- Page 1 TL2253 USER MANUAL...
-
Page 2: Table Of Contents
TO THE CUSTOMER: Thank you for purchasing this LCD TV. When opening the box for the first time, please check whether all the accessories are present. Before connecting parts and power, please carefully read the user manual and always keep these instructions handy and close by your LCD TV. -
Page 3: Safety Precaution
1.Safety precaution Notes: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insinuated WARNING dangerous voltage within the product's enclosure that may RISK OF ELECTRIC SHOCK of sufficient magnitude to constitute a risk of electric shock DO NOT OPEN CAUTION: The exclamation point within an equilateral triangles is intended... -
Page 4: Accessories
SAFETY WARNINGS Before using this product, read and follow all warnings and instructions. This product is not intended for use by young children. Young children should be properly supervised. This product is intended for household use only and not for commercial or industrial use. -
Page 5: Remote Control Manual
3.Remote control manual Bright sunlight or lighting may cause erratic remote operation... -
Page 6: Remote Control Functions
4.Remote control functions (TV/AV/SVIDEO/SCART/VGA/HDMI). -
Page 7: Teletext Function Buttons
5.TELETEXT function buttons... -
Page 8: Lcd Tv Panel Overview
6.LCD TV panel overview TV Control Panel TV connections VIDEO 1.DC 12V power input. 2.HDMI input. 3.VGA input. 4.SCART input. 5.AV input. 6.PC audio input. 7.Headphone output. 8.Antenna input (75 Ohm VHF/UHF). 9.S-VIDEO input. -
Page 9: Connecting To External Devices
7.Connecting to external devices RCA terminal is used to connect the output device of DVD (480I/480p/576I/576p) VIDEO/L/R The rear of TV Left/right Camera Video recorder S Video VIDEO Notes: 1.VIDEO-L-R/S-Video use a common Audio in. 2.VIDEO-L-R of DVD is corresponding to VIDEO-L-R of LCD TV. 3.Scart to Scart from a VCR. -
Page 10: The Osd Menu
8.The OSD menu Menu Setup TV (When using for the first time only) Initial Setup Welcome Welcome to use the Wizard for Initial Setup !! 1. Turn on TV, Please press"OK" to Please press [OK] to start the wizard. start the wizard Language Initial Setup... - Page 11 Menu Operation Under TV Input 1 VIDEO MENU Picture Mode User Video Brightness a. The following picture is the sketch map of Audio Contrast the video menu. Saturation Sharpness b. The definition of each option: Setup Medium Color Temperature b-1. Picture Mode: Change the picture mode Parental in the sequence as: Sta nda rd User Cinema Sport Vivid Hi-Bright...
- Page 12 2 AUDIO MENU Balance Video Video Video a. The following picture is the sketch map Bass Audio Treble of the audio menu. Sound Surround Equalizer b. The definition of each option: Setup b-1. Balance: Change the value of Balance Parental with the key / in the range of -50 to +50.
- Page 13 The submenu of Channel Item Channel Scan Video Video Update Scan b-3-1. Channel Scan Auto channel searching. Audio Manual Scan G Gain Channel Skip b-3-2. Update Scan Searching added channel. B Gain Channel Sort Channel Edit Setup b-3-3. Manual Scan: manual channel searching Channel Decode Parental Analog Channel Fine Tune...
- Page 14 b-3-4. The submenu of Channel Skip Digital arte Video Video The channel skip is used for skipping Digital phoenix Audio Digital Das Erste the channel. Digital WDR Dortmund Digital WDR Dusseldorf Setup Digital WDR Essen Analog Parental Analog Analog BBC1 Analog BBC1 Channels Skip...
- Page 15 b- 3- 7. The submenu of Analog Channel Decode Analog Video Video The channel decode is used for decoding Analog Audio Analog BBC1 the channel. Analog BBC1 Analog Setup Analog Analog Parental Analog Analog Analog Select EXIT Exit Channels Decode b-3-8.
- Page 16 4 Setup MENU Video Video OSD Language English a. This menu is used to set the function Screen Mode Auto Audio OSD TIMEOUT Short b. The definition of each option: OSD Transparency Middle Time Setup b-1. OSD Language: Change the OSD Setup Subtitle Digital Teletext Language...
- Page 17 The Submenu of Time Setup Video Video As Broadcaster Time Zone Time b-5-1. Time Zone: Change the time zone Audio by user. b-5-2. Time set the time. and set power Setup on/off time. Parental Time Setup Select EXIT Exit submenu of Subtitle Item.
- Page 18 5 . Parental menu Password Video Video a. This menu is used to set the block Audio function. Password set the child lock password, Setup the initial password is 0000. Parental Parental Select EXIT Exit Enter b. The Submenu after You Enter the Video Channel Block Video...
- Page 19 b-1. The submenu of channel block. arte Video Digital Video phoenix Digital If you select any of the channel, the Audio Digital Das Erste channe l can not receive signal unless WDR Dortmund Digital WDR Dusseldorf Digital you unblock it. Setup Digital WDR Essen...
- Page 20 b-4. The submenu of change password. Video Video New Password need to input the new password Confirm Password Audio and confirm it. Setup Parental Change Password EXIT Exit b-5. The submenu of Clean All. Are you sure? Press OK to clean your set or cancel to return the previous...
- Page 21 Main menu under VGA Input a. When system signal source switch to Auto Adjust Video Video Video Video H.Position VGA, there will be a VGA mark in the up- Audio V.Position Phase left corner of the screen, it is in the VGA Clock menu ,and you can setup the item.
-
Page 22: Specifications
Specifications Panel Features Screen Size 21.6 inch 477.417mm(H) X 268.416mm(V) Active Area Aspect Ratio 16:9 Panel Resolution 1366 X 768 Brightness 4 cd/m² 800:1 Contrast Ratio Viewing Angle 170º(H) X 160º (V) 0.1165mm(H) X 0.3495mm(V) Dot Pitch Maximum Colour 16.7M Response Time Black-White (R&D) 2/3ms OSD Languages...
