilers switching ON when the FOR THE BOILER SEQUENCER: flow is under temperature.
- Page 20 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup (BOILER SEQUENCER VARIABLE) Continued Maximum preheat… (This screen will not be displayed on timer zones) • We must now program the Enter the MAXIMUM PREHEAT HOURS you want maximum preheat allowed for this for the optimiser (eg.
- Page 21 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup (BOILER SEQUENCER VARIABLE) Continued Maximum flow temperature … • We are now able to set the Enter the MAXIMUM FLOW temperature maximum flow temperature. for this zone: 00 Compensating direct on the boiler = You should contact the boiler manufacturer for this setting.
- Page 22 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup COMPENSATOR You are able to select whether you want DO YOU WANT THIS ZONE TO PUT ZONE 1 IN TO this zone to put zone 1 in to a DAY A DAY CONDITION.
- Page 23 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup COMPENSATOR Continued Compensation slope… • We are now prompted to enter Enter the COMPENSATION SLOPE FACTOR the slope factor. The slope factor (06 = Normal) determines how the flow temperature changes in relation to the external temperature.
- Page 24 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup COMPENSATOR Continued Hysterysis Value … • We are now able to set the Enter the HYSTERYSIS VALUE for the hysterysis value. compensation: 04 This is number of degrees between the load switching in and out for the compensator. For example, with a setting of 04 and a required flow temperature of 50’C, the load will be switched...
- Page 25 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup OPTIMISER • You are able to select whether you DO YOU WANT THIS ZONE TO PUT ZONE 1 IN this want this zone to put zone 1 in to TO A DAY CONDITION.
- Page 26 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup OPTIMISER continued... Pump Overrun… • A pump overrun time can now be Enter the PUMP OVERRUN TIME required programmed in to the system. : 00 The recommended time for the pump overrun is 20 minutes.
- Page 27 Heatmiser Plus User Manual Engineer Setup Setup > Individual zone setup HILO continued… Rate of change… (This screen will not be displayed on timer zones) • We must now program the rate Enter the RATE OF CHANGE setting for the of change for this zone.
-
Page 28: Changing The User Code
Heatmiser Plus User Manual 3. CHANGING THE USER CODE Should the USER code be forgotten you are able to reset it by accessing the engineers section. Press PROG, enter the engineers passcode and select 3 for CODE. THE OLD USER SECURITY CODE WAS : 0000 PLEASE ENTER A NEW CODE(4 DIGITS): At this point you are able to enter a four digit code. - Page 29 Heatmiser Plus User Manual 7. OVERRIDE/ALARM INPUTS On the Heatmiser Plus there are two uses of the inputs. You are able to use them as alarm inputs or override switches. • To configure the inputs first press PROG and enter the engineers code.
-
Page 30: Wiring Instructions
Heatmiser Plus User Manual WIRING INSTRUCTIONS RELAY BANK for Boiler Sequencer (Fixed or Variable) With Pump Overrun. Relay 1 = Pump Relay 2 = Boiler 1 Relay 3 = Boiler 2 Relay 4 = Boiler 3 Continue if more boilers are required ... - Page 31 Important Note PLUS Beldon 8451 cable MUST be used when No Inputs are required for this System Title system. wiring Heatmiser Sensors. 3 Boiler Sequencer with 2 compensated RS PART NUMBER: 360-649 zones. Bridging + and 1-8 enables the above function.
- Page 32 PLUS Important Note Beldon 8451 cable MUST be used when No Inputs are required for this System Title system. wiring Heatmiser Sensors. 2 Boiler Sequencer with pump overrun 1 compensated zone RS PART NUMBER: 360-649 and 1 Timed zone for Hot water.
- Page 33 2 Boiler sequencer with internal Beldon 8451 cable MUST be used when control via 2 internal averaging sensors, with pump overrun. Holiday wiring Heatmiser Sensors. Hot water control timed only Switch with secondary pump run on and hot water temperature...
- Page 34 HEATMISER Important Note PLUS Beldon 8451 cable MUST be used when No Inputs are required for this System Title wiring Heatmiser Sensors. system. 2 Boiler Sequencer with pump overrun. 1 compensated zone, 1 Constant temp heating RS PART NUMBER: 360-649 zone, 1 Hot water zone and 1 secondary pump.
- Page 35 HEATMISER PLUS Important Note INPUTS Beldon 8451 cable MUST be used when 7 Zones of Radiant wiring Heatmiser Sensors. Tubes RS PART NUMBER: 360-649 HEATMISER UK Drawing No - 005 NC C C NO Sensor Inputs Relay Contacts Volt Free...
- Page 36 HEATMISER PLUS Important Note INPUTS Beldon 8451 cable MUST be used when 7 Zones of wiring Heatmiser Sensors. wam air heaters RS PART NUMBER: 360-649 HEATMISER UK Drawing No - 006 NC C C NO Sensor Inputs Relay Contacts Volt Free...
- Page 37 HEATMISER PLUS Important Note INPUTS Beldon 8451 cable MUST be used when 6 Zones of wiring Heatmiser Sensors. wam air heaters and 1 Summer RS PART NUMBER: 360-649 fan zone HEATMISER UK Drawing No - 007 NC C C NO...
- Page 38 Temperatures. The Immersion sensor is supplied with a 8.4cm brass pocket for inserting into the pipe-work. Heatmiser Internal Sensors Heatmiser Internal sensors should be fit about 5ft up and out of direct sunlight or other heat sources. Heatmiser External Sensors Heatmiser External sensors should be fit on North Facing walls out of direct sunlight.
