VARDE OVNE Varde Cast Iron S1 Installation And User Manual

Installing the stove:
According to existing regulations, stoves must be placed with the following minimum dis-
tances (in centimetres) to inflammable walls and materials:
Sides: 30 cm Rear: 15 cm Distance to furniture in front of stove:
If walls are non-inflammable, the stove can be placed closer to them. However, we recom-
mend a minimum distance of 5-10 cm. to allow for cleaning behind the stove.
The cleanout gate must be accessible.
Optimal combustion can only be obtained if fresh air is constantly admitted. It is important,
therefore, to ensure that this is the case.
The best way to provide a steady flow of fresh air is by installing 1-2 air vent(s) in the room
where the stove is situated. (one in each side of the room).
Flooring:
If the stove Varde S1 is to be placed on a floor witch is inflammable, the floor must be cov-
ered with non-inflammable material, such as a steel or glass plate, floor tiles or artificial slate,
covering an area of at least 15 cm. from the sides of the stove and at least 30 cm. from the
front of it. With regard to the front, however, we recommend 50 cm.
If the stove Varde S3 (low feet) is to be placed on a non-inflammable bench witch min. is 27
cm. high, an inflammable floor around the bench has to be covered the same way as for
Varde S1.
If the stove Varde S3 (low feet) is to be placed directly on the floor, the floor has to be made
of non-inflammable materials under the stove, as well as 15 cm. on the sides and 50 cm. in
front of the stove.
Also, the bearing construction must be capable of carrying the combined weight of stove and
chimney. Read the table on page 4, to find out how much your stove weights.
The chimney:
Always use a chimney with a diameter of at least 15 cm. This corresponds to a clear of 175
square centimetres. Make sure the chimney is of a sufficient height, that it draws well and
that smoke does not bother your neighbours.
We recommend that you fit your chimney with a damper, allowing for draft control. This may
prove particularly important on windy days.
Note: the damper must never shut off draught completely – always allow at least 20 square
centimetres free passage through the chimney.
With nominal usage the stove has tested a Smoke flow of 6,0 g/second and with a smoke
temperature of 241 °C in a room of 20 °C.
Varde stoves are always fitted with a smoke plate which redirects smoke to make its way to
the chimney as effectively as possible. This ensures that the heat from the smoke is emitted
inside your home rather than outside it. The smoke plate is moveable and placed on top of
the Vermiculite fire brick side plate. You should make sure that it is pushed all the way back
against the back wall of the combustion chamber.
Lighting for the first time:
The first time that the stove is lit, lighting should be terminated after the initial fire has
caught. This is so that the cement that is used as sealant is able to harden, after that the
stove can be used according to the following instructions.
How to light and stoke a fire:
The first time you light up the stove the enamel will temper, and give off some smoke and a
slight smell. We recommend that you leave doors and windows open, as airing the room will
make the smell disappear. This tempering softens the enamel making it susceptible to dam-
age. Therefore exercise caution and avoid touching the enamel. Likewise we recommend
opening the door to the stove at regular intervals for the first hours to prevent the insulation
rope from sticking to the enamel.
Never use highly inflammable fluids such as spirit and petrol for lighting up! Instead, use a
crumpled up piece of newspaper or kindling blocks topped by 10-15 small sticks (c. 2 kg.).
A thin layer of ashes at the bottom of the stove makes lighting up a fire a lot easier.
Before lighting up the stove, you have to open completely for the combustion air
(Secondary air) by pushing the grip under the door to the right side, (alternatively, shortly
leave the door a little open if there is no wind and no draught in the chimney), thus allowing
the fire to catch on. Always remember to close the door again after some minutes, otherwise
the stove and the chimney can be overheated, and this is not covered by the warranty.
By lighting up we recommend to let the secondary air fully open all the time, this to warm up
the stove and chimney to appropriate working temperature.
Once the wood has burnt to embers, you may refill the stove with the next lot of wood, once
again having the damper fully open until the wood is burning well, then adjust it to the below
described positions.
The following optimal register and fuel quantity settings are recommended (in case of similar chimney draught):
Fuel Combustion Nominal
Quantity Air open Output
[kg] [%] [kW]
2
1,4 50 5,0
(half open)
Regulations
All local regulations as well as
National and European, should be
100 cm
adhered to when installing your stove.
All Varde Ovne stoves are closed
fireplaces.
Draught conditions
Consult your local stove dealer or
chimney sweeper about how best to
adjust the draught in your chimney.
Chimney Fires
Should your chimney catch fire, cut
off the air supply to the stove's com-
bustion chamber and contact the
emergency services.
(The majority of fires die out after the
oxygen supply is cut off).
Following this, the least you should
do is to contact your chimney
sweeper, who will check your stove
and chimney for damage.
Continual fresh air
A continual supply of fresh air is
required in the room in wich the stove
is situated.
This can be achieved by installing
1-2 vents, whilst also ensuring that
these can not be blocked.
The shaking grate
The shaking grate is situated at the
bottom of the combustion chamber.
The ashes will be shaken into the ash
-pan by the pulling and pushing of the
lever.
Overheating
Occurs if too much wood is placed
in the stove or if the combustion
receives too much air.
Combustion / Secondary air
Pre-heated air for the combustion
process, the amount of which can be
altered according to the desired room
temperature, and the effectiveness of
the chimney. A high level of chimney
draught requires a lesser intake of
combustion air.
This combustion air is coming into the
combustion chamber as an airflow
down behind the glass in the door.
A part of the combustion air is also
coming through the oblong holes in
back corners in the combustion cham-
ber.
