R85 Rotary Disc 13-Foot
Self-Propelled Windrower Header
Unloading and Assembly Instructions
Published: December, 2013
Original Instruction
169487
Revision E

Advertisement

loading
Need help?

Need help?

Do you have a question about the R85 and is the answer not in the manual?

Questions and answers

Related Manuals for MacDon R85

Summary of Contents for MacDon R85

  • Page 1 R85 Rotary Disc 13-Foot Self-Propelled Windrower Header Unloading and Assembly Instructions Published: December, 2013 Original Instruction 169487 Revision E...
  • Page 2 INTRODUCTION This instructional manual describes the unloading, setup, and predelivery requirements for the MacDon Model R85 13-Foot Rotary Disc Self-Propelled Windrower Header. Use the Table of Contents to guide you to specific areas. CAREFULLY READ ALL THE MATERIAL PROVIDED BEFORE ATTEMPTING TO UNLOAD, ASSEMBLE, OR USE THE MACHINE.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS GENERAL SAFETY ..............................2 RECOMMENDED TORQUES ........................... 4 GENERAL ............................. 4 SAE BOLTS ............................4 METRIC BOLTS ............................ 4 FLARE TYPE HYDRAULIC FITTINGS ....................5 O-RING BOSS (ORB) HYDRAULIC FITTINGS ..................5 O-RING FACE SEAL (ORFS) HYDRAULIC FITTINGS ................ 6 CONVERSION CHART .............................

  • Page 4: General Safety

    GENERAL SAFETY CAUTION The following are general farm safety precautions that should be part of your operating procedure for all types of machinery: • Provide a first-aid kit for use in case • of emergencies. Protect yourself. • • Keep a fire extinguisher on the machine. Be When assembling, operating, and servicing sure the extinguisher is properly maintained machinery, wear all the protective clothing and...
  • Page 5 • Do NOT modify the machine. Unauthorized modifications may impair the function and/or safety and affect machine life. • Stop engine and remove key from ignition before leaving operator’s seat for any reason. A child or even a pet could engage an idling machine.

  • Page 6: Recommended Torques

    RECOMMENDED TORQUES C. METRIC BOLTS Std Coarse Bolt Torque* A. GENERAL Bolt Dia. 10.9 “A” The tables shown below give correct torque values lb-ft N·m lb-ft N·m for various bolts and cap screws. • Tighten all bolts to the torques specified in chart unless otherwise noted throughout this manual.

  • Page 7: Flare Type Hydraulic Fittings

    D. FLARE TYPE HYDRAULIC E. O-RING BOSS (ORB) HYDRAULIC FITTINGS FITTINGS Lock nut Flare Fitting Washer O-ring Groove Seat Body Flare seat a. Check flare and flare seat for defects that might cause leakage. a. Inspect O-ring and seat for dirt or obvious defects. b.

  • Page 8: O-Ring Face Seal (Orfs) Hydraulic Fittings

    a. Check components to ensure that the sealing F. O-RING FACE SEAL (ORFS) surfaces and fitting threads are free of burrs, nicks, HYDRAULIC FITTINGS and scratches or any foreign material. b. Apply lubricant (typically petroleum jelly) to O-ring and threads. If O-ring is not already installed, install O-ring.

  • Page 9: Conversion Chart

    CONVERSION CHART Inch-Pound Units SI Units (Metric) Quantity Factor Unit Name Abbr. Unit Name Abbr. Area acres acres x 0.4047 = hectares gallons per minute (US) gpm (US) x 3.7854 = Flow liters per minute L/min gallons per minute (Imp) x 4.5460 = Force pounds force...

  • Page 10: Step 1. Unload Header

    UNLOADING AND ASSEMBLY STEP 1. UNLOAD HEADER CAUTION To avoid injury to bystanders from being struck by machinery, do NOT allow persons to stand in unloading area. CAUTION Equipment used for unloading must meet or exceed the requirements specified below. Using inadequate equipment may result in chain breakage,...

