Summary of Contents for Acer NITRO XV272U V3
- Page 1 Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 1 — ACER Monitor XV272U V3 LIFECYCLE EXTENSION GUIDE...
-
Page 2: Table Of Contents
Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 2 — Directory 1、Important Safety Notice ............3 2、Exploded Diagram ............4-5 3、Mechanical Instruction ............6 4、Assembly and Disassembly SOP ...........6-10 5、Troubleshooting .............10-13 ........13 6、FW/EDID SOP&FRU（Field Replaceable Unit）list... -
Page 3: 1、Important Safety Notice
Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 3 — Safety Notice Any person attempting to service this chassis must familiarize with the chassis and be aware of the necessary safety precautions to be used when serving electronic equipment containing high voltage... -
Page 4: 2、Exploded Diagram
Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 4 — 2.Exploded Diagram NO、 Item Power Back Column Base Module mainboard name strip shell assembly assembly NO、 Item Shielding keystroke Key pad horn name sleeve case... -
Page 5: 3、Mechanical Instruction
Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 5 — Material Comparison Table： Customer part Item name Dosage Remark number Module KL.2700H.049 mainboard Power strip Back shell Column assembly Base assembly Key sleeve Shielding case Key stroke Key pad horn 3. Mechanical Instruction 3.1. -
Page 6: 4、Assembly And Disassembly Sop
Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 6 — 4. Assembly and Disassembly SOP 4.1. Physical dismantling steps 4.2. Press the quick release button up to remove the base... - Page 7 Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 7 — 4.3. Loosen the hand screw counterclockwise and disassemble the column and base. 4.4. Remove floor screws and VESA area screws. 4.5. Remove the machine along the ground side, remove the machine mouth, then remove the left and right sides, and finally remove the sky side 4.6.
- Page 8 Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 8 — 4.7. Press the clasp outwards and remove the key plate 4.8. Remove the screen line, power supply line, signal line 4.9. Remove the locking shield cover screws. 4.10. Remove the locking motherboard screws and disassemble the wire...
- Page 9 Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 9 — 4.11. Remove the light guide 4.12. Dismantling the machine is complete 1. Column 2. Base 3. Power cable 5. Key cable 6. Screen cable 7. Mainboard 8. Shield cover 9. Module 10.CM3*4 screws 11.CM4*10 screws 12.CB3*5 screws 13. Conductive foam 14. Light...
-
Page 10: 5、Troubleshooting
Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 10 — Troubleshooting 5.1. Problems that arise Possible solutions *Whether to turn on the power The power LED is not lit *Whether to connect the power cord *Whether the PC matches Plug and Play... - Page 11 Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 11 — Image has chromatic aberration * Adjust RGB color or reselect color temperature (white does not look white) Tips: FreeSync has special requirements for graphics cards and monitors developed by FreeSync for display conversion technology, please check whether the graphics card model supports it.
- Page 12 Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 12 — Horizontal or Use WIN95\/98 shutdown mode to adjust the clock and focus, or use the hotkey (auto vertical distortion key). appears on the screen Tips: FreeSync has special requirements for graphics cards and monitors developed by FreeSync for display conversion technology, please check whether the graphics card model supports it.
-
Page 13: 6、Fw/Edid Sop&Fru（Field Replaceable Unit）List
Acer XV272U V3 LIFECYCLE EXTENSION GUIDE — 13 — 6、FW/EDID SOP&FRU（Field Replaceable Unit）list * Please contact the local service center to find out the solution，If the software is defective or the part needs to be replaced.
