Summary of Contents for MPMan MP434
- Page 1 For Model No. Instruction Manual MP434...
- Page 2 This manual contains important safety precautions and information of correct use. Please be sure to read this manual carefully before use so as to avoid any accidents. Do not place the product in hot, wet or dusty environment, especially in summer, do not leave the product inside a car with all windows closed.
-
Page 3: Specification
1. Specification Hardware CPU processor RK2818 624MHz + DSP 400MHz Flash 4 / 8GB Memory 256MB DDR2 RAM External storage microSD card slot recognizing up to 32GB 4.3 inch resistive touch screen LCD resolution 480 x 272 G-Sensor Wi-Fi Internal WIFI support IEEE802.11b/g High speed Mini USB2.0 Sound input/output Stereo sound 3.5mm earphone jack internal MIC only record... -
Page 4: Button Layout
2. Button layout Important Notice - If the device is freezing or stuck while using, press the reset button (a small hole) on the backside. - When the performance is slow after using some applications, it is recommended to run “Advanced Task Killer” and press End All. Power butten Earphone microSD... -
Page 5: Standby Mode
3. Standby mode Press power button for standby mode Press power button again to turn on the display and slide the lower lock icon to the upper one. 4. Charging To optimize battery life, be sure to fully charge the device before rst use. Also recommend to fully charge it once charging. -
Page 6: Main Screen
5. Main screen To go to home screen, slide the lower lock icon to the upper icon. Main screen consists of 5 di erent screen. Slice right/left to see other screen. To remove the short-cut icon from home screen, long press the icon and put it on the waste bin if the screen activates. - Page 7 Home button Directly go to home screen wherever you are. System notification There is a system noti cation bar on the top of screen. Pull down to see the screen below. Page 6...
- Page 8 Volume control to press +, - Menu button ( ) to see menu Add possible to put Shortcuts, Widgets, Folders, Wallpapers on the main screen. Wallpaper possible to set wallpaper you want. Search use web browser Notifications see the system noti cation on the tool bar. Settings go to Settings.
- Page 9 Return button ( ) to go to previous menu. Press function button ( ) to go to sub-menu. You will see all application as shown below To put the short-cut of application on the main screen, long press the application icon. Then, put it on if the screen activates Page 8...
- Page 10 6. How to connect/disconnect the device with/from computer Connect the device with the computer using USB cable, the device is automatically recognized by the computer as seen below from left to right photo. Press “Turn o the USB storage” to disconnect the device from the computer. Page 9...
- Page 11 7. Settings Press Settings icon ( ) to see screen below. Page 10...
- Page 12 Wireless and networks Wi-Fi – Press Wi-Fi to turn on/o Wi-Fi settings - Press Wi-Fi settings, check [Network noti cation], then the device will automatically search the available Wi-Fi signals. Select the network you want to connect with. Page 11...
- Page 13 Sound Set up each setting as you like. Display Set up each display option such as Brightness, Auto-rotate screen, etc. Page 12...
- Page 14 Location & security Set up screen lock – Protect your device from unauthorized use by creating a personal screen unlock pattern. Visible passwords – Show password as you type. Install from SD card – Install encrypted certi cates from SD card. Set password –...
- Page 15 Applications Unknown sources If you want to allow installation of non-Market Applications, check [Unknown sources] and presses OK. Basically, it is better to check. Page 14...
- Page 16 Manage applications All installed applications are listing. Press an application to manage. Press [Uninstall] to uninstall the selected application. Running services View and control currently running services. Development Set options for application development Page 15...
- Page 17 Account & sync Create your Gmail account. After connecting Wi-Fi network, the Gmail e-mailing system synchronizes your Gmail account with the device. Emails are automatically downloaded into the device. Privacy Factory data reset – Erase all data on device and restore factory default. Page 16...
- Page 18 TF card & device storage Check device memory and microSD card status. Page 17...
- Page 19 Language & keyboard Select Language – Choose your preferable language. Android keyboard – Android keyboard settings On keyboard settings, select “Input languages” and select countries you want. If you select more than two countries at “Input languages”, you can change keyboard type by scrolling the space bar on the keyboard.
- Page 20 How to install Applications(.apk file) into the device With your computer, search application le(.apk) that you want to install into the device. Download the le(.apk) into your computer. Connect the device with your computer. See above [How to connect/disconnect the device with/from the computer.] Copy and paste .apk le into the device and disconnect it from your computer.
- Page 22 For more information please check our website www.mpmaneurope.com...