  • Page 11: Step 2. Remove Underside Shipping Support

    UNLOADING AND ASSEMBLY STEP 2. REMOVE UNDERSIDE SHIPPING SUPPORT CAUTION Keep feet clear when removing final bolts. c. Remove two bolts (D) securing shipping channel to conditioner cover. a. Remove two bolts (A) on each end of support and remove shipping support (B). Discard support and hardware.

  • Page 12: Step 3. Lower Header

    UNLOADING AND ASSEMBLY STEP 3. LOWER HEADER IMPORTANT a. Attach a spreader bar to forks. Chain length must be sufficient to provide a minimum 4 ft. (1.2 m) vertical chain height. CAUTION d. Raise forks until lift chains are fully tensioned. Ensure spreader bar is secured to the forks so that it cannot slide off the forks or towards the mast as the header is lowered to...

  • Page 13: Step 4. Remove Shipping Stands

    UNLOADING AND ASSEMBLY STEP 4. REMOVE SHIPPING STANDS h. Remove the hook (E) at the front corner. Reinstall hardware. NOTE If Tall Crop Divider option will be installed, do NOT reinstall hardware. Repeat steps f. to h. for the other side of the header.

  • Page 14: Step 5. Unpack Curtains

    UNLOADING AND ASSEMBLY STEP 5. UNPACK CURTAINS Remove the two bolts (G) securing cutterbar doors to frame. g. Remove shipping wire around curtains. WARNING a. Remove nut and bolt (A) on baffle adjuster Ensure cutterbar is completely clear of plate (B). foreign objects.
  • Page 15 UNLOADING AND ASSEMBLY Acceptable Not acceptable Check that curtains hang properly and completely encloses cutterbar area. Minor creases in curtains will eventually straighten out. Remove shipping edge trim (A). m. Close the shield (B) over the two lifting holes and tighten fasteners (C).

  • Page 16: Step 6. Install Motor

    UNLOADING AND ASSEMBLY STEP 6. INSTALL MOTOR a. Unpack motor with preassembled hoses/lines. Ensure correct motor bundle for your windrower was supplied with the shipment. Windrower Model Bundle M205 B5456 M200 B5511 M155 and M150 B5510 M205 Configuration b. Remove four bolts (A) and remove plate (B) from gearbox.

  • Page 17: Step 7. Install Hose Supports

    UNLOADING AND ASSEMBLY STEP 7. INSTALL HOSE SUPPORTS M200, M155, AND M150 WINDROWER a. Retrieve hose support and hardware from shipping bundle. b. Attach support (A) to header with the two carriage bolts (B) and nuts. M205 WINDROWER a. Retrieve hose stand (C) from shipping bundle and install in accordance with instructions supplied.

  • Page 18: Step 8. Assemble Forming Shield

    UNLOADING AND ASSEMBLY STEP 8. ASSEMBLE FORMING SHIELD a. Unpack and remove shipping material. b. Remove bolts (B) from side deflectors (C). g. Assemble side deflectors (B) to cover with bolts (B), jam nut (D), washer (E), and nut (F) from previous step.
  • Page 19 UNLOADING AND ASSEMBLY Invert forming shield to installation position Forming Shield–Top View as shown. A - Two 7/16 in. B - Top Shield (11 mm) Holes C - Channel D - Header Forward E - 12.6 in. (320 mm) F - 5.7 in. (144.8 mm) G - 0.77 in.

  • Page 20: Step 9. Install Forming Shield

    UNLOADING AND ASSEMBLY STEP 9. INSTALL FORMING SHIELD a. Remove the header from the windrower (if attached) for ease of installation of the forming shield. Position forming shield under windrower frame. b. Retrieve plate (A) and hardware from forming shield bundle. c.
  • Page 21 UNLOADING AND ASSEMBLY Both Sides Set forming shield side deflectors to desired width by repositioning adjuster bars (H). Use the same hole location on both sides. Adjust rear fluffer deflector (J) to middle position. Loosen handles (K) if required. 169487 Revision E...

