Summary of Contents for MPMan MPQC 784 IPS

  • Page 1 For Model No. User Manual MPQC 784 IPS...
  • Page 2 This manual contains important safety precautions and information of correct use. Please be sure to read this manual carefully before use so as to avoid any accidents. Do not place the product in hot, wet or dusty environment, especially during summer, do not leave the product inside a car with all windows closed.
  • Page 3: Specification

    Specification Hardware Software 7.85” IPS LCD Touch screen (1024x768 pixel) Android 4.2 Capacitive multi-touch (5 touch) point function Google browser CPU : ARM cortex A7 processor Wi-Fi connection RAM : DDR3 1GB (3D accelerator possible for 3D games) e-Book function (all e-book formats supported by application) Wi-Fi (IEEE802.11 b/g/n) for internet connection 1080P HD le playback USB host for OTG function...
  • Page 4 Nomenclature TV-out USB Reset Earphone Camera Speaker Camera Important Notice Power - If the device is freezing or stuck, press the Volume + reset button(a small hole) or long press power button for 7seonds. Volume - - When the performance is slow after using some applications, it is recommended to close running application in setting menu.
  • Page 5: Power On/Off

    1. Power On/Off 2. Desktop After turning on the device, desktop displays with shortcut icons and noti cation bar Page 4...
  • Page 6: Standby Mode(Screen Off Mode) / Unlock The Screen

    3. Standby mode(Screen off mode) / Unlock the screen Page 5...
  • Page 7: System Settings

    4. System settings On the desktop, press menu button and select system settings. Page 6...
  • Page 8: Wireless And Networks

    Press system settings 1. Wireless & networks 2. Sound Set up each setting as you like. Wi-Fi settings - Press Wi-Fi settings, then the device will automatically search the available Wi-Fi signals. Select the network you want to connect with. Page 7...
  • Page 9 3. Display 4. Storage Set up each setting as you like. Check device memory and microSD card status. Unmount SD card – Unmount the SD card for safe removal. Page 8...
  • Page 10 5. Battery 6. Apps Check battery usage status. Manage downloaded or running applications. Downloaded All installed application are listing. Page 9...
  • Page 11 Keep pressing an application to manage. Running services Press Uninstall to uninstall the selected application. View and control currently running services. Page 10...
  • Page 12: Location Access

    7. Location access Access to my location – Let apps that have asked your permission use your location information Wi-Fi & mobile network location – Let apps use Google’s location service to estimate your location faster. Anonymous location data will be collected and sent to Google. Page 11...
  • Page 13 8. Security Screen lock – Protect your device from unauthorized use by creating a personal screen unlock pattern. Make passwords visible – Show password as you type. Unknown sources - If you want to allow installation of non-Market Applications, Press Unknown sources and presses OK. Page 12...
  • Page 14: Language And Input

    9. Language & input Language – Choose your preferable language. Keyboard & input method – Change keyboard & keyboard settings. On Language & input settings, if you need other languages besides English on keyboard, press the relevant keyboard and enter the chosen Keyboard settings, select Keyboards, press the language you need.
  • Page 15: Date And Time

    10. Date & time Set date & time and format 11. Developer options Set options for application development 12. About tablet See status, legal information, ETC Page 14...
  • Page 16 How to connect/disconnect the device to/from the computer On main desktop, connect the device with the PC, drag noti cation bar on the desktop Page 15...
  • Page 17 Press “USB connected”, select “Turn on USB storage”. The device is recognized at Explorer of the computer. Now you can use it as an external storage. Page 16...
  • Page 18: How To Install Applications(.Apk File) Into The Device

    How to install Applications(.apk file) into the device Method 1. Connect the device with internet. See above [1.Wireless & networks] in order to connect internet. Follow the instruction on the screen for installation. Method 2. Connect the device with your computer. See above [How to connect/disconnect the device with/from the computer.] Note You may only download adult applications if you are at least 18 years of age, or at least the age of majority in the jurisdiction where you reside or from...
  • Page 19 HDMI connection with TV Turn on the device and TV Connect the device to the TV using HDMI cable. Note HDMI cable is optional, it may not come in the package, depending on countries. Page 18...
  • Page 20: How To Make Desktop Icons

    How to make desktop icons Press the icon of desktop and the pop-up displays. Page 19...
  • Page 21 Shortcuts Widgets Long press your desired APK icon and put it Long press your desired wiget icon and put it on the desktop. on the desktop. Wallpaper Long press the desktop, press Wallpapers and select one of categories of wallpaper. Select one you desire and press Set wallpaper.
  • Page 22: Change Input Method

    Change Input Method If your device was installed with other more input method, long press setting icon of keyboard, and the pop-up displays. Select the installed keyboard, then the keyboard will appear with your desired language you installed. Page 21...
  • Page 23 Specification Android 4.2 ARM cortex A7 processor SDRAM DDR3 1GB (3D accelerator possible for 4D games) Display 7.85" IPS LCD Capacitive touch panel Multi-touch screen Yes : 5 point multi-touch 4 / 8 / 16GB 3.5ø earphones   Audio port 1 x 5pin micro USB port (support USB host and OTG)  ...
  • Page 24 Page 23...
  • Page 25 For more information please check our website www.mpmaneurope.com Page 24...