Chimney Efficiency Refill interval at nominal
Draught output
[≥i %]
[PA] [minutes]
12 81 approx. 50
VARDE OVNE A/S In most instances, however, you will have to arrive at the best combustion air settings
yourself, as the height and diameter of your chimney, as well as the quality of the firewood
Is a Danish company specialis-
ing in functional, environmentally are decisive factors in determining how your particular stove is best set (see also the section
on troubleshooting on next side).
friendly and designed quality
stoves.
The lowest output of 3-4 kW is usually obtained, when 2-4 small logs with a total weight of
As well as having passed the
1 - 1,2 kg. and the secondary air damper is set to 30-40% open.
Danish (DS/EN 13240),
In this operation mode it is important that the secondary air damper is fully open for the first
Swedish (SP) and
3 - 5 minutes, to make sure that the fire has caught fully before the supply of secondary air is
Norwegian (Sintef) Kite marks,
reduced.
the stove are also awarded the
Please be aware of, that there always must be flames, when there is wood in the combustion
coveted Svanemaerke for envi- chamber. If there's not, you have reduced to much for the secondary air.
ronmentally-friendly products.
(CO value on 0,06 % and a If you are wondering why your stove is fitted with an air beam with small holes in it, running
smoke temperature of less than through the rear of the combustion chamber, this is merely a consequence of our newly
developed combustion system. We refer to these air ducts as the 'tertiary air', and will prove
250 °C).
helpful as you install your new Varde stove.
Tertiary air
When refilling the stove with wood, we recommend opening the stove door only once em-
is constantly added air, which
bers are left in the combustion chamber. Opening the door whilst the flames are still burning
makes the stove burn even
and producing smoke and gas, might cause smoke to slip into the room instead of up the
cleaner, and lowers the content
chimney.
of tar and soot in the combustion
process to an absolute minimum.
What to burn
At optimal combustion settings,
This Varde stove is tested and approved for the burning of wood. Only dry wood with a
glass and combustion chamber
moisture content of maximum 21 percent and the size to fit into the combustion chamber
will be burnt completely clean,
should be used. The burning of moist wood will result in an increased amount of tarry soot,
and the remaining amount of
pollution and uneconomic fuel consumption. Newly chopped wood contains about 60-70
ashes will be minimal.
percent moisture, which makes it completely unsuitable as fuel. Allow newly chopped fire-
wood to dry in an open shed for a year before using it in the stove. Split firewood with a
"So when you light up your
diameter larger than 10 cm. Use firewood with a length on 25-35 cm.
stove, consider the envi-
ronment. We do.."
The use of larger quantities of fuel than recommended in the table page 2 will overtax the
stove and result in increased temperatures in the chimney as well as a lowered efficiency.
This may cause damage to both chimney and stove, and the annulment of the warranty.
What kind of wood to use?
Also, never use toxic materials such as chipboard, painted or impregnated wood.
Generally, beech wood is consid-
ered the best type of wood for
Maintenance and cleaning
burning. It burns evenly without
As any piece of equipment in daily use, your stove needs maintenance.
producing much smoke and the
ashes are clean and take up little
The stove should only be cleaned when cold. Use a dry cloth for cleaning the exterior of the
space. Ash, birch and maple
stove.
wood are fine alternatives.
Clean the interior regularly by removing ashes, soot and tar from the combustion chamber.
The smoke plate should be removed for cleaning as the reverse side will be covered in dirt
Vermiculite fire bricks
and soot. Finally check that the smoke's pathway through the smoke pipe and chimney is
A special non-inflammable
completely clear. You should also inspect the gaskets in the door for signs of wear. Replace
material. The vermiculite fire
them if permeable. Also, remember to oil the hinges of the door as required.
bricks both isolate and protect
the stove from attrition. Vermicu-
Empty the ash pan regularly. It can be emptied into your dustbin, as long as you make sure it
lite fire bricks and smoke plate
contains no hot embers.
are not covered by the warranty.
When in doubt as how to maintenance your stove, contact the dealer from whom you bought
Vermiculite is a very porous
it, or your chimney sweeper. It is especially important to check the stove and its chimney for
material, therefore handle with
blockages after a long period of non-use.
care. When refilling the stove,
put in the wood carefully, use the
The enamelled surface of the stove may wear down at certain places if the stove is
glove.
overheated.
Worn surfaces, however, can be repaired with a special Senotherm
Automatic door-closing
at your local vendor.
Varde Cast Iron S1, S2 and S3
If you are in doubt, please contact your vendor.
are equipped with our new-
developed automatic door-
The plates in the combustion chamber are Vermiculite plates and will eventually be worn –
closing system, witch secures an
as will the smoke plate. Should you accidentally break a plate, for instance by hitting it hard
correctly closing of the door,
with a piece of wood, this does not effect the quality of the combustion.
every time you've had it opened
You need not replace the plate until the gap is 5 mm. wide, or if the thickness of the plates, as
for putting new wood in the
a result of the daily use, is worn down to 2/3 of original thickness.
stove.
You just have to let go of the
The door is constructed with a spring
door from approx. half opened
This spring is very easy to change, just open the door fully, and the spring is situated by the
position, then the automatic
upper hinge. You can just dismantle it with a tong and mount the new spring instead.
system does the rest of the job
This spring is a part of the Automatic door-closing, and may never be removed.
for you.
When kindling the wood in the
Only use original spare parts from Varde Ovne.
stove, you can shortly leave the
door a little open, by leaving the Do not make any unauthorised changes.
door just in contact with the
All external parts of the stove become hot during use, too. Therefore exercise
closing-mechanism, when the
fire has caught fully, close the necessary caution when the stove is in use.
door by pushing it a bit.
®
spray paint, available
which automatically swings the door shut.
3
