MEDICAL DEVICE – COMFORT STROLLERS
MEDICAL DEVICE – Special rehabilitation stroller COMFORT MINI
MEDICAL DEVICE – Special rehabilitation stroller COMFORT MAXI
PRODUCER:
1. Changes not included in the descriptions and illustrations in this instruction manual are reserved.
2. Copying this manual and its content and/or excerpts for purposes other than those for which it was
developed is prohibited.
NOTE: The information contained in the manual does not constitute a commercial offer within the meaning of
the law.
MANUAL
USE
AND SERVICE
Size [1], [3], [4], [5], [6] [6+], [7], [8]
Size [1], [3], [4], [5], [6] [6+], [7], [8]
Wytwórnia Sprzętu Rehabilitacyjnego
COMFORT Sp. z o.o.
60-116 Poznań, Głazowa 43
and
Author: WSR Comfort
Developed: May 2003
Updated: February 2023
Edition XXIII English
Advertisement
Table of Contents
Related Manuals for Comfort MINI
Summary of Contents for Comfort MINI
- Page 1 MANUAL AND SERVICE MEDICAL DEVICE – COMFORT STROLLERS MEDICAL DEVICE – Special rehabilitation stroller COMFORT MINI Size [1], [3], [4], [5], [6] [6+], [7], [8] MEDICAL DEVICE – Special rehabilitation stroller COMFORT MAXI Size [1], [3], [4], [5], [6] [6+], [7], [8] PRODUCER: Wytwórnia Sprzętu Rehabilitacyjnego...
-
Page 2: Table Of Contents
B. Parts ..........................17 Principles of proper operation ..................18 to 20 Residual risk ........................... 20 III. Service ..........................21 IV. WSR COMFORT service points ..................22 V. Period of use .......................... 22 VI. Folding, transport and unpacking ..................22 VII. -
Page 3: Purpose And Environment Of Use And Storage
PURPOSE AND ENVIRONMENT OF USE AND STORAGE COMFORT strollers are designed by the manufacturer to alleviate the course of the disease are used to transport patients with cerebral palsy, extensive paralysis, paresis of the limbs and trunk preventing independent movement. - Page 4 STROLLERS COMFORT MINI Size [1] for children weighing up to approx. 20 kg and height up to approx. 110 cm Size [2] for children weighing up to approx. 30 kg and height up to approx. 120 cm Size [3] for children weighing up to 50 kg and height up to approx. 140 cm (optimally approx.
- Page 5 As part of the option for a special rehabilitation stroller COMFORT, you can choose as follows: Abduction wedge (strut) Suspenders Headrest Thigh belts Footrest straps Ankle straps Calf belts Side lumbar supports Seat cushion Side cushions Central lumbar cushion Upholstered footrest protector...
-
Page 6: General Drawing Of The Stroller
General drawing of the stroller 1. - Stroller handle 2. - Stroller leg 3. - Stroller barrier 4. - Rear backrest of the stroller 5. - Rear backrest tilt adjustment lever 6. - Armrests of the stroller 7. - Stroller footrest 8. -
Page 7: Detailed User Manual
I. DETAILED INSTRUCTION MANUAL UNFOLDING THE STROLLER: 1. Stand in front of the stroller by the footrest. 2. Cut the plastic strap that secures the stroller during transport. 3. Unveil the barrier cover on both sides, press the metal balls at the same time, attracting the barrier to yourself –... -
Page 8: Rear Backrest Tilt Angle Adjustment
REAR BACKREST TILT ANGLE ADJUSTMENT In order to adjust the angle of inclination of the backrest: • hold the backrest of the stroller with the left hand (4), • with the right hand release the clamp lever (5) located on the right side of the stroller, lowering it down –... -
Page 9: Folding Footrest Step
FOLDING THE FOOTREST STEP The footrest step should always be folded when the user wants to get into or out of the stroller. To do this, the footrest step must be pulled upwards, which will rotate it 90° and set it in an upright position. In order to lower the step, push it down with your hand until it stops in a horizontal position –... -
Page 10: Removing And Putting On Upholstery
INSTRUCTIONS FOR REMOVING TWO-PIECE UPHOLSTERY (if the stroller has it) 1. After unfolding the stroller, unfasten the zippers located on both sides of the backrest top. 2. Unfasten the Velcro belt located at the bottom of the backrest. 3. Remove buckles and protectors from the shoulder straps on the front of the backrest – drag the braces through the holes in the upholstery. -
Page 11: Upholstery Cleaning
UPHOLSTERY CLEANING UPHOLSTERY MADE OF FABRICS TYPE "Microphase" For cleaning upholstery made of suede-like fabrics, use a soft clothing brush with natural bristles or a vacuum cleaner with a delicate nozzle. Dirt can be removed with warm water and mild soap. Moisten the dirty place with soap previously applied to a towel or sponge and remove stains with little pressure in a circular motion. -
Page 12: Tire Inflation
TIRE INFLATION In order to inflate the tires, use the pump supplied with the stroller or other available pump (manual or foot) to the valves in which the wheels of the stroller are equipped. Absolutely do not exceed 200 Kpa (0.2 MPa) – recommended pressure 180 Kpa (0.18 MPa). Remark: Inattentive (too strong) inflating of tires can be very dangerous. - Page 13 If the stroller has a handbrake, the tension of the cables should be adjusted for proper operation. The adjustment consists in unscrewing the knurled nuts located at the brakes and on the joint connecting the cables by a few revolutions. After adjustment, the knurled nuts should be corrected with M6 nuts.
