ADI AB-01 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AB
01
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AB-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADI AB-01

Summary of Contents for ADI AB-01

  • Page 1 User Manual...

  • Page 2: Table Of Contents

    catalog Overview……………………………………1 Unpacking and device inspection………2 Annex table…………………………………2 Main features of this machine…………3 Technical index……………………………5 Familiar with this machine………………7 Function operation………………………8 PC programming software function setting……………………………………14 Instructions for use and maintenance………………………………20 Troubleshooting guide…………………22 Appendix: Sub-audio table and digital sub-audio…………………………………25...

  • Page 3: Overview

    Whether you are in a rural area, forest area, pastoral area, or sea area, you can talk normally, and the exquisite appearance can better meet your individual needs. Thank you for your continued support and love to ADI Communications Corp.!

  • Page 4: Unpacking And Device Inspection

    Unpacking and device inspection Please take out the walkie-talkie carefully from the packing box. We recommend that you check whether the following items are in the box before discarding the packaging materials. If any items are lost or damaged during transportation, please immediately ask the seller and ask for the corresponding accessories.

  • Page 5: Main Features Of This Machine

    Main features of this machine 467.5125 – 467.675 MHz full-band intercom. 2. Chinese/English voice report number. 3. High/low power is optional. 4. Wide and narrow bands are optional. 5. 50 sets of CTCSS and 104 sets of DCS noise suppression system. 6.
  • Page 6 10. With dual PTT function, emergency communication is more convenient and fast. 11. With deep power saving function, the standby time is longer. 12. Built-in Bluetooth function (optional) 13. The charging data of the external headset shares the TYPE C interface for easy use.

  • Page 7: Technical Index

    Modulation FM(F3E) Range of working temperature －20℃ --- ＋ 55℃ Operating Voltage 3.7V About 20mA （ Normal Waiting current power saving) Size 140(H) ×49(W) × 20(D) Weight About 100g Emission part Frequency tolerance ±3ppm ≤0.5W/3.7V Output Power ≤0.5A Emission current Max frequency deviation 2.5kHz Audio distortion <5%...
  • Page 8 ≥0.5W Audio power Maximum receiving current ≤380mA Audio distortion <5% Adjacent channel selectivity ≥60dB Intermodulation anti-interference ≥60dB...

  • Page 10: Function Operation

    Function Operation Turn on/off Press and hold the power button for 1-2 seconds. During power on, the interphone will beep. If the voice alarm function is activated, the current channel number will be reported at the same time. When the walkie-talkie is turned on, press and hold the power button to hear the dual tone to turn off.
  • Page 11 will be a corresponding beep sound. If you continue to adjust it when the maximum or minimum is reached, there will be a higher-pitched beep sound to remind you that the volume level has been adjusted to the limit . Emission After pressing the side button [PTT] or the red light of the PTT button on the panel is on, the...
  • Page 12 volume key function cannot be adjusted when the volume button is locked. Long press the panel [Volume -] button for more than two seconds to unlock the keyboard lock function. Bluetooth function operation (optional) Bluetooth function is on When the power of the walkie-talkie is turned on, the Bluetooth function is automatically turned on when you hear the dual-tone tone.
  • Page 13 seconds to turn off the Bluetooth function. Scan When the channel knob is turned to the 16th channel, the walkie-talkie automatically starts the scan function, and the speaker prompts "scan". Perform cyclic scanning on channels with additional scanning. The frequency writing software can set carrier scan and time scan, Carrier scanning means that after scanning to the relevant channel, it stays on that channel...
  • Page 14 When the device is turned on, short press the power button. Power voltage above 3.8V—— "beep beep beep" indicate high power Power voltage 3.6V to 3.8V ——"beep beep" indicate medium power Electric voltage below 3.6V—— "beep"on ce indicates low electric potential You can get a rough estimate of the power of the walkie-talkie battery.

  • Page 15: Usb Charging Function

    Low battery detection function 1. When the voltage is lower than 3.35V, it will remind to charge every 30 seconds 2. When the voltage is lower than 3.2V, the machine will automatically shut down USB charging function When the configured CHARGING USB socket is inserted into the charging port to charge, the red light will be on duri ng the charging process, and the green...