  • Page 22: Step 10. Attach Header To Windrower

    UNLOADING AND ASSEMBLY STEP 10. ATTACH HEADER TO DANGER WINDROWER Stop engine and remove key from ignition Refer to your self-propelled windrower unloading before leaving operator’s seat for any and assembly instructions or your self-propelled reason. A child or even a pet could engage windrower operator’s manual for windrower an idling machine.
  • Page 23 UNLOADING AND ASSEMBLY 1. If the optional center-link self-alignment kit is installed, start engine and activate the REEL UP switch on the GSL to raise the center-link (E). 2. Without the self-alignment kit, relocate the pin (G) at the frame linkage as required to raise the center-link (E).

  • Page 24: Step 11. Connect Center-Link

    UNLOADING AND ASSEMBLY STEP 11. CONNECT CENTER-LINK The center-link consists of either a hydraulic cylinder that adjusts the header tilt or angle and is controlled with switches at the operator’s station or a mechanical turnbuckle type link. An optional self-alignment kit controls the alignment of the center-link when attaching the link to the header.
  • Page 25 UNLOADING AND ASSEMBLY MECHANICAL LINK CAUTION WARNING Check to be sure all bystanders have cleared the area. Stop windrower engine and remove key before making adjustments to machine. A child or even a pet could engage the drive. 1. Stop engine and remove key from ignition. Reel Down Reel Up Header Up...
  • Page 26 UNLOADING AND ASSEMBLY c. Safety props are located on both header lift IMPORTANT cylinders on the windrower. Engage safety props Ensure pin (F) is fully inserted and hairpin is on both lift cylinders as follows: installed behind bracket on boot. WARNING Stop windrower engine and remove key before making adjustments to machine.

  • Page 27: Step 12. Connect Hydraulics

    UNLOADING AND ASSEMBLY STEP 12. CONNECT HYDRAULICS Hydraulics connections are different depending on which windrower the header is attached to. Refer to the appropriate section for your windrower. A. M205 Optional Couplers d. If optional quick-disconnect coupler kit is supplied with the windrower, install the kit prior to connecting the header hoses to the windrower.
  • Page 28 UNLOADING AND ASSEMBLY B. M200 DANGER Stop engine and remove key from ignition before leaving operator’s seat for any reason. A child or even a pet could engage an idling machine. 2. Locate cinch strap (E) through slot and under bracket (F) on windrower hose support.
  • Page 29 UNLOADING AND ASSEMBLY m. Disconnect couplers (M) and (N) at bundle (K) hose ends. Discard caps. h. Lower and lock lever (A). n. Remove O-ring from cap (O) and install over JIC Secure hose bundle (K) with three cinch threads on fitting at port (Y). straps (E).
  • Page 30 UNLOADING AND ASSEMBLY Pressure Return Case Drain s. Connect the three hoses from windrower to the fittings on the header as shown. Disconnect existing electrical harness at the header and replace with new harness (Q) supplied in kit. u. Assemble electrical harness (Q) to harness from windrower.

  • Page 31: M150 And M155

    UNLOADING AND ASSEMBLY C. M150 AND M155 DANGER Stop engine and remove key from ignition before leaving operator’s seat for any reason. A child or even a pet could engage an idling machine. 2. Locate cinch strap (E) through slot and under bracket (F) on windrower hose support.
  • Page 32 UNLOADING AND ASSEMBLY NOTE Secure electrical harness and case drain hose to existing hoses with plastic tie wrap or equivalent. m. Connect harness harness from windrower. M150 Shown - M155 Similar h. Move windrower left side platform OPEN position. n. Lower and lock lever (A). Secure hose (J) with three cinch straps (E).

  • Page 33: Step 13. Install Options

    UNLOADING AND ASSEMBLY STEP 13. INSTALL OPTIONS Install options (if supplied with shipment) in accordance with the instructions supplied with each kit or as follows if instructions were not supplied. DANGER Stop engine and remove key from ignition before leaving operator’s seat for any reason.

