Prestel DTCP-10A User Manual

Android touch screen control panel (desktop)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Prestel DTCP-10A
Android Touch Screen Control Panel (Desktop)
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTCP-10A and is the answer not in the manual?

Questions and answers

Related Manuals for Prestel DTCP-10A

Summary of Contents for Prestel DTCP-10A

  • Page 1 Prestel DTCP-10A Android Touch Screen Control Panel (Desktop) USER MANUAL...

  • Page 2: Table Of Contents

    Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.

  • Page 3: Introduction

    1. Introduction This Android touch screen control panel adopts ARM Cortex-A55 architecture, with a main frequency of up to 1.8Ghz. It is equipped with 32GB EMMC FLASH, 4GB DDR4 RAM and Android 11.0 system. It is an open platform that supports the installation of third-party application APK and secondary development adaptation.

  • Page 4: Specifications

    4. Specifications Technical 4-core ARM Cortex-A53 1.8GHz Operation System Android 11 4GB DDR4 RAM Flash Memory 32GB EMMC FLASH Resolution 1280*800 Touch Type Capacitive Touch Screen Connection 1x Standard 10M/100M/1000M Ethernet RJ45 port, LAN/POE supporting POE function DEBUG 1x Micro USB, for debugging or data transmission 1x RS-485 port, reserved for APK secondary RS-485 development...

  • Page 5: Operation Controls And Functions

    5. Operation Controls and Functions Name Function Description Touch Capacitive touch screen, with standard Android interface. Screen POWER Used for system power on/off, screen off or wake-up. button RESET Function reservation, providing API interface, which can be button used for APK secondary development. DEBUG port Micro USB port, used for debugging or data transmission.

  • Page 6: Touch Panel Operation Guide

    6. Touch Panel Operation Guide 6.1 Network Settings Follow the steps below to set up the network for the product. Step 1. Power on the Android touch panel after connecting with power supply. Swipe up to unlock the touch screen and access the Android interface. 4/12...
  • Page 7 Step 2. After entering the Android interface, swipe up on the screen to pull out the apps list, and select the “Settings.apk” to open the application. Step 3. After opening the application, select “Network & internet” to enter the network settings interface. 5/12...
  • Page 8 Step 4. Select “Ethernet” to enter Ethernet network settings. Step 5. Scroll down to the bottom of the interface, then select “Ethernet Ip Mode” and set the IP mode to “static”. Step 6. Select “static” in the pop-up window and input the IP information to be set.
  • Page 9 Note: If a router is configured in the system, DHCP mode can be used, and the router can assign an IP to the product without setting it as a static IP. 7/12...

  • Page 10: File Transfer

    6.2 File Transfer Follow the steps below to transfer files. Step 1. After entering the Android interface, swipe up on the screen to pull out the apps list, and select the “Settings.apk” to enter the system settings. Step 2. Connect the product to a computer with a Micro USB cable, click the search box and input “USB”, then select “USB controlled by”.
  • Page 11 Step 3. Click “USB controlled by” to enter the USB Preferences interface. Scroll down to the bottom of the interface, then select “File Transfer” to be the USB purpose. Step 4. After setting, the disk of the Android touch panel can be seen on the computer for file transfer.
  • Page 12 Step 5. You can access the file manager from the Android interface to view the files in the host. Step 6. Enter the Files manager and click the setting icon in the upper right corner, then select “Show hidden files” to show the internal storage space. 10/12...
  • Page 13 Step 7. Click the menu icon on the left to wake up the menu bar. Scroll to the end, select "DTCP-10A", and enter the internal storage space. Step 8. After entering the disk, you can view the files stored on the disk (If you need to install the APK, simply click the installation package to install the APK).

  • Page 14: Application Example

    7. Application Example 12/12...