-
Page 14: Tools, Instruments And Materials For Easy Adjustment And Maintenance
Remark: When disassembling a worn brake cap, use pliers or pliers – see Figure 8 Fig. 8 4. replenish or replace lost or damaged springs, 5. complete or replace lost or damaged plastic caps securing the ends of the stroller frame tubes, 6. -
Page 15: Instructions For Use
II. INSTRUCTIONS FOR USE Below are the basic rules for the correct and safe use of the stroller. SAFETY RULES A. In any case – in order to ensure max. The following rules must be strictly observed: 1. Do not leave the stroller with (or without the patient) with the fire open fire and do not bring the sources of fire close to the cart. -
Page 16: Assessment Of The Proper Functioning Of The Basic Mechanisms And Assemblies In The Stroller And Ways To Assess The Wear Of Parts That Need To Be Replaced
ASSESSMENT PROPER FUNCTIONING BASIC MECHANISMS AND ASSEMBLIES IN THE STROLLER AND WAYS OF ASSESSING THE WEAR OF PARTS TO BE REPLACED A. MECHANISMS AND ASSEMBLIES 1. Foot brake (parking) mechanism The brake mechanism works properly if, after pressing the brake rod with the foot, the rear brake pads (14) rest freely on the tire, and the front brake pads (13) brake the wheels as a result of a gentle suffocation into the tire. -
Page 17: Parts
4. Valves Care for valves is one of the elements determining the safety of the user, his comfort and durability of the wheel. Therefore, each time you check the pressure in the tires and after replacing the tire or inner tube, pay attention to: ▪... - Page 18 Compliance with the following rules for the proper use of the stroller will extend its life and at the same time provide the necessary comfort to the user. 1. COMFORT stroller should be used only in accordance with their intended purpose. 2. Always maintain the correct tire pressure.
- Page 19 9. Driving with the user and overcoming obstacles. ◦ During walks, the stroller should always be held by the handle, and letting the stroller loose so that it rolls freely is not allowed, because it deprives the user of help from the caregiver and may be the cause of severe body injury as a result of hitting e.g.
-
Page 20: Principles Of Proper Operation
◦ When transporting a stroller composed of dismantled wheels in models equipped with screw-on hubcaps, it is ordered that after removing the wheels, the caps should be turned on the ends of the axles. This perfectly protects against accidental injuries, accidental damage to the means of transport and additionally protects the ends of the axles from the destruction of threads, and the caps from loss. -
Page 21: Service
REGULATION AND MAINTENANCE, it is still inoperable. 8. The COMFORT company has all the parts necessary for the repair of COMFORT type strollers and sends them at the customer's request to the address indicated. -
Page 22: Wsr Comfort Service Points
IV. COMFORT SERVICE POINTS Wytwórnia Sprzętu Rehabilitacyjnego COMFORT sp. z o.o. Głazowa 43, 60-116 Poznan phone/fax +48 61 863 85 61 V. PERDIOD OF USE There is no defined period of use. VI. STORAGE, TRANSPORT AND UNPACKING If it is necessary to send the stroller for repairs, the stroller in the folded state should be packed in a... -
Page 23: What To Do In The Event Of A Serious Incident Involving A Stroller
VII. WHAT TO DO IN THE EVENT OF A SERIOUS INCIDENT RELATED TO A DEVICE (STROLLER) In the event of a serious incident* related to the COMFORT stroller, the information should be reported to the Manufacturer and to the Office for Registration of Medicinal Products, Medical Devices and Biocidal Products.