  • Page 16: Pc Programming Software Function Setting

    PC programming software function setting PC programming Computer software function setting software operation method Please log in to the website http:// https://www.adicomm.com.tw/ ,Download frequency writing software. The frequency writing software has Chinese and English versions respectively. SQL squelch level setting 1、The quiet voice level in the drop-down menu "Function Settings"...
  • Page 17 level 3. 2 、 The squelch system can eliminate the background noise when there is no signal received, which not only makes the waiting time quieter, but also significantly reduces the standby power consumption. VOX function (no keystrokes to speak) 1、In the key-free speaking level under the drop-down menu "Function Settings"...

  • Page 18: Transmit Timeout Timer

    Power saving function Set the power saving switch in the drop-down menu "Function Settings" of the main menu "Settings" of the programming software, and the default is to turn on the power saving. After the power saving function is turned on, the machine has no action and enters 1/4 power saving mode in 10 seconds.
  • Page 19 will stop and a beep will sound. Release the [PTT] key. Press the [PTT] key again to resume transmission. Voice reporting function In the main menu of the frequency writing software, the "Settings" pull-down menu "Function Settings" under the broadcast voice item can choose Chinese and English two kinds of report sounds.
  • Page 20 definition of busy lock is that when the signal of the same frequency is received, it is forbidden to transmit and interfere with the communication of others. High and low power selection In the channel information of the main menu of the frequency writing software, you can select the channel you are using and select high/low power.
  • Page 21 can select the sub-audio QT/digital sub-audio DQT in the receive sub-tone and transmit sub-tone drop-downs respectively. 2、When a channel is set with sub-audio or digital sub-audio signaling, the squelch can only be turned on when the same sub-audio or digital sub-audio signal is used. Similarly, only the radio station whose QT/DQT signaling mode is consistent with the signaling of your walkie-talkie can receive the signal you...

  • Page 22: Instructions For Use And Maintenance

    Instructions for use and maintenance The walkie-talkie you buy is an electronic product with precision design, so you should use it with care. The following suggestions can make your walkie-talkie last longer. 1 、 Please do not try to disassemble this walkie-talkie, non-professionals The handling of this unit may cause damage.
  • Page 23 The life span of the sub-devices may cause some plastic parts to deform. 5、Please keep the walkie-talkie dry, rain or humidity will corrode Circuit board. 6、If you find a strange smell or smoke from the walkie-talkie, please That is, turn off the walkie-talkie and separate the battery from the walkie-talkie.

  • Page 24: Troubleshooting Guide

    Troubleshooting Problem Solution 1、 The battery pack may be exhausted. Please replace the battery with a new one or recharge it. response 2、 The battery pack may after not be installed Turning on correctly. Please remove the battery pack and install it again.
  • Page 25 away, confirm whether you are within the effective range of other walkie-talkies.  Confirm that the antenna is in good contact and tightened.  Confirm whether the original antenna Short provided by the distance manufacturer is used.  The dealer or user's squelch level is set too high, reduce the squelch level.
  • Page 26 appear in the same time, you must the channel change the signaling of all walkie-talkies in the group.  The life of the battery pack The battery has expired, please power will not last update the battery.  Whether the battery is long after charging fully charged.

  • Page 27: Appendix: Sub-Audio Table And Digital

    ventilated and dry place, and send it to the repair station in the shortest time. Appendix: Sub-audio table and digital sub-audio table 50 groups of sub-audio frequencies 67.0 85.4 107.2 136.5 165.5 186.2 210.7 254.1 69.3 88.5 110.9 141.3 167.9 189.9 218.1 71.9 91.5 114.8 146.2 171.3 192.8 225.7 74.4 94.8 118.8 151.4 173.8 196.6 229.1 77.0 97.4 123.0 156.7 177.3 199.5 233.6...
  • Page 28 104*2 sets of digital sub-audio to choose from 023 054 125 165 245 274 356 445 506 627 732 025 065 131 172 246 306 364 446 516 631 734 026 071 132 174 251 311 365 452 523 632 743 031 072 134 205 252 315 371 454 526 654 754 032 073 143 212 255 325 411 455 532 662 036 074 145 223 261 331 412 462 546 664...
