- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com HT-FLARE-2, HT-FLARE-4, HT-FLARE-8 HDMI Splitter Family USER MANUAL February 18, 2025 Hall Technologies February 18, 2025 Page 1 of 11...
-
Page 2: Important Safety Instructions
8. Protect the power cord from being walked on or pinched particularly at plugs. 9. Only use attachments / accessories specified by the manufacturer. Refer all servicing to qualified service personnel. Hall Technologies February 18, 2025 Page 2 of 11... -
Page 3: Table Of Contents
HT-FLARE-2 Connection Diagram ....................8 HT-FLARE-4 Connection Diagram ....................8 HT-FLARE-8 Connection Diagram ....................9 Operating Instructions ..........................9 EDID ..............................9 HDCP ............................... 9 HDR ..............................9 Specifications ............................10 Hall Technologies February 18, 2025 Page 3 of 11... -
Page 4: Introduction
Introduction OVERVIEW The HT-FLARE series is a family of HDMI splitters that distribute a single HDMI source to two, four, or eight simultaneous outputs. The products support 18Gbps bandwidth, full HDMI 2.0 and HDCP 2.2 with video resolutions up to 4k@60Hz 4:4:4. The products also support simultaneous routing to 4k and 1080p displays via downscaling. -
Page 5: Connectors & Indicators
2 outputs in order to support all displays. POWER LED power indicator LED indicator of connected outputs HDMI OUT HDMI output ports HDMI IN HDMI input port POWER/FIRMWARE Power/Firmware Port Hall Technologies February 18, 2025 Page 5 of 11... -
Page 6: Ht-Flare-4 Front And Rear Panel
When Output 1 is disconnected, Output 2 will output 4K@60Hz. Note: Output 4 is Priority Port Firmware Firmware port DC/5V Power input port HDMI OUT HDMI output ports HDMI IN HDMI input port Hall Technologies February 18, 2025 Page 6 of 11... -
Page 7: Ht-Flare-8 Front And Rear Panel
When Output 1 is disconnected, Output 2 will output 4K@60Hz. Note: Output 8 is Priority Port POWER LED power indicator ON/OFF Press to turn/off device DC/5V Power input port HDMI OUT HDMI output ports HDMI IN HDMI input port Hall Technologies February 18, 2025 Page 7 of 11... -
Page 8: Connection Diagrams
Connection Diagrams HT-FLARE-2 CONNECTION DIAGRAM HT-FLARE-4 CONNECTION DIAGRAM Hall Technologies February 18, 2025 Page 8 of 11... -
Page 9: Ht-Flare-8 Connection Diagram
HDCP 1.4 | 1080p@60Hz HDCP 1.4 | 4K@24Hz HDCP 1.4 | 4K@24Hz HDCP 1.4 | 4K@24Hz Support for HDR (High Dynamic Range) video can be accessed in “Copy EDID” and “Mixed EDID” modes. Hall Technologies February 18, 2025 Page 9 of 11... -
Page 10: Specifications
1 x HDMI Female Outputs 8 x HDMI Female Power Consumption 5W (max) Dimensions (L x W x H) 9.7” x 4.3” x 0.7” (247.2mm x 110mm x 17mm) Net Weight 1.34 lbs. (0.61kg) Hall Technologies February 18, 2025 Page 10 of 11... - Page 11 © Copyright 2024. Hall Technologies All rights reserved. 1234 Lakeshore Drive, Coppell, TX 75019 halltechav.com / support@halltechav.com (714)641-6607 Hall Technologies February 18, 2025 Page 11 of 11...
