- Page 1 Para ver las instrucciones de uso en español visita www.homscales.com Pour les instructions de l'utilisateur dans la visite française www.homscales.com PELSTAR, LLC 9500 West 55th St. McCook, IL 60525-7110 USA www.homscales.com ® Health o meter Professional 1522KL © Pelstar, LLC 2022 UM1522KL REV20221209...
-
Page 2: Specifications
Introduction The 1522KL Mechanical Baby Scale provides precise weighing of babies and toddlers. It is durable, having a sturdy enameled steel body and a wipe down, thermoformed plastic weighing tray with measuring ruler. These installation and operating instructions will guide the user through basic instructions on pillar assembly, plastic weighing tray installation and the zero adjustment of the scale. -
Page 3: Installation Instructions
Installation Instructions The following components are required assembly: ▪ Pillar assembly ▪ Steelyard rod connection ▪ Molded plastic weighing tray assembly Remove all components from the shipping box and lay out in a convenient place. ▪ Pillar Installation Prior to assembly, you will need the following tools to finish assembling the EL-BS Mechanical Baby Scale. - Page 4 3. Insert the pillar into the scale base assembly ensuring that the MEASURETEK logo located on the weigh beam faces the scale base. 4. Using a Philips head screwdriver, screw in the eight bolts and washers to secure the pillar to scale base. UM1522KL REV20221209...
-
Page 5: Steelyard Rod Connection
▪ Steelyard Rod Connection The steelyard rod is located inside the scale pillar. Once the pillar is attached to the scale base, the steelyard rod must be attached to the bottom of the scale. 1. Lay the scale pillar on a table so that the scale platform hangs over the edge of the table and allows you to access the bottom of the scale. -
Page 6: Weigh Platter Installation
3. Place the scale upright gently back on the table ▪ Weigh Platter Installation The weighing platter comes separate from the scale base and must be attached for proper operation. To attach the weigh platter to the scale base, use the following instructions. -
Page 7: Zero Adjustment
Zero Adjustment To ensure accurate weighments, a zero adjustment should be done to the scale upon arrival and setup. To perform a zero adjustment, perform the following steps. 1. Ensure the scale is sitting upright on a level surface. 2. Make sure that the poise weights are pushed all the way to the left hand side (at zero) making sure that the large poise is firmly seated in the notch and the small poise is firmly against the shoulder of the beam. -
Page 8: Troubleshooting
Weighing a Baby To weigh a baby, place the baby on the weigh platter and slide the larger poise (on bottom) to the approximate target weight. Next move the smaller poise on top until the weighing beam balances and the scale pointer is centered within the eye loop area as shown in Figure 4-1. - Page 9 PLEASE REGISTER YOUR SCALE FOR WARRANTY COVERAGE AT: www.homscales.com ® ® Health o meter is a registered trademark of Sunbeam Products, Inc. used under license. Health o meter ® Professional products are manufactured, designed, and owned by Pelstar , LLC. We reserve the right to ®...