  • Page 34: Step 14. Lubricate The Header

    UNLOADING AND ASSEMBLY STEP 14. LUBRICATE THE HEADER DANGER Stop engine and remove key from ignition before leaving operator’s seat for any reason. A child or even a pet could engage an idling machine. a. Wipe grease fitting with a clean cloth before greasing to avoid injecting dirt and grit.
  • Page 35 UNLOADING AND ASSEMBLY Greasing Points High temperature extreme pressure (EP2) performance with 1% max molybdenum disulphide (NLGI grade 2) lithium base Belt Tensioner Pivot (One Place) 10% moly grease is recommended for driveline shaft slip joint only Driveline Universals (Four Places) Roll Shaft Bearings (LH - Two Places) Driveline Shaft (Two Places) 169487...
  • Page 36 UNLOADING AND ASSEMBLY Greasing Points (cont’d) High temperature extreme pressure (EP2) performance with 1% max molybdenum disulphide (NLGI grade 2) lithium base Roll Shaft Bearings (RH - Two Places) 10% moly grease is recommended for driveline shaft slip joint only Driveline Universals (Two Places) Driveshaft (One Place) 169487...
  • Page 37 UNLOADING AND ASSEMBLY Oil Levels Check plug Oil should slightly run out when removed. Conditioner Gearbox Oil Level (Check With Top of Header Horizontal) Check plug Oil should slightly run out when removed. Gearbox Lubricant Level (Check With Top of Header Horizontal) 169487 Revision E...

  • Page 38: Step 15. Perform Predelivery Checks

    PREDELIVERY CHECKS STEP 15. PERFORM PREDELIVERY CHECKS WARNING Stop windrower engine and remove key before making adjustments to machine. A child or even a pet could engage the drive. IMPORTANT To avoid machine damage, check that any shipping dunnage has not fallen down between auger and pans.

  • Page 39: Header Float

    PREDELIVERY CHECKS B. HEADER FLOAT a. Set the float fine adjustment to MID-RANGE with the windrower float adjustment system in the cab. Refer your self-propelled windrower operator’s manual. b. Check float by grasping the front corner of header and lifting. The force to lift should be 95–105 lbf (426–471 N) and should be approximately the same at both ends.

  • Page 40: Check Level Of Header

    PREDELIVERY CHECKS C. CHECK LEVEL OF HEADER a. Park windrower on level ground and raise header approximately 6 in. (150 mm) off ground. DANGER Stop engine and remove key from ignition before leaving operator’s seat for any reason. A child or even a pet could engage an idling machine.

  • Page 41: Conditioner Rolls

    PREDELIVERY CHECKS D. CONDITIONER ROLLS I. ROLL GAP 3/4 in. (19 mm) Crop d. Examine roll timing (distance ‘X’) at each end of the rolls with the header fully lowered. a. The amount of thread protruding through jam nut Each steel bar on one roll should be centered should be 3/4 in.

  • Page 42: Skid Shoes

    The following manuals should be stored in the manual storage case in the windrower cab: WARNING • R85 13-Foot Rotary Disc Pull-Type Mower To avoid bodily injury or death from Conditioner and Self-propelled Windrower unexpected start-up or fall of raised Header Parts Catalog - MD #169459.

  • Page 43: Run-Up The Header

    Refer to your self-propelled windrower operator’s manual for windrower operating instructions. NOTE Higher engine rpm may be required to engage the R85 header. Do NOT exceed 1800 rpm. a. Start windrower and run the machine slowly for 5 minutes, watching and listening FROM THE OPERATOR’S...
  • Page 44 NOTES 169487 Revision E...
  • Page 45 NOTES 169487 Revision E...
  • Page 46 MacDon Inc. 10708 N. Pomona Avenue Kansas City, Missouri United States 64153-1924 t. (816) 891-7313 f. (816) 891-7323 MacDon Australia Pty. Ltd. A.C.N. 079 393 721 P.O. Box 243 Suite 3, 143 Main Street Greensborough, Victoria Australia 3088 t. 03 9432 9982 f.
  • Page 47 R85 Rotary Disc 13-Foot SP Header Predelivery Checklist Perform these checks and adjustments prior to delivery to your customer. See the Unloading and Assembly Instructions for details. The completed checklist should be retained either by the Operator or the Dealer.
