JasonL Quadro Square Boardroom table Assembly Instructions Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Quadro Square
Need help!
Boardroom table
Call us on
1300 527 665
Size: 1200 mm
Tools Required:
Power screwdriver; Allen key set (provided)
2 persons required for installation
Page 1 of 6

Advertisement

loading
Need help?

Need help?

Do you have a question about the Quadro Square Boardroom table and is the answer not in the manual?

Questions and answers

Related Manuals for JasonL Quadro Square Boardroom table

Summary of Contents for JasonL Quadro Square Boardroom table

  • Page 1 All manuals and user guides at all-guides.com www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 1200 mm Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation Page 1 of 6...
  • Page 2 All manuals and user guides at all-guides.com www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 1200 mm COMPONENTS Table top x1 Leg Quadro Square x2 Beam x2 Plastic bracket x8 SCREWS M8x20MM CSK x4...
  • Page 3 All manuals and user guides at all-guides.com www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 1200 mm STEP 02 STEP 01 Using Allen Key provided, attach 4 plastic brackets per leg (D) Using Allen Key provided, attach M8x20MM Socket head (F)- (as per picture above) using M6x20MM (G) Socket head screw.
  • Page 4 All manuals and user guides at all-guides.com www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 1200 mm STEP 03 Adjust extendable beam (C) to desired length using markers and secure beam at that length using screws provided...
  • Page 5 All manuals and user guides at all-guides.com www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 1200 mm STEP 05 STEP 04 TOP VIEW Attach beam (C) to legs (B) using nut insert in legs.
  • Page 6 All manuals and user guides at all-guides.com www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 1200 mm STEP 06 TABLE TOP BOTTOM VIEW Place desktop ontop of frame. Nut inserts in top will align with plastic joiner brackets using M6x30MM (H) sockets attached tops to frame.
